Page 1: Power Amplifier
M O D E L PackLite POWER AMPLIFIER... -
Page 2: Important Safety Instructions
Svenska Nederlands Italiano Français Español Deutsch Dansk English Important Safety Instructions Read these instructions. 13. Unplug this apparatus during lightning storms or when Keep these instructions. unused for long periods of Heed all warnings. time. Follow all instructions. 14. Refer all servicing to qualified Do not use this apparatus service personnel. -
Page 3: Safety Information
This product conforms to the EMC Directive 89/336/EEC and to the Low Voltage Directive 73/23/EEC. The complete Declaration of Conformity can be found on www.bose.com The product must be used indoors. It is neither designed nor tested Note: for use outdoors, in recreation vehicles, or on boats. - Page 4 English OWER MPLIFIER ODEL Introduction Thank you for purchasing the PackLite power amplifier Model A1 and joining the many thousands of musicians worldwide using the Personalized Amplification System™ family of products. This small, lightweight, powerful, and easy-to-use amplifier inter- faces quickly with the Bose ®...
- Page 5 For convenience, please record the serial number and date of purchase on page 3. Check that the shipping carton contains the items shown in Figure 1. Figure 1 Carton contents PackLite power amplifier Model A1 Carrying pouch AC power cord* ¼" TRS (balanced) cable Owner’s guide...
-
Page 6: The Connector Panel
Svenska Nederlands Italiano Français Español Deutsch Dansk English OWER MPLIFIER ODEL The connector panel The A1 connector panel includes the features described in Figure 2. Figure 2 A1 connector panel AC power connector: Accommodates the supplied AC power cord to connect your amplifier to the appropriate AC (mains) outlet. -
Page 7: Top Panel Indicators
English Dansk Deutsch Español Français Italiano Nederlands Svenska OWER MPLIFIER ODEL Top panel indicators The top panel of the A1 has two indicators that tell you the state of the amplifier. Figure 3 A1 top panel Power indicator: Signal indicator: BLUE when amplifier GREEN when a signal is present at the is on and ready to... - Page 8 Svenska Nederlands Italiano Français Español Deutsch Dansk English OWER MPLIFIER ODEL Figure 4 Typical setup INPUT OUTPUT Bass-Line A1 amplifier B1 bass modules PS1 power stand B1 bass modules Do not connect more than two B1 bass modules to an CAUTION: A1 amplifier.
- Page 9 English Dansk Deutsch Español Français Italiano Nederlands Svenska OWER MPLIFIER ODEL Using another ¼" TRS cable, connect the THRU connector on the first A1 amplifier to the INPUT connector of the next A1 amplifier. Connect a B1 bass module to the OUTPUT connector on each A1 amplifier.
- Page 10 Svenska Nederlands Italiano Français Español Deutsch Dansk English OWER MPLIFIER ODEL Using the A1 in other applications The A1 amplifier can be used as a power amplifier in other system configurations. The A1 can drive other passive loudspeakers including subwoofers, floor monitors, studio monitors, and guitar cabinets.
-
Page 11: Troubleshooting
English Dansk Deutsch Español Français Italiano Nederlands Svenska OWER MPLIFIER ODEL Troubleshooting Problem What to do Power LED is not • Be sure power switch is ON. lit; the amplifier • Make sure the power cord is fully inserted into the unit and does not seem to an AC outlet. -
Page 12: Customer Service
877-335-2673 or visit the support area online at www.bose.com/musicians • Visit the Bose website of your country or call the corresponding support number as listed below. If your country is not listed here, please inquire with the dealer where you bought the product. -
Page 13: Specifications
English Dansk Deutsch Español Français Italiano Nederlands Svenska OWER MPLIFIER ODEL Specifications Electrical Power, 4-ohm load ... . . 250 watts RMS (1 kHz, 0.1% THD) Power, 8-ohm load ... . . 125 watts RMS (1 kHz, 0.1% THD) Minimum loudspeaker load . - Page 14 English Cropped 10-24-05, KS...
