L 2021-40
Information Systems |

General Description

The L 2021-40 charger rack has been specially designed for stationary applications.
It holds up to 40 receivers that will automatically quick-charge to be ready for the
next event. At the same time, the L 2021-40 serves as an ethernet interface to allow
pre-selecting the active channel for each receiver on a central PC. Up to 125 charger
racks with up to 5000 receivers can be connected to the PC. The CC 2021 control
software offers simple presets to select and confirm channels for them all with just
one click. Users and service staff can easily monitor which receivers at which station
have been prepared for any given language or program. Configuration problems are
a thing of the past!

Features

Quick-charge of up to 40 pcs. HDE 2020-D receivers in less than 2,5 hours
j
Copy-function for the quick and easy transmission of the channel configuration
j
Ethernet-port to connect the PC-control software CC 2021
j
Certificate of Compliance according:
j
CAN/CSA 60065-03 incl. AM 1
j
UL Std No. 60065-2006
j
IEC 60065(ed. 7); am 1
j

Product Variants

EU mains cable
j
Mains cable with EU plug, 1.8 m, black
US mains cablel
j
Mains cable with US plug, 1.8 m, black
UK mains cable
j
Mains cable with UK plug, 1.8 m, black
Tourguide 2020-D Stationary
Art.-Nr. 054324
Art.-Nr. 054325
Art.-Nr. 057256

Technical Data

Mains voltage ............................100 – 240 V ( 50 / 60 Hz)
Power consumption ................................................  150 W
Voltage ................................................. 5 V pro Ladeschacht
Power supply ...............................400 mA pro Ladeschacht
Charging time .............................................................  2,5 h
Operating temperature ...................................0°C ... +40°C
Dimensions .......................................... 483 x 399 x 172 mm
Weight ..................................................... 8.800 g (19.43 lbs)
Cat. No. 502037
(19.02" x 15.71" x 6.77")
