Acterna MTSe 5000 Series User Manual

page of 219

/ 219
Bookmarks

Quick Links

Download this manual

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

SER

ANUAL

MTS

5000 Series

Manual reference:

5000M02

750000992/16

Software:

Versions 4.xx

Print ed:

December 2001

 2001 Acterna

The information contained in this document is the

property of Acterna. It is only provided for the operation

and maintenance of the instrument. It must not be

duplicated without the prior written permission of

Acterna.

Acterna Saint-Etienne

34 rue Necker

42000 Saint-Etienne

Tel. +33 (0) 4 77 47 89 00

Fax +33 (0) 4 77 47 89 70

Web

www.acterna.com

Need help?

Do you have a question about the MTSe 5000 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Acterna MTSe 5000 Series

Page 1 December 2001  2001 Acterna The information contained in this document is the property of Acterna. It is only provided for the operation and maintenance of the instrument. It must not be duplicated without the prior written permission of Acterna.
Page 2 Notice The information contained in this manual is subject to change without notice. Acterna shall not be liable for errors contained herein or for incidental or consequential damages resulting from the use of this material. This document must not be photocopied, reproduced, or translated into another language without the written consent of Acterna.
Page 3 Laser classes applicable to the MTS modules: Reference standard Modules EN 60825-1 :1994 FDA21CFR§1040.10 Multimode MM and ML - at 1300 nm Class 1 Class 1 - at 850 nm Class 3A Class 1 Singlemode SR, DR Class 1 Class 1 Singlemode HD µs - at 1310 nm, 20...
Page 4 Optical connector The optical connector is the access point to the laser beam (see figure below). Laser emission Example of a laser connector on the MTS 5100 rear panel The user must take the necessary precautions concerning the optical output of the instrument and follow the manufacturers instructions.
Page 5 Table of contents Visual Conventions .................... ii Laser safety ......................ii AC/DC and battery safety ................iv Measurement Principles ..............1-1 OTDR measurements principle ............1-1 Measurement result ..................1-1 Measurement validity ..................1-2 Reflectance ......................1-2 OTS Measurement principles ..............1-3 Attenuation measurement ................1-3 Power measurement ..................1-4 WDM principle and analysis ..............
Page 6 Switching on/off the MTS ..............3-8 After switching on ................3-9 Installing a new version of the software ............3-9 Instrument Set up ..................3-11 System setup ....................3-12 Help ....................3-18 Printing ...................3-18 Copying to the internal printer ..............3-18 Loading a new roll of paper .................3-26 Coping to an external printer ...............3-26 Copying to a file on a floppy disk ...............3-27 Visual fault locator function .............3-27...
Page 7 Selecting fiber parameters ................5-5 Acquisition ..................5-6 Real-time mode ....................5-7 Automatic acquisition mode ................. 5-9 Manual acquisition mode ................5-11 Case of the multi-wavelength acquisition ..........5-13 Detection of traffic ..................5-13 Result analysis ................5-14 Using the cursors ................... 5-14 Zoom and shift functions ..............
Page 8 Using the OTS module ................ 6-1 OTS Test SET-UP ................6-1 Selecting Light source parameters ..............6-2 Selecting Power meter parameters ..............6-3 OTS Results Window ................. 6-4 Light Source ......................6-5 Power meter .....................6-8 OTS Measurements ................. 6-11 Adjusting the power meter zero setting .............6-11 Making a reference measurement ...............6-11 Measuring the fiber under test ..............6-12 Source Specific Functions ..............6-12...
Page 9 File management ................8-1 Storage media ...................8-1 Selecting the storage location ................ 8-1 Storing data ..................8-2 Filename ..................8-2 Different file naming ..................8-2 OTDR Module Automatic Filenaming ............8-3 OTDR Module Semi-Automatic Filenaming ..........8-4 OTS Module Automatic Filenaming ............8-7 OTS Module Semi- Automatic Filenaming ..........
Page 10 Linking commands ..................9-4 Parameters ......................9-4 Queries ......................9-4 Common part commands ..............9-5 SRQ commands (IEEE interface only) ............9-5 Status structure Registers ................9-6 Status commands .....................9-7 System setup commands ................9-7 Commands relative to the module and the function .........9-8 Commands relative to the keys ..............9-8 Identification commands for a previous measurement ......9-9 Next measurement identification commands ...........9-10 Remarks in table ....................9-10...
Page 11 Technical specifications ..............11-1 Mainframe specifications ..............11-1 Display ......................11-1 Storage ......................11-1 Input/Output ....................11-2 Internal printer (optional for MTS 5200 only) ......... 11-2 Power supply ....................11-2 Environmental conditions ................11-3 OTDR Measurement characteristics ..........11-4 OTS measurement characteristics ............ 11-5 Modules, Options and Accessories ...........
Page 12 750000992/16 ANUAL Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Page 13 Chapter Measurement Principles This chapter give the principle of measurement : ❏ for OTDR modules ❏ for OTS modules ❏ for the WDM modules OTDR measurements principle Optical time domain reflectometry consists of injecting a light pulse down the optical fiber to be analyzed and observing, at the point of injection, the intensity of the light reflected back in the opposite direction to the pulse propagation.
Page 14 Measurement Principles The measurement result should provide: • the attenuation • the location of faults in terms of distance from defined point • the attenuation versus distance (dB/km) • the reflectance of an event or an optical link In so far as location is concerned, it should be noted that an OTDR is Attention a time domain machine (Optical Time Domain Reflectometer).
Page 15 OTS Measurement principles • the backscattering coefficient of the fiber used. Typical values of backscattering coefficient for a 1ns pulse for a singlemode fiber - 79 dB at 1310 nm - 81 dB at 1550 nm and 1625 nm for a multimode fiber - 70 dB at 850 nm - 75 dB at 1300 nm In order to measure the largest range of reflection coefficient, a variable optical...
Page 16 Measurement Principles 2. The power P2 at the output of the fiber section of two meters is measured and serves as the reference. The attenuation of the fiber tested is: P1 - P2. This method is very accurate but is little used due to its destructive nature. It cannot be used during maintenance or installation but only during the manufacture of the fiber.
Page 17 WDM principle and analysis With this new technology, new measurements are required. During installation and maintenance of WDM systems, it is important to verify the following parameters: 1. Presence of all channels at corresponding wavelengths, without any drift. 2. Right channel power levels, without any power variation 3.
Page 18 Measurement Principles 750000992/16 ANUAL Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Page 19 Chapter Introduction The Acterna 5000 series Media Test Set is a fully modular portable platform designed for the construction, commissioning and maintenance of fiber optic networks. This dedicated cost effective instrument allows testing to be fast and easy. It has the following principle characteristics: ❏...
Page 20 Introduction • OTS modules: power meter, light sources and talk set. Measurements The MTS allows long and short range tests to be made, in singlemode or multimode, on point-to-point or complex optical networks during: • the design and production of the equipment •...
