- Page 1 ’ WNER ANUAL STREAMER ST200 Signature...
- Page 2 You have just bought a product with exceptional audiophile performances. We really thank you for your confidence in our products. To get the best part of your streamer, please read carefully this manual. INDEX : • Index, cautions & advises ................p2 •...
-
Page 3: General Informations
1 - GENERAL INFORMATIONS GÉNÉRAL INFORMATIONS AND DVISES Your ATOLL Streamer is DLNA and UPnP compatible, it can run in a network with other devices. Take the time to read carefully the section « getting started » of this manual (page 7) before putting your unit under voltage. - Page 4 ONNECTING Rear view of Appliance: 8 9 10 1- Analog stereo Output 9- Trigger Output 2- Input Analog 1 10- Coaxial 2 Input 3- Input analog 2 11- Ethernet Input (RJ45) 4- Optical Output 12- USB Input (A type) 5- Coaxial Output 13- Power input 6- Optical 1 Input 14- On/Off switch...
-
Page 5: Remote Control
REMOTE CONTROL: The remote control uses 2 lithium CR2032 (3V) batteries. Make sure to place + upside. Warning : some keys may have different uses depending of the menus or context. Keys already available from the front panel : 17- Menus control keys 21- Volume control + &... - Page 6 2 - CONNECTINGS SETUP SOURCE MODE PREAMPLIFIER (B This device can be use as a source (like a CD player) or as a preamplifier which gives ability to control the volume. Schemes below shows how to connect correctly depending of your choice. ST200 Signature Source Preamp...
- Page 7 3 - USES Starting: Before switching On your appliance, connect the network cable (RJ45) to switch (10). For much better results and best performances, we highly recommend to uses a wired connection better than a Wifi connection. While started, wait for display switch on. You can use the buttons of navigation (17) of the remote control or the front panel to select the different menus.
- Page 8 2/ WIRELESS In this case, your appliance will be able to find the Wireless connections available in your home. Advise: We advises to use the WPS button to connect your appliance to your Wifi network. Press on the WPS button of your internet receiver and then on WPS button of the remote control (30). Display shows «...
-
Page 9: Internet Radio
II – PLAYLISTS: This devices allows to create Playlists with all music tracks or albums that are available in your network. Note that it is not possible to add tracks from Streaming services in those Playlists. You have 3 different menus available: PlayQueue: The PlayQueue is a temporary playlist where you can place all tracks one after the other. -
Page 10: Media Server
V – MEDIA SERVER: This menu allows to get access to all the music files on your network. While entering this menu, you’ll find all different sources available in the network (could be NAS, computer, router…). While selecting them, you’ll have the choice of: Musique / photo / video. Only music files can be read on this device. - Page 11 4 - PREAMP / BY-PASS FUNCTIONS: Your appliance can be use as a preamplifier allowing to manage the volume control and selection of the different sources. It can also be use as a single source (By-pass led switch on). Connect: as a preamplifier the streamer can be directly connected to a power amplifier. In that case, ensure you to never turn your device on BY-PASS mode.
- Page 12 Dealer’s Stamp Buying Date: Address: Buyer’s Signature: ATOLL Electronique is a French brand that designs manufactures and markets all its products. ®...
