***Caution: Please read all instructions carefully before starting the assembly process. These parts are cumbersome and heavy. Therefore, two people
are recommended in order to prevent personal injury and insure the parts are not damaged during the assembly.
Code
Table Top
A
Connecting Plate
B
Undertop Table Leg
C
Bottom Table Leg
D
STEP 1
A
Remove Connecting Plate from the Table Top.
This product is manufactured by HMIS for
MADE IN VIETNAM
Assembly Instructions
HMIS 1823-11 Brown Table
HMIS 1825-31 White Pearl Table
PARTS LIST
F
B
Step
Code
Allen Bolt - Ø5/16x18x32mm
1Pc
3
E
Flat washer - Ø5/16x19x1.5mm
1Pc
Allen Key - 4mm
1+3+4
F
1Pc
1Pc
STEP 2
Assemble the two Legs into the X shape like the
description above.
SKU # 42218239
SKU # 42218253
Hardware List
Lock washer - Ø5/16
C
D
6Pcs
6Pcs
6Pcs
1Pc
1 OF 2