Page 21 Printing It is possible to print the displayed screen either on an internal (MTS 5200 ) or external printer or to create a bitmap (.bmp) type file and store it on a floppy disk. The external printer uses the Centronics port. Epson, Canon or HP compatible printers can be used.
Page 22 Introduction 750000992/16 ANUAL Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Page 23 Chapter Getting Started This chapter explains the operations to carry out to start using the MTS ❏ before switching on: unpacking the instrument, installation and removal of a module, charging and installing batteries, connecting an external power supply, connecting the fiber, positioning the unit, connecting the handle or carrying strap.
Page 24 Getting Started Module Locking screws MTS 5200 rear view Removal of module The MTS must be switched off and, if AC powered, the cord must Attention be disconnected. 1. Completely unscrew the two large locking screws of the module. 2. Carefully pull the module backwards to slide it out of its slot. Installation of module The MTS must be switched off and, if AC powered, the cord must...
Page 25 Before switching on When the MTS is being held during use, the support strap should replace the carrying handle. Two positions are available: 1. MTS held in front, with the strap hanging around the neck of the user. The carrying strap must then be fixed at the upper studs, as shown in the following figure 1.
Page 26 Getting Started Use the same procedure to attach the opposite end of the handle or strap. The transport handle is attached to two metal studs on the left hand side of the instrument. The strap is attached to both sides of the instrument as follows: •...
Page 27 Before switching on the batteries and mains adapter can be left in place and it is powered from the mains. It is imperative to let the battery reach the end of its charge to pro- Important vide the maximum autonomy. If this is not done this period will be considerably reduced.
Page 28 Getting Started Battery Battery Connectors with compartment keyways towards the Installing the battery (example with MTS 5100 2. A keyway on the connector of the battery avoids any connection errors. Position the battery in its compartment, keyway towards the top and push the battery until it connects to its connector.
Page 29 Before switching on Using MTS from the mains supply The mains adapter allows the MTS to be used, while charging the batteries, or during a measurement to save battery life, if a mains supply is available. You must only use the mains adapter supplied with the MTS .
Page 30 Getting Started Refer to the Maintenance Chapter for all the precautions relative to Attention fiber optic connectors. The connection quality indicator is displayed on the screen when the Note measurement is started. Switching on/off the MTS Switching on the MTS •...
Page 31 After switching on Opening screen example (MTS 5100 After switching on Installing a new version of the software During the installation of a new version of the software, there is a Attention risk to reset the internal memory. It is therefore recommended, before installing the new software, to make a copy of the traces in memory, using the Copy option of the File manager menu, called by button.
Page 32 Getting Started The user will receive the set of floppy disks he need to upgrade his MTS Installation of the boot (if necessary) 1. The MTS being switched off (AC/DC adapter unplugged), insert the disk 1 of the boot into the floppy disk drive. 2.
Page 33 After switching on Press the YES key. "Programming flash memory; in progress": the MTS then programs its internal memory and starts up the new MTS software. "Completed" appears then the screen is blank: the software upgrade is completed. The MTS is ready for use when the LED is flashing.
Page 34 Getting Started OTDR Power meter Laser Source Valid the selected Function Function Function Function Visual Fault Fault locator Talk Set If VFL selected: IF Talkset Locator Function* Function* Function* Continuous or selected call Talk Set commands * (if the option is present) Configuration screen of the instrument (example with MTS 5100 and OTDR and OTS modules)
Page 35 After switching on To modify system setup parameters • With the MTS powered up, press the button. SET-UP The configuration selection keys are displayed on the screen. • Press the <System Setup> menu key. • Use the displacement keys ↑and ↓ to move the cursor to the element to modify.
Page 36 Getting Started Choosing the color of the trace background Press the button press the <System Setup> menu key in the Screen SET-UP , then window. Place the cursor on "Trace Background" and then choose either Black or White. If the instrument includes a VGA monitor, then the <VGA> key enables the transfer of information to this screen (see page 4-11).
Page 37 After switching on Welcome message (example with MTS 5100 If you don’t want this message at each power on, press the button, then SET-UP with the <System Setup> key, in the Screen window: • move the cursor to Welcome message •...
Page 38 Getting Started Choice of length (OTDR) or frequency (WDM) unit Press the button, then with the <System Setup> key, in the Country SET-UP window, move the cursor to the Unit option to choose : • kilometers, kfeet or miles for an OTDR trace (MTS with OTDR module). •...
Page 39 After switching on Choice of the content of the copy (on internal or external printer) In the Printer window move the cursor to Printer Contents to choose one of the options: Trace copy of the trace only together with the header (not available with OTS module).
Page 40 Getting Started Help key allows to access to an electronic manual : HELP 1. a first press on the key display the presentation and configuration of HELP the MTS 2. a second press on the key calls the electronic manual. HELP Help contents •...
Page 41 Printing Make sure the printer has paper (see "Loading a new roll of paper" Attention on page 3-26). 1. Press the key, then the <System setup> softkey and select the internal SETUP printer. 2. On the "Printer contents" line, select to print either only the trace or only the table, or both trace + table or the screen.
Page 42 Getting Started Table 1: Example of header for OTDR results Range Range used for the measurement Resolution Space between measurement points Averaging Number of seconds of averaging for the measurement Fiber Number Fiber number Fiber parameters Index Index of the fiber Scatter Coeff.
Page 43 Printing Table 2: Example of header for WDM results Frequency Frequency range in THz Resolution Filter resolution Averaging Number of seconds of averaging for the measurement Threshold Threshold used to detect the channels S/N Distance Distance between the channel peak and the reference point for the noise Noise Acqu BW Reference bandwidth used for noise acquisition...
Page 44 Getting Started Examples of OTDR print out The following examples concern the 4 possibilities given in the menu <System setup>, on the line Printer/Print Contents: print of the trace only, the table only, the trace and the table, the screen. Example of printed "Trace"...
Page 45 Printing Example of printed "Table" 3-23 750000992/16 ANUAL Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Page 46 Getting Started Example of printed "Trace + Table" 3-24 750000992/16 ANUAL Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Page 47 Printing Example of hardcopy 3-25 750000992/16 ANUAL Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Page 48 Getting Started Loading a new roll of paper The paper rolls must be stored in a cool, dry and shaded place. Attention see reference on page 11-7. An internal device detects the end of the roll and triggers display of "No paper". Also a red line is marked on the paper, beginning approximately 1 meter from the end of the roll.
Page 49 Visual fault locator function 3. On the Printer contents line, select to print either the trace, or the table, or both trace + table or to make an hardcopy of the screen. 4. In the I/O interface windows, line Centronics, select the Printer option. Printing on an external printer Use the following procedure to print on an external printer: 1.
