Chapter 1 Getting started
Overview of features
Overview of features
Status LEDs
2
When attached to the HST-3000 base unit, the DDS Local
Loop (DDS-LL) SIM lets you perform physical layer test oper-
ations necessary for provisioning transmission circuits. The
DDS-LL test option includes the following features:
– BER testing on all supported rates, including end-to-end
(straightaway) testing or loopback testing using another
test device at the far end.
– Channel service unit/data service unit (CSU/DSU) emula-
tion.
– A single 8-pin, RJ-48 DDS-LL interface connector. For pin
assignments, see
– Copper testing. See the HST-3000 Copper Testing User's
Guide.
– Frame Relay testing (optional). See the HST-3000 Frame
Relay Testing User's Guide.
Six status LEDs are located on the front of the HST-3000,
above the LCD screen.
Table 6
Status LEDs
LED
Description
Sync
A two-color LED that reports the signal status.
– Green indicates a signal is present and there is
frame synchronization.
– Red indicates that at least one of the channels
does not have signal or frame synchronization.
– If the Sync LED is not illuminated, no signal has
been detected.
HST-3000 DDS Local Loop Testing User's Guide
Table 7 on page
Table 6
describes the LEDs.
