CDMA 800/1900 MHz
BS Test
Software Option 897 804
Operating Instructions
(61_CDMA) Doc. Version: 9811-210-A
10
Acterna Muenchen GmbH, Gutenbergstr. 2 – 4, D-85737 Ismaning
¤
+49 (89) 9 96 41-0
Fax: +49 (89) 9 96 41-160