Page 50 Getting Started Optical Talk Set Function This function is available as an option with the OTS modules. It consists of a headset and microphone. It allows two users situated at each extremity of an optical link to communicate. Each extremity of the link must be equipped with a combined Laser source/ Power meter: •...
Page 51 Introducing a user logo Specific key functions when the Talk Set is active Pressing the <Talk Set> key calls the following keys: <Com. Laser>Toggles the transmitted signal wavelength between 1550 and 1310 nm. This key is also available in the standby state. A 1550 nm wave length provides communication of greater distances than a 1310 nm wavelength.
Page 52 Getting Started • the new logo appears on the screen: it will now replace the previous logo on the help pages obtained by pressing the button. It will also be present in HELP headers of the printouts. It is possible that the colors selected on the PC are not the colors dis- Note played on the MTS .
Page 53 Chapter Controls This chapter describes the MTS commands: ❏ Front panel commands: buttons, softkeys, screen, etc … ❏ Rear panel commands: connectors (power, RS 232, Centronics), disk drive, optical connector. The MTS is a multi-tasking instrument: the user can simultaneously Note make an acquisition, modify the configuration parameters, print the results and access an internal memory directory or floppy disk direc-...
Page 54 Controls Display screen Softkeys ↑ Charge Help Print File Results Run Set-up Start ← → Stop ↓ Front Panel Display screen and softkeys The MTS is equipped with a large display screen that provides excellent resolution and that can also be backlit: •...
Page 55 Front panel Horizontal line localisating Acquisition parameters used: the display part of the type of module, trace with respect to the exact wavelength at 25°C (nm) Icon representing complete trace. pulsewidth, Positions of the cursors the actual function index of refraction (IR), are represented by little : printing, copy on fiber number N,...
Page 56 Controls Directional arrow keys The directional arrow keys have two principle functions: • on the result page, they are used to position zoom and move the cursor. • on the setup pages, they are used to scroll though the menus. Control keys The six keys on the screen provide the following functions: This START STOP key has two functions.
Page 57 Configuration menus Configuration menus • All the configuration menus are accessible from one another by pressing on the corresponding key. • The configuration menu can be displayed and modified during an acquisition or measurement. The parameters that cannot be modified are dimmed.
Page 58 Controls Edition menu This menu contains: • in the central window, the list of characters available (which can be understood by the DOS system) and, in the upper part of this window, the text to modify or the text that is being entered. •...
Page 59 Editing To delete a character in a text: • Position the cursor on the character • Press the <Del Char.> key Repeatedly pressing this key deletes the proceeding characters. To insert characters in the text: • Position the cursor on the character proceeding the point you want to enter text.
Page 60 Controls Editing a text from the external keyboard Function External keyboard Ctrl + H Help Ctrl + P Print Ctrl + F File Results Ctrl + R Start/Stop Ctrl + S Set-Up Ctrl + U ← ↑ → ↓ ← ↑ → ↓ F1 →...
Page 61 Rear panel On the MTS 5200 only, if the corresponding options are present : • the internal printer • the connector IEEE VFL output Interchangeable modules Optical (option) connector (OTDRs in this example) Connector for RS 232 Centronics Floppy disk 12 V mains connector (printer / keyboard)
Page 62 Controls Serial port (RS 232) A 9 pin serial connector (RS232 DTE) allows a direct connection to a modem for programmed operation. Function Input/output ← ← → → → ← → Port RS232 ← In the case of a connection to a computer (PC for example) which has Attention also a DTE behavior, use a cord inverting pins 2 and 3, 4 and 5, 8 and 9.
Page 63 Rear panel IEEE port Optional, for MTS 5200 mainframe only: 24 pin parallel port allowing the connection to a controller. Reference of the option: 5200/IEEE. Computer display output Optional, for MTS 5200 mainframe with color TFT display only: 15 pin port allowing the connection to a projector or a monitor.
Page 64 Controls 4-12 750000992/16 ANUAL Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Page 65 Chapter Using an OTDR module This chapter describes the different steps required to make a measurement: ❏ The configuration of the acquisition (manual, auto, etc.) and the acquisition parameters. ❏ The choice of the results to display. ❏ The start of measurement (acquisition) ❏...
Page 66 Using an OTDR module All these parameters are configured from the Identifiers menu of the File Manager window and can be entered before or after the acquisition. To select the required acquisition, you must call the OTDR TEST SETUP window measurement result display parameters and fiber parameters, pressing the <...
Page 67 OTDR Test SET-UP The available choices are displayed on the screen; these depend on the chosen function. Make the required choice with the ← and → directional arrows. Selecting measurement acquisition parameters You can choose the following measurement acquisition parameters, from the Acquisition menu of the ODTR TEST SETUP window, regardless of the type of measurement made on the trace: Laser...
Page 68 Using an OTDR module Selecting measurement result display parameters You can choose the following measurement result display parameters from the Result menu of the OTDR TEST SETUP window: Splice threshold: Selection between: ALL, NONE or any value in dB between 0 and 6.00 in 0.01 dB steps.
Page 69 OTDR Test SET-UP Results on trace Choose to display: None: the trace only All: the trace with results and markers Graphics only: the trace with markers only. Factory default value: All. Remarks in table Selection of the display of notes in the table (see "Notes in table"...
Page 70 Using an OTDR module - or select a predefined value : press the <Preset Index> < softkey and select (using the « «and «>» arrows keys) one of the cable. See in the following table the index for each cable type. Once a cable has been selected, press the <Confirm Index>...
Page 71 Acquisition ❏ A manual acquisition mode that lets you configure your acquisition parameters exactly for the fiber you wish to test. After any acquisition (except in real time mode), an automatic measurement is performed. With multi-wavelength modules, the acquisition can be started automatically on all the wavelenghts, each time the button is pushed.
Page 72 Using an OTDR module Status Connection condition Indicates one of the following cases: There are several connectors close to the front end connector. One of the connectors is dirty or badly connected. You must re-connect or change the pigtail. There is no fiber connected. For a bad connection condition you can make measurements but very poor detection results should be expected.
Page 73 Acquisition Automatic acquisition mode The simplest way to quickly use the MTS to detect any faults on your fiber optic link is to make use of the automatic acquisition function that is provided. This function allows you to automatically configure the MTS to use the optimum acquisition parameters (pulsewidth and range) for the link under test with respect to the selected time.
Page 74 Using an OTDR module Start Auto-Configuration Chose range Detected Range Short Medium Long Choose pulse: Auto select: - Pulsewidth - Range Acquisition for: MAX ACQ TIME Auto-Configuration Process 5-10 750000992/16 ANUAL Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Page 75 Acquisition Acquisition time in progress Number of averaging Acquisition measurement progress display You can push the key at any time to stop the acquisi- Note <START STOP> tion measurement. If you do this, an automatic measurement is real- ized but certain events may not be detected because the instrument will not have made the required number of averages for an optimum measurement.
