- Page 1 Instructions for use ECAM31X.6Y - 31X.8Y...
-
Page 2: Table Of Contents
Contents Magnifica Evo Next DESCRIPTION OF THE MACHINE (A) ................4 DESCRIPTION OF PANEL (B) ..................6 Following selection of drink (e.g. Espresso) ............7 DESCRIPTION OF HOMEPAGE (C) ................. 7 DESCRIPTION OF ACCESSORIES (D)* ................8 DESCRIPTION OF MILK CARAFE (E) ................9 USING THE MACHINE FOR THE FIRST TIME .............. - Page 3 COFFEE-BASED DRINKS ................... 26 Preparation with pre-ground coffee ..............27 Tips for a hotter coffee ..................28 DIRECTIONS FOR COFFEE-BASED DRINKS..............28 MILK-BASED DRINKS ....................29 Preparing the milk carafe ..................29 What milk to use? ....................29 Filling and attaching the milk carafe ..............29 Making milk-based drinks ..................30 Cleaning the milk carafe after each use (Clean function) ........30 Preparing several drinks in succession: ..............30...
-
Page 4: Description Of The Machine (A)
Description of the machine (A) Magnifica Evo Next Bean hopper with lid Pre-ground coffee funnel flap Cup shelf Accessories connector flap Coffee spouts (height-adjustable) Cup tray Drip tray Power cord Removable water tank... - Page 5 A10. Condensate tray A11. Grounds container A12. Drip tray grille A13. Drip tray water level indicator A14. Brewing unit flap A15. Brewing unit housing A16. Removable brewing unit A17. Coffee grinder adjustment dial...
-
Page 6: Description Of Panel (B)
Description of panel (B) Magnifica Evo Next ON/Standby button Machine settings menu button Press OK to confirm Scroll arrow/intensity selection - pre-ground Scroll arrow/quantity selection button (Esc) used to exit Profile change button "My" button: customization of drinks Direct drink selection B10. -
Page 7: Following Selection Of Drink (E.g. Espresso)
Description of homepage (C) Magnifica Evo Next Profile 1 Choose the drink Filter spent indicator Descaling required indicator Selected profile Milk carafe Clean alert indicator Following selection of drink (e.g. Espresso) Espresso Name of selected drink Selected quantity (variable using “<” button B5) Selected intensity (variable using “>”... -
Page 8: Description Of Accessories (D)
Description of accessories (D)* Magnifica Evo Next (* Accessories: number and type differ according to model) Pre-ground coffee measure Hot water spout "Water Hardness Test" strip Descaler Water softener filter... -
Page 9: Description Of Milk Carafe (E)
Description of milk carafe (E) Magnifica Evo Next Milk carafe lid Froth dial Milk spout connector (non removable) Lid release button Milk carafe connector Milk spout Milk intake tube (silicone) Milk container... -
Page 10: Using The Machine For The First Time
WATCH THE VIDEO HERE NextUsing the machine for the first time Magnifica Evo Please note: • Possible traces of coffee in the grinder are the result of settings tests performed on the machine before sale, proof of the meticulous care and attention we invest in our products. •... -
Page 11: Fill The Water Tank
Fill the water tank 4. Remove the water tank (A9) (fig. 4). 5. Fill the tank with cold drink- ing water up to the MAX level (fig. 5) and reposition it in the machine, then press ">” (B4). Prepare the machine 6. -
Page 12: Check The Hardness Of The Water
Check the hardness of the water The machine will prompt for descaling to be carried out after a predeter- mined period of time, depending on the water hardness. The machine can also be programmed according to the actual hardness of the local water supply, so that descaling is required less frequently. -
Page 13: Installing A Filter
Installing a filter To ensure the performance of the machine remains constant over time, a message will suggest you install a De’Longhi water softener filter (D5). Proceed as follows to install the filter straight away, or alternatively, press “ ” (B6) to postpone installation: 18. -
Page 14: Tutorial
Tutorial A short video tutorial will help you get to know your machine better. Support for operation Scanning the QR code shown in the display with your smartphone, you can get access to manuals and informative materials for operation of the machine. -
Page 15: Turning The Machine On
