Manufactured by (DVDR) for
Thank you for purchasing this quality product. Be sure to check all packing material carefully for small
parts. which may have come loose inside the carton during shipment. Identify and count all parts and
compare with the parts list below:
No.
1
2
3
Hardware List
No.
A
B
Part List
C
D
E
F
Hardware
& Legs
Hardware Pack Location (s) : Bolts pack inside bottom drawer ( Leg inner carton)
Chest SKU #
32616217
Version #1-2023/10/02
JCBC (M6) with Spring Washer and Washer
Allen Key (M4)
Phillips Screwdriver
Chest
Front Left Leg (Packed Inside Drawer)
Front Right Leg (Packed Inside Drawer)
Back Left Leg (Packed Inside Drawer)
Back Right Leg (Packed Inside Drawer)
Tipping Restraint (Packed Inside Drawer)
ASSEMBLY INSTRUCTION
DVDR HD1619-392C CHEST
Description
Description
A
D
B
SKU# 32616217
Dimension
M6 x P1.0 x 40mm
4 x 65mm
-
Not Provided
C
PAGE 1 OF 2
Qty
8 Pcs
1 Pc
Qty
1 Pc
1 Pc
1 Pc
1 Pc
1 Pc
1 Pc
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ROOMS TO GO DVDR HD1619-392C
Summary of Contents for ROOMS TO GO DVDR HD1619-392C
- Page 1 ASSEMBLY INSTRUCTION DVDR HD1619-392C CHEST SKU# 32616217 Manufactured by (DVDR) for Thank you for purchasing this quality product. Be sure to check all packing material carefully for small parts. which may have come loose inside the carton during shipment. Identify and count all parts and...