Page 76 Using an OTDR module Use the following procedure to configure your manual acquisition in the OTDR TEST SETUP window (refer to "Selecting measurement acquisition parameters" on page 5-3): 1. Select the Laser wavelength with the Acquisition:Laser option. 2. Select the Manual mode with the Acquisition:Mode option. 3.
Page 77 Acquisition You can push the key at any time to stop the acquisition Note START STOP measurement. If you do this, an automatic measurement is realized but certain events may not be detected because the instrument will not have made the required number of averages for an optimum measurement.
Page 78 Using an OTDR module • Stop the measurement. • Disconnect the source sending out the signals in the fiber or disconnect the network fiber. • Restart the measurement. Result analysis Once you have completed an acquisition, Results are displayed to allow you to analyze the resulting trace.
Page 79 Zoom and shift functions Zoom and shift functions Zoom function The Zoom function allows you to analyze a detected event in greater detail. Using the Zoom function in combination with the Event function allows you to quickly verify any uncertain events. The zoom of the display is made around the selected cursor.
Page 80 Using an OTDR module Once you have made an acquisition and have results, you can simply press the Event key to move the cursor from event to event. Using this function in combination with the ZOOM and CURSOR keys allows you to rapidly analyze the fiber.
Page 81 Table of results 3. Use the Event key. The measurements given are the true distance from the < > beginning of the link, and the attenuation of the link plus the attenuation of the connection. This function may also be used to determine the loss budget for a partial section of the fiber under test.
Page 82 Using an OTDR module Table of results To return to the display of only one line of the table, press the <Trace> key. Information given for each type of event detected • the type of event with its associated event number: Non-reflective event (e.g.
Page 83 Table of results Event marker when a measurement cannot be made. If an added event is too close of an existing event, this icon appears on the trace and on the table for the second event, but no measurement is made : a manual measurement is necessary to have results for this event.
Page 84 Using an OTDR module • press the <Notes table> key and select the Notes option • enter the note in the Edit menu. • press the <Exit > key. The user can display indicators in the result table to evaluate the uncertainty about the result.
Page 85 Addition of markers If only automatic measurements are to be made, verify that the lock Note marker function is not activated (i.e. icon not shown in the title bar of the display). Using this method of detection and measurement allows you to rapidly find all the events on the fiber under test.
Page 86 Using an OTDR module Adding markers To add event markers: 1. Select a cursor. 2. Use the positioning arrows to move the cursor to the position where you want to add a marker. 3. Press the <Marker> key. 4. An event marker is displayed at the cursor location and a full measurement is immediately performed.
Page 87 Addition of manual measurements Making Slope measurements To make a manual slope measurement: • Press the button to call the trace. RESULTS • Position the A cursor at the start of the section of the trace where you wish to measure the slope.
Page 88 Using an OTDR module If no result is displayed If no result is displayed this can be due to: • the display slope measurement result threshold is higher than the slope you are trying to measure, • the Slope Threshold option in the OTDR Test Setup menu, is set to NO slope display.
Page 89 Addition of manual measurements Two cursor splice measurement result Five cursor method To make a five cursor splice measurement: 1. Measure the slopes that precede and follow the fault to be measured using the slope function. 2. Position the cursor at a point between the two slopes (at the location of the fault).
Page 90 Using an OTDR module Five cursor splice measurement result 3. Successively press the <Expert>, then <Manual>, then <Splice> keys. The splice event marker is positioned at the point defined by the cursor and the result is displayed on the trace and in the event result table. To perform a five cursor splice measurement, when the <Splice>...
Page 91 Locking markers The ORL is measured for the section of the trace defined and the result indicator shows the ORL in dB in the table of results and on the trace. ORL measurement result ORL on a saturated trace When events are saturated, then the ORL value is given with a < sign. This means that the real ORL is less than the value displayed.
Page 92 Using an OTDR module Recommended sequence The following sequence is recommended: 1. Make an automatic measurement 2. add markers using the <Marker> key. 3. add required manual measurements (<Expert> / <Manual> key) If a marker is added using the <Marker> key, after performing man- Attention ual measurements, then all markers on the trace ( .
Page 93 Overlay trace function Example : overlay of 3 traces Transferring stored traces to the overlay memory To display up to 4 traces originating from the memory, with the erasing of the current trace or the traces already loaded, do as follows: •...
Page 94 Using an OTDR module Adding overlay traces With one or more traces already displayed, you can add other traces to the display (up to 4 traces on the screen at the same time can be displayed). To do this: • Press the key, and then in the Memory menu select the trace files to be FILE added (see "Selection of several files"...
Page 95 Overlay trace function Shifting traces Manual shift of the current trace To vertically shift the active trace while the overlaid traces remain at their original position, select the Cursor mode, then use the ↑ or ↓ arrow key. Manual shift of all the traces To simultaneously shift the displayed traces, select the Shift mode, then use the ↑...
Page 96 Using an OTDR module Both End Measurement The Both End measurement function allows the results of measurements made in both directions of the fiber (Origin to End or End to Origin) to be used to obtain more accurate splice and connector loss results. Measurement Principles The Both End measurement function uses the Trace Overlay function "Overlay trace function"...
Page 97 Both End Measurement Acquisition of the two traces If you need to make an acquisition in both directions: • Make a measurement in one direction. The corresponding trace is displayed in the Results page. • Successively press the <Expert>, <Overlay> and <2 Traces> keys to put this trace into the overlay mode.
Page 98 Using an OTDR module Data corresponding to active trace Active trace: green (or dark) Non-active trace: blue (or light) Simplified marker The active trace in this example is O to E Both End Measurement display Changing the active trace If you are in Cursor or Zoom/Shift mode, press the <Evt OE> key. The event search function is activated and can be started with the directional keys.
Page 99 Both End Measurement Results displayed in red if they exceed the splice alarm threshold defined in the OTDR TEST SET Non detected event Total result of the fiber link menu. (distance and loss) without Result Table A marker must therefore be placed on the corresponding trace, at the position where the event was detected in the other direction.
Page 100 Using an OTDR module Origin launch Fiber Under Test Extremity cable Launch Cable launch cable O-> E launch cable E-> O Marker 1 Marker 1 Saving Both End measurement result table Once the result table is complete, it is possible to save it as an ASCII file which can be imported into EXCEL.
Page 101 Fault locator mode • Return to the normal display of the two traces in overlay by successively pressing the <Expert>, <Overlay>, <Standard overlay> keys. • Return to displaying a single trace by successively pressing the <Expert>, <Overlay>, <1 trace> keys. The MTS also exits this mode if a new trace is loaded or a new Note...
Page 102 Using an OTDR module Fault location The OTDR trace is also displayed with the cursors A and B placed on the end of the fiber. Cursor and Zoom keys are available. Messages indicate how to return to the instrument configuration menu ( SETUP key) and to locate the end of the fiber again ( key).
