LINCOLN ELECTRIC EUROPE
Service Notice N° : ESN0078 Rev.01
Date:
Product
PRESTOTIG 160 PFC
PRESTOTIG 180 FORCE W000382577
PRESTOTIG 220 FORCE W000382578
CITOTIG 1600 HPF
CITOTIG 1800 FORCE
CITOTIG 2200 FORCE
INVERTEC 175TP
Be sure that only qualified individuals perform all installation, operation, maintenance
and repair procedures. Lincoln Electric is not responsible for damages caused by
improper installation, improper care or abnormal operation.
Before opening or disassembling any parts of the product, the power must be turned
OFF and the product must be disconnected from the input power source. Only
Lincoln trained service technicians are authorized to perform these modifications.
Explanation of the Problem
Randomly, after starting or during welding, the front panel turns off completely and the welding
arc is extinguished
Correction of the Problem
Problem can be solved by cleaning from the paint the area under the earth connectors. In
addition, only on the INVERTEC 175TP, replacing the 7 metal standoff that are fixing the HF
board (W000274816) and Control Panel PCB (R-6042-086-2R) with plastic ones.
22 March 21
Random shut down of front panel PCB
K Number
W000273518
W000273517
W000382579
W000382580
K14169-1
Code Number
-
-
-
-
all serial numbers below
-
-
50394
WARNING
1
Serial Numbers
P12104xxxxx
Advertisement
Related Manuals for Lincoln Electric PRESTOTIG 160 PFC
Summary of Contents for Lincoln Electric PRESTOTIG 160 PFC
- Page 1 WARNING Be sure that only qualified individuals perform all installation, operation, maintenance and repair procedures. Lincoln Electric is not responsible for damages caused by improper installation, improper care or abnormal operation. Before opening or disassembling any parts of the product, the power must be turned OFF and the product must be disconnected from the input power source.
- Page 2 Correction of the Problem step by step for Invertec 175TP (K14169-1), PRESTOTIG 160 PFC, PRESTOTIG FORCE 180,220 and CITOTIG 1600 HPF, CITOTIG FORCE 1800, 2200 (W000273518,W000382577, W000382578, W000273517, W000382579, W000382580) 1. Remove the machine cover. 2. Locate all earth/ground connectors fixed on the machine metal frame 3.
- Page 3 Correction of the Problem for Invertec 175TP (K14169-1) 7 wrong metal standoff 1. Remove the machine cover. 2. Locate the HF PCB and the Control Panel PCB mounted on the back of the machine front panel (the following picture is showing you the four standoff on the left side, three more are on the right side) 3.
