Puls PISA11 Series Installation Manual

EN PISA11 Series Installation Manual - CCC-Ex
PISA11 系列 安装手册 - CCC-Ex
CN
Doc. ID: PU-399.025.00-xxA (2024-01-30-MR1)
This is a family installation manual for Hazardous Location applications in
China.
Read this first!
Before operating this device, please read this manual thoroughly and retain this
manual for future reference! This device may only be installed and put into operation
by qualified personnel. If damage or malfunction should occur during operation,
immediately turn power off and send device to the factory for inspection. The device
does not contain serviceable parts. The information presented in this document is
believed to be accurate and reliable and may change without notice. For any
clarifications the English translation will be used.
Risk of electrical shock, fire, personal injury, or death:
Turn power off before working on the device. Protect against inadvertent re-
-
powering.
- Do not open, modify or repair the device.
- Use caution to prevent any foreign objects from entering the housing.
- Do not use in wet locations or in areas where moisture or condensation can be
expected.
- Do not touch during power-on and immediately after power-off. Hot surfaces may
cause burns.
Product Description
The PISA11* module has one 24V input and four output channels to which the
current is distributed. Each output channel is equipped with a redundant over-current
protection, which avoids that wires will be overloaded.
Intended Use
This device is designed for installation in an enclosure and is intended for the general
use such as in industrial control, office, communication, and instrument equipment.
Do not use this protection module in equipment, where malfunction may cause
severe personal injury or threaten human life.
This device is designed for use in hazardous, non-hazardous, ordinary or unclassified
locations.
List of Covered Models and Ratings:
PISA11.401 Input: DC 24V; 4,0 A
Output Channel 1-4: DC 24V; 1,0 A
Temperature range: -25° C to +70° C
Ex protection level:
PISA11.402 Input: DC 24V; 8,0A
Output Channel 1-4: DC 24V; 2,0 A
Temperature range: -25° C to +70° C
Ex protection level:
PISA11.403 Input: DC 24V; 12,0A
Output Channel 1-4: DC 24V; 3,0 A
Temperature range: -25° C to +70° C
Ex protection level: Ex ec nC IIC T4 Gc
PISA11.CLASS2 Input: DC 24V; 15,0A
Output Channel 1-4: DC 24V; 3,7 A
Temperature range: -25° C to +70° C
Ex protection level: Ex ec nC IIC T3 Gc
Input: DC 24V; 16,0A
PISA11.404
Output Channel 1-4: DC 24V; 4,0 A
Temperature range: -25° C to +60° C
Ex protection level: Ex ec nC IIC T4 Gc
Input: DC 24V; 20,0A
PISA11.406
Output Channel 1-4: DC 24V; 6,0 A
Temperature range: -25° C to +60° C
Ex protection level: Ex ec nC IIC T4 Gc
Input: DC 24V; 20,0A
PISA11.410
Output Channel 1-4: DC 24V; 10,0 A
Temperature range: -25° C to +60° C
Ex protection level: Ex ec nC IIC T3 Gc
Input: DC 24V; 18,0A
PISA11.203206
Output Channel 1-2: DC 24V; 3,0 A
Output Channel 3-4: DC 24V; 6,0 A
Temperature range: -25° C to +60° C
Ex protection level: Ex ec nC IIC T3 Gc
Electronic Fuse Module
电子保险丝模块
English
T4
Ex ec nC IIC Gc
Ex ec nC IIC T4 Gc
普尔世电源产品（苏州）有限公司 苏州工业园区兴浦路瑞恩巷 1 号 215021
The information in this document is believed to be accurate and reliable and may change without notice
本文件中的信息被认为是准确和可靠的，并可能未经通知而发生变化
这是一份适用于中国危险场所应用的安装手册。
安装要求！
在操作本产品之前，请仔细阅读本手册，并保留本手册以供将来参考！
本产品只能由有相关资质的人员安装和操作。
如果安装或运行过程中发生损坏或故障，立即关断电源，并将产品返回厂商检查。
本产品不包含需要维护的零件。
本文档中提供的信息准确、可靠；如有修改，恕不另行通知。
本文档翻译自英文版本，中英文版本之间如有差异，应以英文版为准。
- 在设备上执行作业前，先关断电源。提供保护，以免设备意外重新通电。
- 由于产品内部有高压，请勿自行打开或维护本产品。
- 谨防任何异物进入壳体。
- 切勿在潮湿地点或可能会出现湿气或冷凝区域使用该产品。
- 电源在运行期间及刚断电时，切勿触碰。灼热的表面可能会造成烫伤。
产品介绍
PISA11 系列是一款单路 24V 直流输入和四路受控电流输出的电子断路器。各通道均内置解耦
的过流保护装置预防通道过载。
预期用途
本装置设计安装在机箱内，广泛应用于工业控制，楼宇自动化，通信和仪器设备领域。
请勿将本装置用于发生故障可能导致严重人身伤害或威胁人类生命的设备中。
本装置涉及用于危险性区域，非危险性区域，普通或未分类的区域。
涵盖的型号和额定规格:
输入: DC 24V; 4,0 A
PISA11.401
1-4 通道输出: DC 24V; 1,0 A
温度范围: -25° C to +70° C
防爆等级:
Ex ec nC IIC
输入: DC 24V; 8,0A
PISA11.402
1-4 通道输出: DC 24V; 2,0 A
温度范围: -25° C to +70° C
防爆等级:
Ex ec nC IIC T4 Gc
输入: DC 24V; 12,0A
PISA11.403
1-4 通道输出: DC 24V; 3,0 A
温度范围: -25° C to +70° C
防爆等级: Ex ec nC IIC T4 Gc
输入: DC 24V; 15,0A
PISA11.CLASS2
1-4 通道输出: DC 24V; 3,7 A
温度范围: -25° C to +70° C
防爆等级: Ex ec nC IIC T3 Gc
输入: DC 24V; 16,0A
PISA11.404
1-4 通道输出: DC 24V; 4,0 A
温度范围: -25° C to +60° C
防爆等级: Ex ec nC IIC T4 Gc
输入: DC 24V; 20,0A
PISA11.406
1-4 通道输出: DC 24V; 6,0 A
温度范围: -25° C to +60° C
防爆等级: Ex ec nC IIC T4 Gc
输入: DC 24V; 20,0A
PISA11.410
1-4 通道输出: DC 24V; 10,0 A
温度范围: -25° C to +60° C
防爆等级: Ex ec nC IIC T3 Gc
触电、火灾、人身伤害或死亡危险。
T4 Gc
中文