Page 103 Macro Macro menu Starting a macro (Play) • Press the , then the <Macro> key. SET-UP The Macro menu appears. • Select the macro to use • Press the <Play> key if you want to execute the actions with the same delay as when creating the Macro;...
Page 104 Using an OTDR module Creating a user macro 1 to 4 (Learn) Precautions before creating a macro • Set-up the MTS When a macro is played, the MTS set-up is restored to the state when creating the macro. Therefore it is advised to set-up the MTS before creating the macro.
Page 105 Macro Loading a macro from a floppy disk • Press the key. FILE • Press the <Explore> key and select the directory of the floppy disk. • Press the <Open Dir> key and select the macro file. It has a .mac extension. •...
Page 106 Using an OTDR module - Markers: not locked - Fiber Number The macro 5 starts the following actions: • acquisition for the selected time • storage of acquisition and results (first wavelength) • overlay • wavelength change • new acquisition for the selected time •...
Page 107 Chapter Using the OTS module This chapter describes the different steps required to make an OTS measurement: ❏ OTS Test Setup ❏ OTS Result Display ❏ OTS measurements ❏ Result acquisition methods OTS Test SET-UP To set up the OTS and then make a measurement of the fiber under test the following parameters need to be configured: ❏...
Page 108 CW: Continuous signal. 270 Hz, 330 Hz, 1 KHz and 2 KHz: the source transmits a modulated signal at the frequency selected. Emul. OLS: to communicate with an Acterna OLS or OFI instrument. Scanning The source then switches every 10 seconds between the two wavelengths and provides a signal indicating the wavelength of the transmitted signal.
Page 109 (CAL). In the "Emul. OLS» mode the signal is alternated every 4 s. in order to be compatible with the TwinTest mode of the OLS and OFI Acterna series. Power Mode only available with laser sources.
Page 110 Using the OTS module instrument at the time interval selected with the Auto Time function described below. User Select Selection of the any wavelength value between 800 nm to 1650 nm in 1 nm steps, using the arrow key <- or ->. Choice of the time interval between measurements for Time Auto Autostore or Autoprint.
Page 111 OTS Results Window OTS Results Window (including light source and power meter) Light Source Light Source Display The Light source display provides all the details of the currently selected Light source configuration. It also contains the specific softkeys required to control the various functions of the Light source when it is selected.
Page 112 Using the OTS module Light Source Softkeys The following softkeys are available when the laser source function is selected from the OTS Results window: <Laser On> / <Laser Off> (or <LED on> / <LED Off>) used to switch the light on and off. When <Source> is selected from the OTS Results window the <Laser On>...
Page 113 OTS Results Window Source Power in Power in Toggle between Laser On / Laser on wavelength: selected non- the 2 icon 1310 or 1550 nm unit selected wavelengths unit Power mode SCANNING Transmission mode Send Lambda (only available if indicator: LIGHT mode icon indicator: CW, signal to the...
Page 114 Using the OTS module Source LED On icon Toggle between the LED On / Off wavelength: 2 wavelengths 850 or 1300 nm Power mode SCANNING Transmission mode Send Lambda (only displayed if indicator: LIGHT mode icon indicator: CW, signal to the VARIABLE power OFF or 270Hz, 330Hz,...
Page 115 OTS Results Window • The selected threshold cursor showing the current threshold in dB. Pressing the ← and → directional arrows modifies this value. • The icon that indicates an audible alarm will be given if the measured power passes the selected threshold. •...
Page 116 Using the OTS module Wavelength: Light Power Shows that an external Select wavelength 850, 1310, 1550 nm calibrated in selected attenuation has been softkey or any value between 800 and unit included in the test set- 1650nm in 1nm increments up menu.
Page 117 OTS Measurements LEVEL legend on the power meter display and remains displayed until another value is selected. • The <Wavelength> key is used to select the required measurement wavelength. Each press of the key toggles the available calibrated wavelengths (850, 1310 1550nm), the currently entered User Select wavelength and Autolambda automatic wavelength selection.
Page 118 Using the OTS module 4. From the OTS Results window press the <Source> softkey to access the Light source functions of the OTS. 5. Press the <Laser On> (or <LED on>) softkey. The resulting measured power is displayed on the power meter. 6.
Page 119 Power meter Specific Functions 3. Press the direct access key to display the OTS Results window. RESULTS 4. From the OTS Results window press the <Power meter> softkey to access the power meter functions of the OTS. 5. Use the <Wavelength> key to select the AUTOLAMBDA mode. 6.
Page 120 Using the OTS module • To access the memory functions press the <Memories> key. The following memory functions are displayed. Name of the displayed memory: Go to : - OTS RESULTS for the active memory - the top, - FILENAME for the currently displayed loaded table - the middle - CURRENT for the results saved during an Autostore operation - the bottom of table...
Page 121 Power meter Specific Functions • the <top> key moves the display window to the first set of memorised results in the table • the <Middle> moves the display window to the middle of the memorised results in the table • the <Bottom> moves the display window to the end of the memorised results in the table •...
Page 122 Using the OTS module 5. Press the direct access key to execute the automatic result START/STOP storage sequence. It is possible to integrate manual storage to an automatic storage.To Note do this the cursor must be positioned on the last line of the memory. Then the <Store Results>...
Page 123 Power meter Specific Functions 9. Press the direct access key to execute the automatic result START/STOP storage sequence. The results are printed on the printer at the selected time interval. 10. The sequence is stopped either when the key is pressed to stop START/STOP the execution or when 300 results have been printed.
Page 124 Using the OTS module 6-18 750000992/16 ANUAL Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Page 125 Chapter Optical spectrum analyser This chapter describes the different steps in carrying out a spectrum analysis of an optical signal by an MTS equipped with a WDM 507x module: ❏ OSA configuration test ❏ Display of spectrum and results of the WDM analysis Configuration of the instrument After connecting the fiber to be tested to the optical connector, you must select the OSA module (see "Instrument Set up"...
Page 126 Optical spectrum analyser OSA CONFIGURATION TEST Acquisition parameters When a channel power is higher than10 dBm or when the composite Note power of the input signal is higher than20 dBm, a warning is dis- played and the signal is cut off. Sweep Continuous Every two seconds there will be a measurement with a trace...
Page 127 OSA test setup Detection parameters Channel Detection 1st swap Channels of the first measurement serve as a detection reference. Grid Manual, ITU and Auto grid serve as a detection reference. The grid selection has priority on the "Channel Detection". For exam- Note ple it is not possible to choose Channel Detection = Grid, if the grid option is Off or Convent.
Page 128 Optical spectrum analyser Results display parameters Start screen Start of display. Auto Automatic detection of start of display depending on the channels detected. Start and end of displays are set automatically. Full Start of display at 1525 nm (for a 5071 WDM module). Manual Start of display manually chosen.
Page 129 Display of WDM results from 50 to 400 GHz by steps of 5 GHz, or from 0.160 to 8.000 nm by steps of 0.001nm. - number of channels. The <Between A and B> key allows to have only between the cursors the grid with the defined spacing .
