Mocka Aspen Bookcase Assembly Instructions Manual page 5

Aspen Bookcase
A B
bolt locking
x22 nut x 22
CL
DL
CR
L+R
slide rail
slide rail
x2
W
safety
strap x 1
WARNING: Any furniture that is not anchored to a wall has the potential to tip over in certain
circumstances, i.e. if a child attempts to climb up on the furniture or in the event of an earthquake.
Accordingly, we recommend that all furniture is anchored to a wall. We supply a free safety wall
anchor with all furniture sold and we recommend these are used to prevent your product tipping.
The fixing device provided should fit most wall types, but please note that different wall materials
may require different fixing devices from those supplied.
mocka.co.nz I mocka.com.au
C
dowel
x20
I
DR
L+R
handle
x2
x2
HARDWARE SUPPLIED
Y
screw
x 1
WALL STRAP
E
D
long screw small screw
x10 x8
J K
long screw nut
x4 x4
X
wall
anchor x 1 screw x 1
Phillips & Flathead screwdrivers
and hammer required
For quicker assembly, we recommend the
use of a power drill on a low-speed setting.
F
medium screw
x6
M
N
cover
medium screw
x8
x 16
V Z
wall washer
x 1
