1. Turn on the COMBO you want to control.
2. Hold down the SETUP (11) key until the red
indicator lamp (1) remains lit (the indicator light
remains on for a few seconds to give you the time
to proceed with the following steps. The indicator
lamp flashes when this time is almost up, and then
goes off).
3. Press the TV (2) key, then follow one of the
programming methods (A, B, C or D) described
earlier.
4. If second code programming is required then repeat
steps 2 and 3 above.
4 - How to retrieve
a programmed code
You may want to retrieve the code programmed in the
remote control.
1. Hold down the SETUP (11) key until the red
indicator lamp (1) remains lit (the indicator light
remains on for a few seconds to give you the time
to proceed with the following steps. The indicator
lamp flashes when this time is almost up, and then
goes off).
2. Press the product key (2) that corresponds to the
type of product you want to control:
TV: television set,
SAT: satellite receiver.
3. Press SETUP (11) again briefly. The red indicator
lamp flashes once.
4. Press the number keys (0 to 9) in ascending order
until the red indicator lamp (1) flashes once.
5. The digit which made the red indicator lamp (1)
flash, is the first number of the 3-digit code. Please
make note of it.
6. Repeat step 4 to find out the two other numbers of
the code.
7. When the third number is found, the red indicator
lamp (1) goes off.
5 - Check the programming
- For a television or a satellite receiver: turn on and
off, then try to change channels using a digit key (9).
- DVD player: load a DVD and then press PLAY (B)
(18).
Try other remote control keys to find out which
functions you can control. If you think that not all of the
keys are active, try the programming Method B or C.
When you have retrieved the code of your product,
make note of it.
After battery replacement, you may have to
programme the remote control again.
TV CODE
SAT CODE
DVD: DVD player,
DVD CODE
6 - Controlling volume in
satellite and cable mode
For satellite systems with a volume control, you can
choose the product that the MUTE (15) and VOL (4)
keys will control: the television volume or the volume
of the satellite or cable receiver.
To choose, proceed as follows:
1. Press the TV (2) key (the remote control must be
in TV mode for this procedure).
2. Hold down the SETUP (11) key until the red
indicator lamp (1) remains lit (the indicator light
remains on for a few seconds to give you the time
to proceed with the following steps. The indicator
lamp flashes when this time is almost up, and then
goes off).
3. Release the SETUP (11) key.
4. Press the MUTE (15) key for around 8 seconds.
The indicator light will blink and then go off for
about 8 seconds before blinking once more and
then staying off.
5. If the remote previously controlled the television
volume in SAT mode, it will now control the
volume of the satellite receiver; if it previously
controlled the volume of the satellite receiver, it will
now control the television volume.
7 - The NAVILIGHT system
The THOMSON NAVILIGHT navigation system allows you
easy access to the settings of your television set (TV) or your
video recorder (VCR) fitted with the THOMSON
NAVILIGHT system provided that you have allocated the
DVD or SAT keys to the video recorder.
1. Switch on the product you want to control.
2. Select the type of product concerned (TV, DVD or
SAT). In the DVD position, make sure that the AV
mode is activated for the TV set (the SCART socket
must be selected).
3. Press the SHIFT (3) key once and then press the
MENU (5) key.
4. To travel through the setting menus, press the up,
down, left, right keys (4 and 14).
5. Confirm with OK (15).
6. Exit the menus by pressing the EXIT (16) key.
Note:The SHIFT (3) key remains on as long as light I is
lit. If this light goes out, you have to press the SHIFT key
again before using the navigation keys. To exit this mode,
press SHIFT a second time.
ENGLISH - Do not mix different types of batteries or new and old
batteries. Do not use rechargeable batteries. In order to avoid any risk
of explosion, observe polarities indicated inside the battery
compartment. Replace only with the type of batteries specified above.
Do not throw them into fire, do not recharge them. If you are not using
the remote control for a long period of time, remove the batteries.
Please respect the environment and prevailing regulations. Before you
dispose of batteries or accumulators, ask your dealer whether they are
subject to special recycling and if they will accept them for disposal.
3
ROC 3205 / EN - pp - PB / abalis - rst / 07-2005