Page 130 Optical spectrum analyser Module Resolution Number of Signal Distance Fiber Date and hour of number acquisition threshold number acquisition Channels Threshold Scale Cursors A and B Channel numbers Frequency (or wavelength) and Frequency difference (or Displayed channels (current, found power at point of the trace wavelength) and the power or exceeding the threshold alarm) marked by the cursors A and B...
Page 131 Display of WDM results Cursors To move the A (or B) cursor by pressing the cursor key, first display <Cursor A> (or <Cursor B>), then use the < or > arrow keys. To move both cursors simultaneously, press the cursor key to display the <Curs. AB>...
Page 132 Optical spectrum analyser Grid display The display window of the trace may contain a grid to facilitate the control of the position of the channels. Several grid types are possible: • The Conventional grid has an interval (spacing) indicated in the top right corner of the window, which varies according to the zoom level.
Page 133 Display of WDM results Total power Gain Tilt Gain Slope Display of total power, Gain Tilt and gain slope between the cursors Overlay See "Overlay of traces" on page 7-12 Table Lines Depending on the choice made in the Set-up menu, in the Detection window, for the «Channel Detection»...
Page 134 Optical spectrum analyser Table contents without statistics In the absence of statistics (see "Detection parameters" on page 7-3), the parameters given for each channel are as follows: 1. Channel number (the total number of channels is given in the first column header).
Page 135 Display of WDM results Successive addressing of channels according to the chosen sort On the trace and in the table, it is possible to make the cursor successively pass on the channels according to the selected sort order. To do this: •...
Page 136 Optical spectrum analyser • during the following acquisitions, the detected channels or «current channels» are not necessarily the same as the channels found with the first acquisition. To choose the channels to be displayed, use the <Current Channels> / <Found channels>...
Page 137 Overlay of traces Possible actions after overlaying a trace Returning to a single trace display When two traces are displayed, press the <Remove> key to remove the overlay trace and display only the current trace. The softkey <View 2 curves> allows you to recall the last overlay trace so that you can have both traces on the screen again.
Page 138 Optical spectrum analyser 7-14 750000992/16 ANUAL Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Page 139 Chapter File management This chapter describes the following file management functions: ❏ Choosing the storage medium ❏ Storing data ❏ Using stored data (loading traces, copying and deleting a file) ❏ Automatic and manual file naming ❏ Overlaying traces ❏ Formatting a floppy disk Storage media For storing and recalling acquisition data MTS is equipped with the following:...
Page 140 File management • In the File window, with the directional keys, select the Media/Dir option, then the support: Internal or Floppy Disk or Hard Disk (options). When the Media line is selected, the key <Format> is available to format the selected media (see "Formatting"...
Page 141 Filename AUTO The file name is automatically created when it is saved, conforming to the naming conventions given below. SEMI-AUTO The file name is automatically created when it is saved, conforming a code defined by the user. Warning concerning file naming When saving in internal memory (RAM), if the first character of the Note identifier is a digit, it will be replaced with an A in the file name.
Page 142 File management OTDR module automatic file naming: cccffwps Pulsewidth used for the measurement 3 ns 5 ns 10 ns 20 ns 30ns 100ns 200ns 300 ns 500 ns 1 µs 3 µs 10 µs 20 µs Direction origin to extremity extremity to origin * the available values are depending on the module used.
Page 143 Filename Semi-auto file naming edition • On the Coding line of the editing menu, define the filename code. For that, move the cursor on the different line of the menu (in the order you wish for the coding) and enter the corresponding characters pressing the <Valid Char.>...
Page 144 File management when you leave the semi-automatic mode for another mode, the cod- Attention ing is lost. OTDR module semi-automatic file naming t... First characters of the title c ... First characters of the cable identification defined in the File windows Fiber number 0 to 99 decimal coding...
Page 145 Filename OTDR module semi-automatic file naming Resolution * 4 cm 8 cm 16 cm 32 cm 64 cm 125 cm 250 cm 10 m 20 m 40 m 80 m 160 m 320 m * the available values are depending on the module used. OTS Module Automatic Filenaming When you store an OTS data to disk using automatic file naming, the file name is automatically created using the following file naming conventions :...
Page 146 File management OTS module automatic file naming: cccffwps Range manual range µW manual range manual range Auto range Direction origin to extremity extremity to origin * the available values are depending on the module used. OTS Module Semi- Automatic Filenaming When you store an OTS data to disk using semi-automatic file naming, the file name is created using the file naming conventions selected by the user as follows:...
Page 147 Filename OTS module semi-automatic file naming Fiber number 0 to 99 decimal coding A0 to YZ alphanumeric coding (100 to 999) o ... First characters of the origin location e ... First characters of the extremity location Direction origin to extremity extremity to origin Laser wavelength used for the measurement 1310 nm...
Page 148 File management WDM module automatic file naming: cccpppff Fiber number 0 to 99 decimal coding A0 to YZ alphanumeric coding (100 to 999) WDM Module Semi-Automatic Filenaming When you store an WDM data to disk using semi-automatic file naming, the file name is created using the file naming conventions selected by the user as follows: •...
Page 149 WDM file format Each time a WDM result is saved, two files are created with the following format: .WDM: Acterna formats (compatible with the Acterna WinTrace and WinCable softwares) . .TXT ASCII format for a possible transfer to a spreadsheet or word processing program.
Page 150 File management • Save the file on a floppy disk: see "Copying files from one medium to another (if available)" on page 8-21. • Copy this file on the PC loaded with the Excel software. • On the PC open Excel •...
Page 151 Filename Transferring OTS file under Excel (2) • Select the following parameters: Delimiters: Tab Text Qualifier: " • Click on: Next>. The following window is displayed: Transferring OTS results under Excel (3) • Select the Column Data Format: General. • Click on: Finish. For OTS table The OTS measurement results are displayed in an Excel table as follows: 8-13...
Page 152 A Macro (ref macroots.xls) is available to improve the layout of the table under Excel: it adds the column title (for parameters and results). To get this macro, ask your Acterna service center. Use of the file macroots.xls: • Open the file "macroots.xls ", then the OTS file to display.
Page 153 Filename Memory Info and Comments In this example, the Memory info and Comments concern the trace recalled from Memory info menu of the File Manager window The information displayed in the Memory Info and Comments windows concerns: • either the acquired trace. •...
Page 154 File management Cable Id. Choose an identification name for the cable. The first three characters of this name are used for the file name when automatic file naming is selected. Fiber Number Select the identification number of the fiber from 0 to 999. This number is used in the file name when automatic file naming is selected.
Page 155 Manipulating stored data Directory management Directory window The left window displays: • the icons representing the available media RAM or Hard disk and diskette (a double click on these icons gives a direct access at the corresponding media); • the directories contained in the selected media; •...
Page 156 File management ↓ : at the end of the list. • Use the «↑» and «↓» arrow keys to scroll the list. The directory whose files are listed is highlighted. Use the arrow keys to move from one window to another or to select a file or a directory in a window.