Turning the machine on Magnifica Evo Next Please note: Each time the machine is turned on, it carries out an automatic preheat and rinse cycle, which cannot be interrupted. The machine is not ready for use until the cycle has been completed. 0.5 seconds 1. -
Page 16: Switching Off For Extended Periods
Turning the machine off Magnifica Evo Next Whenever the machine is turned off after being used to make coffee, it will run a rinse cycle automatically. 1. To turn the machine off, press the button (B1) and hold for 0.5 second (fig. 20). 2. -
Page 17: Access The Settings Menu
WATCH THE VIDEO HERE Menu settings Magnifica Evo Next Access the settings menu 1. Pressthe button (B2) (fig. 22). The settings are divided into three topics: • Maintenance • Preferences • Info Rinsing Auto-off Statistics Descaling Beep sound Serial number Water filter Energy saving Support... -
Page 18: Descaling
Ready to start descaling? (25 min) To ensure the performance of the machine remains constant over time, it is advisable to install a De’Longhi water softener filter (D5). For further information, visit www.delonghi.com. EAN: 8004399327252 1. Press the button (B2). -
Page 19: Milk Carafe
“<” (B5) until the required topic is highlighted; otherwise press “ ” (B6) to exit. 8. Press “ ” a second time to go back to the homepage. Maintenance: Milk carafe 1. Press the button (B2). Maintenance 2. Use the scroll arrows “>” (B4) or “<... -
Page 20: Auto-Off
7. Press “OK” (B3): the machine will run a rinse cycle, releasing hot water from the spouts. 8. Once rinsing is complete, remove the water tank (fig. 31) and empty 9. Remove the filter (D5) (if installed) from the water tank and press the forward arrow “>”... -
Page 21: Energy Saving
3. Use the scroll arrows “>” (B4) or “<” (B5) to select “Beep” (fig. 34). If enabled, the machine emits a beep whenever an operation is per- Preferences formed. Selecting this item, you can enable or disable the beep. 4. Press “OK” (B3): the display will show the preference currently Beep selected. -
Page 22: Grinder
Please note: The effect of varying the temperature is most noticeable with long drinks. Grinder Preferences: 1. Press to access the settings menu (fig. 13). 2. Use the scroll arrows “>” (B4) or “< “(B5) to select “Preferences”. Press “OK” (B3). -
Page 23: Statistics
3. Use the scroll arrows “>” (B4) or “< “(B5) to select “Languages” (fig. 39). To enter a new language setting, proceed as follows: 4. Press “OK” (B3) and change the selection using the scroll arrows “>” (B4) or “<” (B5). -
Page 24: Serial Number
Serial number Info: 1. Press the button (B2). Info 2. Use the scroll arrows “>” (B4) or “< “(B5) to select “Info”. Press “OK” (B3). Serial number: 3. Use the scroll arrows “>” (B4) or “< “(B5) to select “Serial number” xxxxxxxxxxxxxxx (fig. -
Page 25: Selection Of Profiles
Selection of profiles Magnifica Evo Next The machine has 3 selectable profiles, each one of which identified by a different colour: • Profile 1: • Profile 2: • Profile 3: The default setting is Profile1: to select a different profile, press the button (B7): the profile can be selected both before and after making the... -
Page 26: Set Up The Machine To Make Coffee-Based Drinks
WATCH THE VIDEO HERE Coffee-based drinks Magnifica Evo Next Set up the machine to make coffee-based drinks Important! Do not use green, caramelized or candied coffee beans as they could stick to the coffee grinder and render it unusable. 1. Place 1 or 2 cups under the coffee spout (A5). 2. -
Page 27: Preparation With Pre-Ground Coffee
livery of coffee) appears on the display. 6. Once the drink has been delivered, changes can be saved and stored in the current profile, pressing “OK” (B3) . If you do not want to save any new settings, press “ ”... -
Page 28: Tips For A Hotter Coffee
Directions for coffee-based drinks Magnifica Evo Next • While the machine is making coffee, delivery can be interrupted at any time by pressing the button corresponding to “Stop” (B5). or “ ” (B6). • At the end of delivery, to increase the quantity of coffee in the cup, simply press the button corresponding to “Extra”... -
Page 29: Milk-Based Drinks
