- Page 1 IM3210 12/2024 REV01 ® SPRINTER 160S / 180S OPERATOR’S MANUAL ENGLISH Lincoln Electric Bester Sp. z o.o. ul. Jana III Sobieskiego 19A, 58-260 Bielawa, Poland www.lincolnelectric.eu...
-
Page 2: Table Of Contents
12/05 THANK YOU! For choosing the QUALITY of the Lincoln Electric products. Please check packaging and equipment for damage. Claims for material damaged in shipment must be notified immediately to the dealer. For ease of use, please enter your product identification data in the table below. Model Name, Code & Serial Number can be found on the machine rating plate. -
Page 3: Technical Specifications
Technical Specifications NAME INDEX SPRINTER ® 160S CE K14436-1 SPRINTER ® 180S CE K14437-1 INPUT Input Voltage U1 EMC Class Frequency ® SPRINTER 160S CE 230V ± 10%, 1-phase 50/60Hz 120V ± 10%, 1-phase ® SPRINTER 180S CE Power factor for max input Input Power at Rated Cycle Input Amperes I1max current... - Page 4 RECOMMENDED INPUT CABLE AND FUSE SIZES Fuse Type DZ/Gf or Circuit Breaker D Power Lead with plug ® SPRINTER 160S CE 3 Conductor, 2,5mm 16A, D16A* 3 - pin, 16A/250V ® SPRINTER 180S CE Maximum recommended extension cord Minimum recommended extension cord size length ®...
-
Page 5: Eco Design Information
ECO design information The equipment has been designed in order to be compliant with the Directive 2009/125/EC and the Regulation 2019/1784/EU. Efficiency and idle power consumption: Efficiency when max power Index Name Equivalent model consumption / Idle power consumption K14436-1 SPRINTER ®... - Page 6 Tig Process: In TIG welding process, gas usage depends on cross-sectional area of the nozzle. For commonly used torches: Helium: 14-24 l/min Argon: 7-16 l/min Notice: Excessive flow rates causes turbulence in the gas stream which may aspirate atmospheric contamination into the welding pool.
-
Page 7: Electromagnetic Compatibility (Emc)
If any electromagnetic disturbances are detected the operator must put in place corrective actions to eliminate these disturbances, if necessary with assistance from Lincoln Electric. WARNING This equipment complies with IEC 61000-3-12. -
Page 8: Safety
Failure to follow the instructions in this manual could cause serious personal injury, loss of life, or damage to this equipment. Read and understand the following explanations of the warning symbols. Lincoln Electric is not responsible for damages caused by improper installation, improper care or abnormal operation. - Page 9 FUMES AND GASES CAN BE DANGEROUS: Welding may produce fumes and gases hazardous to health. Avoid breathing these fumes and gases. To avoid these dangers the operator must use enough ventilation or exhaust to keep fumes and gases away from the breathing zone. ARC RAYS CAN BURN: Use a shield with the proper filter and cover plates to protect your eyes from sparks and the rays of the arc when welding or observing.
-
Page 10: Installation And Operator Instructions
Introduction ® welding machines SPRINTER 160S Recommended equipment, which can be bought by user, SPRINTER ® 180S CE enables welding: was mentioned in the chapter "Accessories" SMAW (MMA), GTAW (Lift TIG) The complete package contains: Manual Instruction (USB) ... - Page 11 Controls and Operational Features 4. Power Switch ON/OFF (I/O): Controls the input power to the machine. Be sure the power source is connected to the mains supply before turning power on ("I"). 5. Remote Control Connector Plug: To install Remote Control Kit. This connector allows connection Remote Control.
- Page 12 User Interface 15. Welding process parameter indicator: LED indicates the active process parameter: ARC FORCE: The output current is temporarily increased to clear short circuit connections between the electrode and the work piece. Lower values will provided less short circuit current and a softer arc.
- Page 13 TIG method (contact ignition and lift maintenances, it is recommended to contact the nearest ignition). Technical Service Center or Lincoln Electric. Repairs and modifications performed by unauthorized service or ® ® SPRINTER 160S CE / SPRINTER 180S CE does not personnel will cause, that the manufacturer’s warranty...
- Page 14 We respond to our customers based on the best information in our possession at that time. Lincoln Electric is not in a position to warrant or guarantee such advice, and assumes no liability, with respect to such information or advice. We expressly disclaim any warranty of any kind, including any warranty of fitness for any customer’s particular purpose,...
-
Page 15: Troubleshooting
Troubleshooting Problem Possible Cause Recommended Course of Action Make certain that the input power switch is in the “ON” position and machine is plugged Check the input voltage at the Machine not working - machine. Input voltage must no output, no fan. - Page 16 Clean oily organic contamination from the work piece. Tungsten electrode contaminated. Replace sharpen. Black areas along weld Check for contaminated gas or bead. leaks in the gas line, torch, or connections shielding insufficient. Increase gas flow; reduce tungsten stickout beyond gas cup.
-
Page 17: Weee
12/05 Part list reading instructions Do not use this part list for a machine if its code number is not listed. Contact the Lincoln Electric Service Department for any code number not listed. Use the illustration of assembly page and the table below to determine where the part is located for your particular code machine. -
Page 18: Accessories
Accessories OPTIONS & ACCESSORIES K10095-1-15M REMOTE CONTROL, 15 M K10398 EXTENSION CABLE FOR REMOTE CONTROL BOX, 15 M W000011139 KIT 35C50 WTT2 TIG TORCHES AIR W10529-14-4V WTT2 17 TIG TORCH WITH GAS VALVE 4M AIR COOLED English English... -
Page 19: Dimension Diagram
Dimension Diagram 11/24 English English...