Page 157 Manipulating stored data To deselect a file, place the cursor on this file, then press the <Deselect> key. Selecting all the files in a directory The <Select all> key selects all the files of the selected directory. Then, the <Cancel Select.> key allows to deselect all the files. If there hasn’t been any files selected by the <Select.>key, then the Note file where the cursor is currently placed above is considered as...
Page 158 File management If the configuration can be recalled it is possible to make an acquisition with the same conditions as those of the recalled trace. If, during the acquisition of the trace, the OTDR was equipped with Note a different type of module to the current module, certain configura- tion parameters will not be able to be set.
Page 159 Manipulating stored data • Either press the <Select key to select each file you want to delete. Select any > of the stored files you want to delete. • or press the <Select all> key to select all the files in the directory. •...
Page 160 File management Copying from internal memory or hard disk to floppy disk (if option selected) • Press the key to call the File manager window. FILE • Select the Internal medium or Hard disk. • Press the Explore key: the corresponding directory is displayed. <...
Page 161 Formatting Printing files Renaming a file To rename a file: • Move the cursor on the filename to change as described above (see "Finding files" on page 8-18) • press the <Rename> key: the Editing menu appears. You can then enter the new name (see "Editing"...
Page 162 File management 4. Press the Format key. < > Abort> and <Confirm keys are displayed to format the disk or abort < > the operation. 5. Press the <Confirm> key to start formatting the floppy disk. If there is no disk inserted in the disk drive, when you try to format it Note will display the following error message: (201) Insert a disk...
Page 163 Chapter Remote control Remote control of the MTS uses either the IEEE 488 standard (or international equivalent IEC625-1) or RS232 interface. English is the default language. This chapter includes: ❏ Remote control principles (link to controller, format of commands, tree menus of commands) ❏...
Page 164 Remote control Connection via the Ethernet interface Equipment delivered with the option • RS232/Ethernet Adaptor plugged into RS232 port. • Ethernet crossed cable for direct link between PC and MTS • WS-FTP Pro software (ref. 5996/MTS) • Diskette containing set-up file for WS-FTP Pro. Link with PC The link with the PC may be direct or via a network: 1.
Page 165 Description of commands and queries • either via the RS232 connector. In this case, in the menu System set-up menu, on the Remote Access line select the option TCP/PPP. • or via the Ethernet connector (if the option is present). In this case, in the menu System set-up menu, on the Remote Access line select the option TCP/ ETH.
Page 166 Remote control Command Syntax • Commands include upper and lowercase characters - only uppercase characters are required, - lower case characters can be removed to abbreviate the commands. • Successive nodes should be separated by a colon (:) • A space should separate the last level node from any possible associated parameter.
Page 167 Request to go to the remote mode. *REM Request to return to local mode. *LOC Identification and option queries request the MTS identification. *IDN? Response: Acterna, MTS5100, n, X.YZ with: serial number X.YZ software version Request options available on the MTS *OPT? Reset commands...
Page 168 Remote control Device event bit enable *ESE * ESE is followed by a number (0 to 255) Action: Enabling register modified and ESB bit updated. This instruction is associated with *ESE? Clear status registers *CLS - clear standard event register in RS 232 - clear standard event register and device status register in IEEE.
Page 169 Common part commands Status commands Response : "In-process" or "Stopped" STATus ACQ? (reported to bit 0 of STB page 9-6) TOP? Message displayed at the top of the screen Error message (Warning, reported to bit 1 of STB page 9-6) ERRor? They query results from a previous command.
Page 170 Remote control Commands relative to the module and the function Format des commandes MODule FONction? [LEFT, RIGHt], [OTDR, SOUR, PWM, VFL, TSET, OSA] FONction [LEFT, RIGHt], [OTDR, SOUR, PWM, VFL, TSET, OSA], [ON, OFF] NAME? [LEFT, RIGHt] Description des fonctions •...
Page 171 Common part commands PREView Begins the waveform acquisition in real time without averaging the results. The unit either can be stopped remotely during the real time acquisition or will stop automatically after 10 minutes. SK1, …SK6 Softkey 1 to 6 (from top to bottom of the display). BEGinacq Begins the waveform acquisition and averages waveform results during the acquisition period.
Page 172 Remote control TERMin Name for the end of the fiber. Measurement direction: O → E (origin to extremity) or E → O. DIRection FNUMber Identification number of the fiber from 0 to 999. This number is used in the file name when automatic file naming is selected. INCFiber Auto-increment file name function.
Page 173 Command relative to the OTDR module Format des commandes [1:100], [string of 41characters] ONOTes Description des fonctions Note of up to 41 characters associated with an event. For each wavelength, a maximum of 16 notes are possible. Command relative to the OTDR module Acquisition commands Format des commandes ACQuisition...
Page 174 Remote control AUTO: The MTS will choose the appropriate resolution. The second parameter is necessary but not significant. MANU: the resolution must be given in the second parameter. If the selected value is less than the min. possible value, then the min.
Page 175 Command relative to the OTDR module Result commands Format des commandes [0 : 601] MEASure DSPLice [-100 : -10] DREFlectance DSLope [0:2001] DGHOst [YES, NO] [TWOpoints, LINear] MSLope DCURve [YES, NO, GRAPhic] [NO, UNCertainty, NOTes, YES DREMarks [2:15] End of fiber 2= automatic ENDFiber 3 to 15 = threshold in LCABle...
Page 176 Remote control e.g. “(R:-50dB)”. Factory default value: yes. Ghosts are only detected during an automatic measurement. MSLope Slope measurement methods: least squares (LSA) or 2-point loss. Factory default value: LSA DCURve Measurements displayed on trace: No: the trace only YES: the trace with results and markers GRAPhic: the trace with markers only.
Page 177 Command relative to the OTDR module Fiber commands Format des commandes FIBer [L850, L1300, L1310, L1550, L1625], [1.3 : 1.7] Index of the fiber depending on the wavelength [L850, L1300, L1310, L1550, L1625], [-99 :-50] Backscattering coefficient depending on the wavelength [L850, L1300, L1310, L1550, L1625] [L850, L1300, L1310, L1550, L1625] Description des fonctions...
Page 178 Remote control Reading of OTDR results commands Format des commandes OTResult OTDR? PULSewidth? RANGe? LASer? ATIMe? DATE? SIZE? XOFFset? XSCale? YOFFset? YSCale? BUFFer? CURSor [A, B], [0 : 400.000.0] m CURSor? [A, B] CVALue? [A, B] STABle? [1: 200] LTABle? [1 : 200] RTABle? [SOR, WTK, BSOR, BWTK]...
Page 179 Remote control PULSewidth? Returns the pulsewidth RANGe? Returns the range LASer? Returns the wavelength ATIMe? Returns the acquisition time DATE? Returns the date SIZE? Returns the number of points (size of the trace). XOFFset? Returns the X axis offset XSCale? Returns the X axis scale YOFFSet Returns the Y-axis offset...
Page 180 Remote control Reading the buffer storing the trace The current curve is stored in a buffer. Capacity of this buffer: 4 x number of points. Each point is coded using four ASCII characters on 16 bits. Command used to read the buffer: OTResult:BUFFer? Example of response for a buffer of 2000 points: #6008000217F217E2180...
Page 181 Commands relative to the OTS modules Conversion from delay to distance To convert the result from second to meter, use the following formula: × ∼ ------- × time s ( ) × meters with: c = speed of light in vacuum (2.99792458 m/s) n = refractive index of the fiber t = time (expressed in second) to convert in distance Commands relative to the OTS modules...