WATCH THE VIDEO HERE Milk-based drinks Magnifica Evo Next Preparing the milk carafe Please note To avoid the preparation of milk with insufficient froth or large bub- bles, always clean the milk carafes as described in sections “Cleaning the milk carafe after each use (Clean function)” “Thorough cleaning of milk carafe”... -
Page 30: Making Milk-Based Drinks
4. Reposition the lid on the milk container; 5. Lower the flap of the carafe connector (A4) and attach the carafe, pushing it fully home (fig. 54). The machine emits a beep (if the beep function is enabled); 6. Place a sufficiently large cup under the coffee spouts (A5) and under the milk spout (E6). -
Page 31: After Multiple Preparations, There Is Enough Milk Left In The Container To Make Further Drinks
After multiple preparations, there is enough milk left in the container to make further drinks • Having carried out the cleaning step (“Clean” function), remove the milk carafe and put it straight in the refrigerator. The carafe contain- ing milk can be kept in the refrigerator no more than 2 days, after which time all components should be cleaned as described in the section “Thorough cleaning of milk... -
Page 32: Hot Water
Hot water Magnifica Evo Next 1. Push down the flap of the accessories compartment (A4) and attach the hot water spout (D2) (fig. 7). 2. Place a cup under the hot water spout. 3. On the control panel (B), press the image that indicates hot water. 4. -
Page 33: My" Function
“My” function Magnifica Evo Next With the “my” function, you can select the quantity of each single ingredi- ent used for preparation of the hot drink you want to make. 1. Check that the selected profile (C3) is the one for which you want to customize the drink. -
Page 34: Cleaning The Machine
WATCH THE VIDEO HERE Cleaning the machine Magnifica Evo Next ➡ ➡ ➡ COFFEE GROUNDS DRIP TRAY AND DRIP TRAY INTERNAL CIRCUIT OF THE CONTAINER GRILLE MACHINE ➡ ➡ ➡ COFFEE SPOUTS INSIDE OF THE MACHINE WATER TANK ➡ ➡ ➡... -
Page 35: Internal Circuit Of The Machine
Which items are dishwasher-safe Hot Lattecrema Carafe Drip tray grille (A12) (all components must be disassembled) Internal circuit of the machine If the machine has not been used for more than 3-4 days, it is strongly rec- ommend that before any further use, it should be switched on (Turning the machine on) and rinsed 2 or 3 times, selecting the relative function... -
Page 36: Drip Tray And Drip Tray Grille
Important! Danger of scalding If several milk-based drinks are prepared one after the other, the metal cup grille (A6) becomes hot. Wait for it to cool down before touching it, and handle from the front only. To clean (with the machine on): 1. -
Page 37: Inside Of The Machine
Inside of the machine Danger of electric shock! Before carrying out cleaning operations on internal parts, the machine must be turned off (see “Turning the machine off”) and unplugged from the mains power supply. Never immerse the machine in water 1. -
Page 38: Pre-Ground Coffee Funnel
5. Immerse the brewing unit in cold drinking water for about 5 min- utes, then rinse under the tap; Important! RINSE WITH WATER ONLY NO DETERGENTS - NO DISHWASHER 6. Do not use detergents when cleaning the brewing unit, as they could damage it. - Page 39 WATCH THE VIDEO HERE 1. Press the release button (E4) and lift the lid (fig. 51). 2. Turn the milk delivery spout (E6) into an upright position and pull out until detached (fig. 61); pull the intake tube free (E7) (fig.
-
Page 40: Descaling
WATCH THE VIDEO HERE Descaling Magnifica Evo Next Important! • Before use, read the instructions and the labelling on the descaler pack. • Use only descaler supplied by De’Longhi. If unsuitable descaler is used, or descaling is not carried out properly and when required, the machine may develop faults not covered by the manufactur- er’s guarantee. - Page 41 8. Place an empty container of at least 2 litres capacity under the spouts (A5) (D2) (fig. 9). Press “OK” (B3) to start the procedure. Important! Danger of scalding Hot water containing acid flows out of the spouts. Accordingly, take care to avoid contact with this solution.
- Page 42 Please note: • If the descaling cycle is not completed successfully (e.g., due to a power outage), the machine will prompt for the entire procedure to be repeated. • Water may find its way into the grounds container (A11) during the descale procedure.
