Manufactured by (DVDR) for
Thank you for purchasing this quality product. Be sure to check all packing material carefully for small
parts. which may have come loose inside the carton during shipment. Identify and count all parts and
compare with the parts list below:
No.
1
Hardware List
2
3
No.
A
Part List
B
C
Hardware
& Legs
Hardware Pack Location (s) : Bolts pack inside bottom drawer ( Leg inner carton)
Nightstand SKU #
Version #1-2024/04/08
DVDR HD4221-404 NIGHTSTAND
JCBC SCREW NYLOCK
SPRING WASHER
JCBC nylock with
Spring Washer
FLAT WASHER
and Washer
Allen Key (M4)
Phillips Screwdriver
Nightstand
Leg (Packed Inside Drawer)
Tipping Restraint (Packed Inside Drawer)
32542210
ASSEMBLY INSTRUCTION
Description
Description
A
B
SKU# 32542210
Dimension
M6 x P1.0 x 60mm
M6 x 12mm
M6 x 19 x 1.0mm
4 x 65mm
-
Not Provided
PAGE 1 OF 2
Qty
8 Pcs
1 Pc
Qty
1 Pc
4 Pcs
1 Pc
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for ROOMS TO GO DVDR HD4221-404
Summary of Contents for ROOMS TO GO DVDR HD4221-404
- Page 1 ASSEMBLY INSTRUCTION DVDR HD4221-404 NIGHTSTAND SKU# 32542210 Manufactured by (DVDR) for Thank you for purchasing this quality product. Be sure to check all packing material carefully for small parts. which may have come loose inside the carton during shipment. Identify and count all parts and...
- Page 2 ASSEMBLY INSTRUCTION DVDR HD4221-404 NIGHTSTAND SKU# 32542210 Manufactured by (DVDR) for ASSEMBLY TIPS: 1. Remove hardware from box and sort by size. 2. Please check to see that all hardware and parts are present prior start of assembly. 3. Please follow attached instructions in the same sequence as numbered to assure fast and easy assembly.