Page 182 Remote control PRINT: automatic printing of the results on the printer connected to the MTS at the time interval selected in seconds in the second parameter. REALtime Choice of the real time or averaging mode. When this mode has not be selected the power meter is, by default, in averaging mode. ALArm Selection of the required alarm threshold (-70 to +30 dBm).
Page 183 Laser source set-up MODe Transmission mode of signal emitted: CW: continuous power M270, M330, M1000, M2000: power modulated to selected frequency (270 Hz, 330 Hz, 1 kHz, 2 kHz) SCANNING: sources are alternated at regular intervals. POWer Transmitting power of laser source: CALIBRATED: power calibrated to 1 mW (0 dBm).
Page 184 Remote control read. For example, if ten measurements have been conducted, ten lines with the above format will be sent. MEM? Reading of one of 300 measurement results which were able to be stored in memory. This result is given on one line in the form: Lambda, Result Date Hour, (dBm), Res.
Page 185 Commands relative to the WDM module Commands relative to the WDM module Configuration OSA Format des commandes OSASetup DEFault MODe [0:100] HSEns [YES, NO] [FULL, R01nm, R02nm, R03nm, R04nm, R05nm] RESO [FIRst, GRId] DETection [-80.0: 20.0] [YES, NO] STAtistics [AUTO, I25ghz, I50ghz, I100ghz] [LEFT, RIGHt, BOTH] NBAnd [10:10000]...
Page 186 Remote control 2 to 100: the number of acquisition 0= continuous acquisition HSEns YES = commutation of High sensitivity saving. RESO Filter resolution. FULL: maximum filter resolution (<0,1 nm) R01, R02, R03, R04, R05 0,1 / 0,2 / 0,3 / 0,4 or 0,5 nm. DETection Detection of channels: FIRst: on the first acquisition.
Page 187 Commands relative to the WDM module Reading of OSA results Format des commandes OSAResult DATE? TIME? SIZE? XOFfset? XSCale? YOFfset? YSCale? BUFfer? FBUffer? CURsor [A, B] , [190.0: 198.0] m CURsor? [A, B] CVAlue? [A, B] GAIN TILT? GAIN SLOpe? POWER TOTal? POWER...
Page 188 Remote control Description des fonctions DATE Acquisition date TIME Acquisition time SIZE? Number of points on the curve XOFfset? First point of Abscissa (in THz) XSCale? Space X between two points (in THz) YOFfSet Y axis shift - Coefficient B of «val dB = A*y + B» YSCale? Y axis scale - Coefficient A of «val dB = A*y + B»...
Page 189 Signal/Noise standard deviation for the channel? OFILe? Returns the current results in a file. Acterna file format: WDM or BWDM. The BWDM file is the same as the WDM one but the size of the file is given in front of the response.
Page 190 Remote control In this example, for the last point, the y value is CB00 in signed hexadecimal. Thus: • CB00 in signed decimal = -13568 • the value in dB is: A*y + B = [-2.939746e-03 x (-13568)] + 34.590000 =- 13533.412 dB Number of points in the buffer? OSARESult:SIZE? Example of response: 32000...
Page 191 Maintenance work on this instrument can only be undertaken by qualified personnel using suitable equipment. In the majority of cases, it is advisable to contact the nearest Acterna Service Centre, which will undertake the appropriate troubleshooting and repair work. The performance and technical complexity of the MTS...
Page 192 Maintenance • If a fault is detected, or if a doubt exists, it is advisable to contact the nearest Wavetek Service Centre which will undertake the appropriate repair work. Returning an instrument When returning an instrument, please indicate the following minimum information: •...
Page 193 Battery replacement Cleaning the optical cable connector If your module has an universal connector, unscrew its adaptor to Note access the ferule. • Use a non degradable type of paper, such as Joseph paper, soaked in ethanol. • Pay particular attention to the polished face of the fiber, rubbing it in a perpendicular motion to the fiber.
Page 194 Maintenance 10-4 750000992/16 ANUAL Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Page 195 Chapter Technical specifications This chapter gives the specifications of: ❏ the MTS 5100 and MTS 5200 mainframes ❏ the OTDR modules ❏ the OTS modules ❏ the available options and accessories. Mainframe specifications Display Screen: • 8" Black & White or color passive (option 5000/PAS) or 8.4"...
Page 196 Technical specifications Input/Output • RS232C • Ethernet (option) • Centronics • IEEE-488 GPIB (option), for MTS 5200 only. Internal printer (optional for MTS 5200 only) • Reference 5200/PR • High quality (graphical) thermic printer • 832 dots / line • paper width: 112 mm. Power supply Batteries •...
Page 197 Mainframe specifications Dimensions Base unit MTS 5100 MTS 5200 Height 90 mm 130 mm Width 235 mm 235 mm Depth 300 mm 300 mm Weight 3.5 kg 5.5 kg including 1 module & 1 battery including internal printer, 2 modules &...
Page 198 Technical specifications OTDR Measurement characteristics Distance measurement • dual cursors • distance displayed with respect to the calibration of the fiber’s group index • group index adjustable from 1.30000 to 1.70000 in 0.00001 step • display resolution: 1 cm (0.39 inch) max •...
Page 199 OTS measurement characteristics OTS measurement characteristics The OTS modules comprise: a Power meter, Light sources and combinations of Light source/Power meter. Light source = Laser source or Led source Note A complete range of optical connectors and adaptors is available. Light source specifications •...
Page 200 Technical specifications Singlemode OTDR modules available The specifications of the 5026 (SR, DR, HD, VHD) modules are the specifications of the modules 5024 and 5025 (SR, DR, HD, VHD) according to the wavelength. The specifications of the 5029 VHD module are the specifications of the 5025 and 5027 VHD according to the wavelength.
Page 201 Modules, Options and Accessories LED source Wavelength (nm) 1300 850&1300 50610 LTS 50620 LTS 50630 LTS LED source + power meter 50611 LTS/TS 50621 LTS/TS 50631 LTS/TS LED source + Power meter + Talkset Chassis options 5000/PAS Color passive display 5000/COL Color TFT display 5000/FD...
Page 202 Technical specifications 5003/2 • for United Kingdom 5003/3 • for USA 5004 Soft carrying case for MTS 5100 5005 Hard transit case for MTS 5100 5006 Cigarette lighter Power Adapter Additional AC Adapter / Charger for MTS 5200 5007/1 • for Europe 5007/2 •...
Page 203 Modules, Options and Accessories DIN or Universal connector with adaptor Power meter adapters supplied with the MTS for connector VFO: 506VFO for connector FC/PC:506FC for connector ST: 506ST for connector DIN: 506DIN for connector D4: 506D4 for connector PFO: 506PFO for connector SC: 506SC 11-9...
Page 204 Technical specifications Specifications of the OTDR modules Wavelength and pulsewidth Multimode Modules 5023MM 5023 ML 5021MM 5022MM Wavelength 850 ± 20 nm 1300 ± 20 nm 8500/1300 ± 20 nm Dynamic range 20 dB 18 dB 16/14 dB with long pulse 25 dB 23 dB 18/16 dB...
Page 205 Specifications of the OTDR modules Singlemode Modules High Short Resolution High Dynamic Very High Dynamic Modules Range Medium Long range Long range range 5024/25/26 5024/25/26 5024/25/26 5027 / 5024/25/26 5029 /36 HD 36 HD Wavelength 1310 / 1310 / 1550 1310 / 1550 1625 1310 / 1550...
Page 206 Technical specifications Multimode MM and ML - at 1300 nm Class 1 Class 1 - at 850 nm Class 3A Class 1 Singlemode SR, DR Class 1 Class 1 Singlemode HD µs - at 1310 nm, 20 Class 3A Class 1 - at 1310 nm, other pulse widths Class 1 Class 1...
Page 207 Specifications of the OTDR modules Ranges Ranges for MM and 5023ML modules 3 ns 20 ns 50 ns 200 ns 500 m (1.6 kft) 1 km (3.25 kft) 2 km (6.5 kft) 5 km (16 kft) 10 km (33 kft) 20 km (65 kft) 40 km...
Page 208 Technical specifications Ranges for HD modules 1 µs 3 µs 10 µs 20 µs 10 ns 30 ns 100 ns 300 ns 5 km (16 kft) 10 km (33 kft) 20 km (65 kft) 40 km (131kft) 80 km (262kft) 140km (459kft) 260km (853kft) 380 km...
Page 209 Specifications of the OTS modules at 25 °C Specifications of the OTS modules at 25 °C Light sources Laser sources LED sources Wavelength 1310 & 1550 850 nm 1300 nm ± 850 & 1300 nm (source at 25°C) ± 30 nm ±...
Page 210 Technical specifications Specifications WDM modules Typical values measured at 25° C, unless otherwise stated. Module 5071- C band Module 5073- C+L band Wavelength Range 1525-1570 nm 1525-1610 nm Sweep time (real time) < 1 s <1,5 s Accuracy ± 10 pm Display Resolution 1 pm Min.
