Shop-Vac 984A Quick Start Manual

M M o o d d e e l l 9 9 8 8 4 4 A A
ITEM DESCRIPTION
1 #12 x 1 / " AB Ph pan head screw
2
2 Motor cover
3 Motor mounting plate
4 Motor mounting screw #8-10 x
5 Motor housing
6 #10 x 1 / " Hex head screw, type AB
2
7 Internal tooth lockwasher
8 Ground lead
9 Power Cord
10 Strain relief bushing
11 Handle package (includes
2 handles and hardware)
12 #10 x 3 / " Slotted hex head screw,
4
type AB
13 Switch
14 Exhaust fitting
15 Gasket O-ring
16 Retaining ring
17 Mid motor gasket
18 Ground screw
19 Wire nut
20 Motor
21 Grid plate
22 Ball float
23 Filter cage
24 Foam lid
25 #10 - 24 Washer base hex nut
26 #10 - 24 x 3 / " Hex head screw
8
27 Foam sleeve
28 Filter cage clip
29 #10 - 24 Hex nut
30 Full filter frame
31 Full polyester filter
32 High efficiency collection bag
33 Tank assembly for (15 gal.)
34 Clamp
35 Rivet
36 Inlet fitting
37 #10 x 5 / " Slotted hex screw
8
PART NO.
15050-99-0
99364-00-2
99360-10-9
5 / " PH 15917-00-8
8
98608-96-1
15061-99-7
23004-99-7
42228-96-5
04291-96-9
34004-99-4
93551-96-8
15039-99-3
82303-04-1
84600-00-6
83234-00-5
36002-99-6
56300-00-7
17008-99-6
05001-99-5
13496-97-1
89400-10-5
00811-00-0
87901-00-5
89878-00-3
13022-99-1
09003-99-7
90585-62-1
99384-00-0
13009-99-8
30037-00-6
90639-00-6
91907-10-5
10415-97-4
(15 gal. S/S) 10416-97-2
01403-00-5
03002-99-5
21720-01-6
15054-99-2
Catalog 984-01-10
984-02-10
6
7
8
9
10
11
12
16
17
18
20
21
23
24
25
27
34
35
Limited One-Year Warranty
Shop-Vac Corporation warrants all Industrial, Commercial, and
Contractor vacuum cleaners for one year from date of purchase to
correct by repair or parts replacement without charge any product
defect due to faulty material or workmanship, provided that the
vacuum cleaner is not used for rental service.
Standard Accessories:
12' (3.66 m) x 1 1 / " (3.81cm) Hose
2
(2) 1 1 / " (3.81cm) Metal extension wands
2
14" (35.56 cm) Metal master nozzle
14" (35.56 cm) Squeegee shoe
14" (35.56 cm) Brush shoe
14" (35.56 cm) Rug shoe
Hose carrier
(15 Gal.)
(15 Gal. s/s)
1
2
3
4
5
13
14
15
17
22
26
28
29
12
37
11
33
19
32
30
31
36
SC87516-69