-
Page 43: Frequent And Alarm Messages
Frequent and alarm messages Magnifica Evo Next • The water tank (A9) is not in place Can you insert the Reposition the tank in the water tank? machine correctly, and press fully home. • Coffee beans have run out. Fill the bean container (A1) Oops! it looks like and press OK... - Page 44 • Too much pre-ground coffee has been used Press OK (B3), remove the I am unable to complete your drink. drip tray (A7) and the grounds Please reduce the pre-ground container (A11), empty them quantity, empty the grounds both, then return all parts to container and try again the machine and repeat the preparation, reducing the...
- Page 45 • The grounds container (A11) full. Please empty the drip Clean as described in heading tray “Coffee grounds container” and the grounds container • The drip tray (A7) and/or the grounds container are not (A11) Please insert the correctly in place, or missing grounds container and Refit the drip tray complete drip tray...
- Page 46 • Milk carafe (E) not positioned correctly, or missing. Can you insert the Position the milk carafe and LatteCrema Hot push fully home: the machine carafe? emits a beep (if the beep function is enabled). • Every time a milk-based drink has been prepared, the machine Time to clean the asks for the carafe (E) to be...
- Page 47 • The water softener filter (D5) spent. Press “OK” to remove/ (B3) replace the filter, or “ ” (B6) if the intention is to replace it It's time to replace your water filter. later. Follow the instructions in Ready? heading Water filter.
- Page 48 • During the guided procedure on preparation for the start of the Add De'Longhi descaler descale cycle, the quantity of (up to Level A), and descaling solution put into the top up with water (to water tank was not sufficient level B) Prepare the solution as described in heading...
-
Page 49: Faq
Magnifica Evo Next • Coffee not hot (1) It has been 2-3 minutes since the last preparation and the internal circuit of the machine has cooled down: in this situation, a hot rinse is advisable. On the homepage, press to enter the settings menu: Go to the “Maintenance”... - Page 50 • Coffee not hot (3) The temperature set for preparation of the coffee is too low. Select a higher temperature as indicated below: On the homepage, press to enter the settings menu: Go to the “Preferences” section, select the item Coffee temperature and proceed as indicated to select a higher temperature.
- Page 51 • Coffee weak or not creamy enough (1) The coffee is ground too coarsely. Adjust the grind level following the tips given below: on the homepage, press to enter the settings menu: Go to the section containing “Preferences”, select the item and proceed with adjustment of the grinder dial Grinder (A17)
- Page 52 • Coffee delivered too slowly or drop-by-drop The coffee is ground too finely. Adjust the grind level following the tips given below: on the homepage, press to enter the settings menu: Go to the section containing “Preferences”, select the item and proceed with adjustment of the grinder dial Grinder (A17)
- Page 53 • The coffee delivered is watery The funnel is clogged. Clean as described in section ➡ PRE-GROUND COFFEE FUNNEL • Delivery of the drink short of measure The amount of water in the tank is not sufficient. (A9) Always fill the tank at least to the MAX level...
- Page 54 • The brewing unit cannot be removed. (A16) The machine has not been turned off correctly. Switch off by pressing (see Turning the machine off) (B1) • On completion of the descale cycle, the machine calls for a third rinse. During the two rinse cycles, the water tank has not been (A9)
- Page 55 • Milk presents large bubbles, or splashes from the milk spout or is under-frothed (1). (E6) Cow's milk Whole (fat >3,5%) Semi-skimmed (fat between 1.5 and 1.8%) Skimmed (fat <0.5%) Vegetable drinks Soya Almond Oatmeal Use cow’s milk or vegetable drinks at refrigerator temperature (about 5°...
-
Page 56: Technical Data
Technical data Magnifica Evo Next Voltage: 220-240 V~ 50-60 Hz max. 10 A Power: 1450 W Pressure: 1.5 MPa (15 bars) Water tank capacity: 1.9l Size LxDxH: 240x440x360 mm Cord length: 1200 mm Weight: 9.6 kg Bean container capacity: 250 g De’Longhi reserves the right to change the technical specification and styl- ing of its products at any time, while maintaining their functionality and quality unaffected. - Page 57 57132C9063_00_ 0424...
