- Page 1 2.5” SSD to Dual M.2 RAID Module Customer: Customer Part Number: Innodisk Part Number: Innodisk Model Name: Date: Innodisk Customer Approver Approver...
-
Page 2: Table Of Contents
E2SS-32R2 Table of Contents ......................ABLE OF ONTENTS ......................EVISION ISTORY ........................ 1 IST OF ABLES ......................2 IST OF IGURES ....................3 RODUCT NTRODUCTION 1.1. O ......................3 VERVIEW 1.2. F ....................... 3 EATURES ..................... 4 RODUCT PECIFICATIONS 2.1. D .................... -
Page 3: Revision History
E2SS-32R2 EVISION ISTORY Revision Description Date First Released Aug, 2023... -
Page 4: List Of Tables
E2SS-32R2 List of Tables 1: D .................... 4 ABLE EVICE PARAMETERS 2: P ................... 4 ABLE OWER EQUIREMENT 3: P ..................4 ABLE OWER ONSUMPTION 4: T ..................4 ABLE EMPERATURE ANGES 5: S ..................5 ABLE HOCK AND IBRATION 6: M (MTBF) .............. -
Page 5: List Of Figures
E2SS-32R2 List of Figures 1: B ....................3 IGURE LOCK IAGRAM 2: E2SS-32R2 P ..................3 IGURE ICTURE 3: 7+15P SATA ..............9 IGURE CONNECTOR DRAWING 4: P 2*5P ................10 IGURE EADER DRAWING SMD 2*26P ................11 IGURE DRAWING... -
Page 6: Product Introduction
Product Introduction 1.1. Overview Innodisk E2SS-32R2 is designed with standard 2.5” form factor, E2SS-32R2 is compatible with SATAIII(6.0Gb/s) specification, E2SS-32R2 can be configured as 2 ports SATA Hardware striping & mirror & port multiplier functions, optimized for higher performance and ensure data integrity, which brings you a flexible expansion solution for embedded systems. -
Page 7: Product Specifications
E2SS-32R2 Product Specifications 2.1. Device parameters Table 1: Device parameters Form Factor 2.5” Input I/F SATA III Output I/F SATA III Output M.2 B-Key 2242/2260/2280 x 2 Connector Dimension 69.85 x 100 x 9.5mm (WxLxH) 2.2. Electrical Specifications 2.2.1. Power Requirement... -
Page 8: Shock And Vibration
Ground Benign, Controlled environment, 50% operation stress 2.4. CE and FCC Compatibility E2SS-32R2 conforms to CE and FCC requirements. 2.5. RoHS Compliance E2SS-32R2 is fully compliant with RoHS directive. R e v 1 . 0 T P S , A u g 2 0 2 3... -
Page 9: Hardware
E2SS-32R2 2.6. Hardware 2.6.1. Layout J6 J5 CON2 CON1 J2 J1 Table 7: PCB Layout Legend Label Connector Type Function J1 J2 Slide Switch SMD 3P 90° RAID Level setting USB 2.0 Input I/F DIP 2*5P 90° P:1.27mm LED access & error function 7+15P 90°... -
Page 10: Pin Define
E2SS-32R2 2.6.2. Pin Define Table 8: mSATA Pin Define (CON1 CON2) Signal Name Pin # Pin # Signal Name +3.3V +3.3V +3.3V +3.3V +3.3V R e v 1 . 0 T P S , A u g 2 0 2 3... - Page 11 E2SS-32R2 Table 9: 7+15 SATA Pin Define (J6) Pin # Signal Name Description Differential Signal Pair Differential Signal Pair 5V Power, Pre-Charge 5V Power 5V Power Device Activity Signal / DAS/DSS Disable Staggered R e v 1 . 0 T P S , A u g 2 0 2 3...
