- Page 1 OWNER’S MANUAL ST200 SIGNATURE STREAMER...
-
Page 2: Safety Instructions
Feel free to take advice from your specialist dealer. YOU WILL FIND ENCLOSED – An ST200 Signature streamer. – Two antennas. – A power lead. – This manual with the warranty – A RCA cord. certificate. – A remote control. Page 2 ATOLL ELECTRONIQUE... -
Page 3: General Information
Output level: 2,6 Vrms Signal/Noise ratio: 129 dB Distortion at 1 kHz: 0,0004% Bandwidth: 5 Hz - 20 kHz Rising time: 1,5 µs Digital/analogue converter: Burr-Brown PCM1792 24 bits/192 kHz Dimensions: 440×284×95 mm Weight: 6 Kg Page 3 ATOLL ELECTRONIQUE... - Page 4 You will find the antennas in the bag of the remote control. Make sure that the WIFI and Bluetooth® antennas are correctly installed before any connection and use. Please use the 2 supplied antennas (identical) or an antenna with male connector. Page 4 ATOLL ELECTRONIQUE...
-
Page 5: Remote Control Functions
38) Input selection keys: Coaxial 1, Coaxial 2, Optical 1, Optical 2. 39) FAVORITE: add (ADD) or remove (REM) from a radio station. 40) CD keys: keys to control CD and Drive Atoll players. 41) IN/PR keys: keys allowing you to control the Atoll integrateds and preamps. Page 5 ATOLL ELECTRONIQUE... -
Page 6: Connecting Setup
Trigger cable must be a stereo Male to Male jack plug Ø 3,5 mm (1/8”). Therefore, each time the Streamer comes out of standby, the amplifier will switch on. It will also turn off each time it is put on standby. Page 6 ATOLL ELECTRONIQUE... -
Page 7: Getting Started
– Deezer. – Settings. – Amazon Music Connecting an RJ45 cable automatically launched the network link. If this is done correctly ( blinking), your network is correctly configured. The following paragraph is optional in your case. Page 7 ATOLL ELECTRONIQUE... -
Page 8: Network Configuration
This menu allows you to rename the auxiliary inputs, to allow the user to identify their different inputs. It also allows you to check/uncheck the entry of your choice so that it is displayed/hidden in the main menu of the navigation bar. Page 8 ATOLL ELECTRONIQUE... -
Page 9: Power Management
These applications undergo regular updates, their operation and their possibilities are therefore likely to evolve over time. N.B: Note that the old ATOLL Signature application is still available for download. Page 9 ATOLL ELECTRONIQUE... -
Page 10: Internet Radio
Popular podcasts / Trends / Filters. FRONT & REAR USB Select one of those inputs to read all music files from a USB key or Hard Disk. Readable files system can be FAT32, NTFS, EXT 2/3/4. Page 10 ATOLL ELECTRONIQUE... -
Page 11: Media Server
The signal reception quality may depend on the power of the Bluetooth® transmitter on your device and the distance between the two devices. To ensure correct reception without interruption, avoid being more than 5 meters away from your device. Page 11 ATOLL ELECTRONIQUE... -
Page 12: Troubleshooting Table
– Turn off the power switch level before restarting. WARRANTY FORM ~ ST200 Sig to present to your dealer and to join with your purchase invoice when sending back the appliance to the service center or the address below: ATOLL ELECTRONIQUE® Bd des Merisiers 50370 BRECEY FRANCE WARRANTY CONDITIONS This device was made to give you complete satisfaction.
