Technical Specifications
Power Rating
Amplifier Power
Audio Performance
Frequency Response
THD+N
Channel Separation
(Crosstalk)
Dynamic Range
Integrated DSP
A/D and D/A Converters
Processing Functions
Loudspeaker Presets
Audio Latency
Audio Inputs
Input Channels
Connectors
Input Range
Adjustment Range (RCA)
Adjustment Range
(Euroblock)
Input Impedance
Maximum Input Level
Sensitivity
Audio Outputs
Outputs
Connectors
Indicators and Controls
Power LED
Input Signal LED
Output Limit LED
Controls, Front Panel
Controls, Rear Panel
Electrical
Mains Voltage
AC Power Consumption
Mains Connector
Maximum Inrush Current
Overload Protection
Physical
Dimensions
Shipping Weight
Net Weight
Cooling System
General
Inputs (Control)

SPECIFICATIONS

PS602
2 x 300 W @ 4-8 Ω, 70/100 V
4-8 Ω: 20 Hz – 20 kHz (+0/–1 dB, @ 1 W 4 Ω); 70/100 V: 50 Hz - 20 kHz (+0.5/-0.5 dB, @ 1 W)
≤ 0.1 % (1 kHz, at rated full power, 8Ω);
>75 dB @ 1 kHz, >55 dB @ 20 kHz
98 dB, 4 Ω
24-bit / 48 kHz
Standard mixer, loudspeaker EQ, room EQ, Vpeak/Vrms limiters, delay, crossover, phase inversion (per channel)
DS 16, DS 40, DS 100, FS3B, Panaray® 402 and 802 Series IV, MA12X, RoomMatch® Utility RMU105, Flat
14 ms (any input to speaker output)
PS602
2 unbalanced, 2 balanced
Stereo RCA, 3-pin Euroblock
4 to 20 dBu (Euroblock);
-10 to 6 dBV (RCA)
-10 to -2 dBV, -2 to 6 dBV (RCA)
4 to 12 dBu, 12 to 20 dBu
10 kΩ (RCA), 20 kΩ (Euroblock, XLR)
6 dBV / 8.2 dBu (RCA); 20 dBu (Euroblock)
-10 dBV / -7.8 dBu (RCA), 4 dBu (Euroblock)
PS602
2
2-pin inverted Euroblock
Solid green indicates power is on. Blinking green indicates standby mode. Solid amber indicates an over-
temperature fault. Solid red indicates a power supply fault.
See Front and Rear Panel section for each amplifier for details.
See Front and Rear Panel section for each amplifier for details.
Amplifier mode DIP switches, loudspeaker EQ dials, output trims (PS602 and PS604 only)
100 VAC – 240 VAC (±10%, 50/60 Hz)
120 VAC: 79 W (Standby), 324 W (Max)
Standard IEC (C14)
PS602: 12.33 A (230 VAC / 50 Hz), 8.27 A (120 VAC / 60 Hz)
PS602P: 14.14 A (230 VAC / 50 Hz), 8.04 A (120 VAC / 60 Hz)
PS604: 11.79 A (230 VAC / 50 Hz), 11.72 A (120 VAC / 60 Hz)
High temperature, output short, excessively low or high AC line voltage
44 mm H x 483 mm W x 414 mm D (1.7" H x 19.0" W x 16.3" D)
PS602 and PS602P: 6.9 kg (15.3 lb); PS604: 7.8 kg (17.2 lb)
PS602 and PS602P: 5.5 kg (12.2 lb); PS604: 6.4 kg (14.1 lb)
Variable speed fans create continuous left-to-right air flow
RJ-45 remote input for volume control using the CC-1 ControlCenter Zone Controllers (PS602 and PS604 only),
or for connection to the CV41. USB input for configuring the amplifier with PowerShare Editor Software. Mute
input control via a normally open contact closure
PS602P
2 x 300 W @ 4-8 Ω, 70/100 V
≤ 0.5% (1 kHz, at rated full power, 70/100 V)
PS602P
2 unbalanced, 2 balanced
Stereo RCA, XLR with 1/4" combo
4 to 20 dBu (Euroblock);
-10 to 6 dBV (RCA)
-10 to -2 dBV, -2 to 6 dBV (RCA)
4 to 12 dBu, 12 to 20 dBu
PS602P
2
NL4 & binding posts
230 VAC: 88 W (Standby), 384 W (Max)
13
PS604
4 x 150 W @ 4-8 Ω, 70/100 V
PS604
4 balanced
3-pin Euroblock
4 to 20 dBu (Euroblock)
N/A
4 to 12 dBu, 12 to 20 dBu
PS604
4
2-pin inverted Euroblock
