- Page 1 L 2015 Instructions for use...
-
Page 2: Safety Instructions
Safety instructions Only use the L 2015 charger for charging the BA 2015 accupack! Never try to charge other rechargeable batteries or non-rechargeable batteries! Keep liquids and small parts away from the unit! Never use the unit in humid environments! -
Page 3: The L 2015 Quick Charger
The L 2015 quick charger The L 2015 quick charger must only be used for automati- cally charging BA 2015 accupacks – individual rechargeable battery cells or primary cells cannot be charged! The BA 2015 accupack is suitable for units of the Sennheiser ew G2 series and the System 2015. -
Page 4: Delivery Includes
! Up to three chargers can be cascaded together to form a larger charging station which can be powered by a com- mon mains unit. Delivery includes ! L 2015 quick charger ! Instructions for use Suitable mains units are available as accessories (see ”Accessories“ on page 29). -
Page 5: Operating Controls
Operating controls » ¿ ´ » ¿ ´ ¶ ³ · ³ · ³ Red LED CHARGE/ERROR (2 x) · Green LED READY (2 x) » Charging compartment for BA 2015 accupack (2 x) ¿ Charging compartment for SK/EK of the ew 300 G2 or ew 500 G2 series and the System 2015 (2 x) ´... -
Page 6: Led Indications
LED indications Each charging compartment has two LEDs which indicate the following operating states: No LED lit: The charging compartment is ready for operation (provided that the charger is connected to the mains), no accupack is identified. All LEDs briefly light The charger has been connected to up one after the the mains and is carrying out a self... -
Page 7: Cascading Several Chargers
Cascading several chargers Make sure that the charger is disconnected from mains. º Unscrew the two screws ¾ at the right bottom side of º the charger. ¶ Slide the two rails out of the guiding slots and screw them tight using the two screws º. -
Page 8: Setting Up The Charger
Setting up the charger The charger has four plastic feet to ensure that it cannot slip on the surface on which it is placed. Attention! Some furniture surfaces have been treated with varnish, polish or synthetics which might cause stains when they come into contact with other synthetics. -
Page 9: Charging The Ba 2015 Accupack
Charging the BA 2015 accupack µ µ Insert the accupack into one of the two charging » » compartments as shown. ³ The red LED at the occu- pied charging compartment lights up. Charging completely discharged accupack takes approx. 2½ hours at room temperature. - Page 10 After the accupack has been fully charged, the green · lights up. Note: For charging, the accupacks can remain in the bodyback transmitter (SK) or receiver ¸ (EK). Place the unit with the accupack inserted into ¸ the charging compartment ¿...
-
Page 11: Care And Maintenance
If problems occur... If a red LED starts flashing, one of the following errors has occurred at the corresponding charging compartment: ! No contact with the accupack (contacts are dirty or accupack is not inserted correctly): Clean the contacts or insert the accupack correctly. ! Accupack is defective (overaged or defective rechargeable battery cells): Replace the accupack. -
Page 12: Specifications
Specifications Input voltage: 12 V DC via hollow jack socket Hollow jack: Input current: max. 750 mA Charging voltage: 2 x 2.9 V Charging current: 2 x 700 mA Charging principle: –∆U method Deep discharge recovery charge Trickle charge Accupack temperature monitoring Over/undercharge detection Charging time limit (max. - Page 13 BA 2015 Accupack for powering units of the Sennheiser ew G2 series and the System 2015 NT 1 Mains unit for powering a single L 2015 charger NT 3 Mains unit for powering up to three cascaded L 2015 chargers...
- Page 14 ENGLISH The guarantee period for this Sennheiser product is 24 months from the date of purchase. Excluded are accessory items, rechargeable or disposable batteries that are delivered with the product; due to their characteristics these products have a shorter service life that is principally dependent on the individual frequency of use.
- Page 15 Konformitätserklärung Sennheiser electronic GmbH & Co. KG erklären, dass dieses Gerät die anwendbaren CE-Normen und Vorschriften erfüllt. Approval Sennheiser electronic GmbH & Co. KG declare that this device is in compliance with the applicable CE standards and regu- lations. Certification Sennheiser electronic GmbH &...
- Page 16 Sennheiser electronic GmbH & Co. KG 30900 Wedemark, Germany Phone +49 (5130) 600 0 Fax +49 (5130) 600 300 www.sennheiser.com Printed in Germany Publ. 01/04 93903/A01...