-
Page 12: I/O Connector Mechanical Drawing
E2SS-32R2 Table 10: USB 2.0 & LED Pin Define (J5) Pin # Signal Name (USB 2.0) Signal Name (LED) CON2 Error CON2 Access CON1 Error CON1 Access 2.6.3. I/O Connector Mechanical Drawing Figure 3: 7+15P SATA connector drawing R e v 1 . 0... -
Page 13: Figure 4: Pin Header 2*5P Drawing
E2SS-32R2 Figure 4: Pin Header 2*5P drawing R e v 1 . 0 T P S , A u g 2 0 2 3... - Page 14 E2SS-32R2 Figure 5: M.2 SMD 2*67P drawing R e v 1 . 0 T P S , A u g 2 0 2 3...
-
Page 15: Figure 6: Switch Smd 3P Drawing
E2SS-32R2 Figure 6: Switch SMD 3P drawing R e v 1 . 0 T P S , A u g 2 0 2 3... -
Page 16: E2Ss-32R1 Mechanical Drawing
E2SS-32R2 2.6.4. E2SS-32R2 Mechanical drawing Figure 7: E2SS-32R2 drawing R e v 1 . 0 T P S , A u g 2 0 2 3... -
Page 17: Raid Level Setting
Blue RAID Error Green + Blue RAID Rebuilding 2.7 Packing List E2SS-32R2 2.5” Card x 1 Screw M2*3.5 Silver x 6 Screw M2*2.5 Black x 4 2.5” SSD Bottom cover x 1 2.5” SSD Top cover x 1 2.8 Software Support Use native AHCI driver for setting. -
Page 18: Quick Installation Guide
E2SS-32R2 Quick Installation Guide To install the M.2 storage, the following steps are required. Check the component for button cover, top cover, E2SS-32R2, screws. Check the screws for each part. R e v 1 . 0 T P S , A u g 2 0 2 3... - Page 19 E2SS-32R2 Use the flat screws to fix the M.2 SSD on the RAID module(E2SS-32R2). Use the screws for to fix the RAID module(E2SS-32R2) on the button cover. R e v 1 . 0 T P S , A u g 2 0 2 3...
- Page 20 E2SS-32R2 Screw the top cover to the button cover. R e v 1 . 0 T P S , A u g 2 0 2 3...
-
Page 21: E2Ss Rebuild Disk Sop
E2SS-32R2 E2SS Rebuild Disk SOP The SOP is to instruct how to rebuild Disk of E2SS. 1. Prepare a new Disk with the same capacity. 2. Backup the Disk data. 3. If one of the Disk is damaged during RAID 1 mode, the RAID [Status] will be [Degraded], and then use iRAID Tool to confirm which Disk is damage. - Page 22 E2SS-32R2 5. Take the following picture as an example, replace the broken Disk with a new one. The left side is Disk 2 (PCB print is CON2), so remove the CON2 Disk and install a new Disk to CON2. 6. Install the new Disk into CON2.
- Page 23 E2SS-32R2 7. Power on. 8. The system will automatically execute “Rebuild” process at this time, and you can see the [Status] is [Rebuilding] via iRAID Tool. (And there is no need to press any buttons.) R e v 1 . 0...
- Page 24 E2SS-32R2 9. Finally, it’s completed. The [Status] will show [Normal]. R e v 1 . 0 T P S , A u g 2 0 2 3...
- Page 25 E2SS-32R2 R e v 1 . 0 T P S , A u g 2 0 2 3...
- Page 26 E2SS-32R2 R e v 1 . 0 T P S , A u g 2 0 2 3...
- Page 27 E2SS-32R2 R e v 1 . 0 T P S , A u g 2 0 2 3...
- Page 28 E2SS-32R2 R e v 1 . 0 T P S , A u g 2 0 2 3...
-
Page 29: Contact Us
+81-3-6667-0161 China sales_cn@innodisk.com +86-755-2167-3689 www.innodisk.com © 2018 Innodisk Corporation. All right reserved. Specifications are subject to change without prior notice. September 1, 2023 R e v 1 . 0 T P S , A u g 2 0 2 3...
