Installation Checklist
WARNING
Installer must be suitably qualified and ensure compliance with all codes and standards
!
including AS/NZS3500.1.
Unpack
• Unpack the machine, check for damage and complete delivery.
Positioning
• Place machine on sound waterproof self draining floor and adjust feet to level
• Allow room for adjacent chemical containers
Water
• Flush supply lines before connection
• Connect hose supplied to adjacent accessible isolator valve - 20 mm 3/4 male
• Flow rate required - 15 litres per minute
• Temperature - Less than 20˚C
• Consumption per cycle - 2.6 litres
• Pressure required - 200-350 kPa - fit limiter above this pressure
Atmospheric Vacuum Breaker
• Back Flow -
• Potable water quality is required - filter or soften if necessary
Power
• Three phase 15 A per phase 415V 50Hz
Waste
• Connect drain pump hose supplied to vented upstand or sink waste connection
Detergent
• Insert hose into container of commercial dishwasher low foam detergent
• Adjust detergent dosing and prime detergent using the keypad (refer to page 7)
• Use good quality chemicals and regularly check containers
Rinse Fluid
• Insert hose into container of commercial dishwasher rinse fluid
• Adjust rinse fluid dosing and prime rinse aid using the keypad (refer to page 7)
• Use good quality chemicals and regularly check containers
Operation
• Run several cycles, ensure that operator has read and understands instructions
Troubleshooting Installation
• If machine doesn't fill after switching on power, check & ensure that hot water supply tap is
open, water supply pressure is not below specification and DCV is correctly installed as per
arrow on DCV body
