24"
Thank you for choosing Grain Wood Furniture, it is an honor to be in your home!
If you have any questions, feedback, or need replacement parts please contact us at:
grainwoodfurniture.com/help or
Montauk Collection
2-Drawer Nightstand
REV - 09/2021
Assembly Instructions
24"
support@grainwoodfurniture.com
16"
Made in Brazil
1-person assembly
Model #
Finish
MT0411
Rustic Walnut
MT0412
Rustic Off-White
MT0420
Rustic Grey
MT0424
Driftwood
PH #2
page 1/14
Advertisement
Related Manuals for GrainWood MT0411
Summary of Contents for GrainWood MT0411
- Page 1 Assembly Instructions 16" 24" 1-person assembly 24" PH #2 Model # Finish MT0411 Rustic Walnut MT0412 Rustic Off-White MT0420 Rustic Grey MT0424 Driftwood Thank you for choosing Grain Wood Furniture, it is an honor to be in your home! If you have any questions, feedback, or need replacement parts please contact us at: grainwoodfurniture.com/help or...
- Page 2 PLEASE READ BELOW BEFORE BEGINNING ASSEMBLY Enlist help from a friend or family member as most items require two Ÿ people for proper assembly. Choose a spacious, open area near where the piece will be located once Ÿ assembled. It is easier to move parts than to relocate the furniture after it is fully assembled.
-
Page 3: Hardware List
HARDWARE LIST ATTENTION 28 + 1 4x30 Before starting assembly 2 + 1 please verify the hardware set is complete. 3,5x16 4 + 1 For missing hardware please contact us at M4x22 grainwoodfurniture.com/help 16 + 1 WARNING: 6x10 CHOKING HAZARD Small parts, not for children. - Page 4 Description Qty. Part # Right side Left side Internal crosspiece Upper/ lower crosspiece Drawer front Drawer right side Drawer left side Drawer bottom Drawer back Back panel Hardware page 4/14...
- Page 5 Tip: Use a hammer in case dowels are hard to install by hand. 3,5x16 8x30 page 5/14...
- Page 6 Glide wheels should be positioned towards the front and bottom of the side panel. Need help? Scan the QR code. 6,0x10 RIGHT Side page 6/14...
- Page 7 Glide wheels should be positioned towards the front and bottom of the side panel. Need help? Scan the QR code. 6,0x10 LEFT Side page 7/14...
- Page 8 Attention: There are no predrilled holes for the A1 screws on part 4x30 4x30 Attention: There are no predrilled holes for the A1 screws on part 03. page 8/14...
- Page 9 4,0x30 Attention: There are no predrilled holes for the A1 screws on part 04. Attention: There are no predrilled holes for the A1 screws on part 07. 4,0x30 3,5x16 page 9/14...
- Page 10 4,0x30 Make sure back panels are perfectly aligned with side panels and top and there are NO gaps. û ü ü 10x10 page 10/14...
- Page 11 Make sure back panels are perfectly aligned with side panels and top and there are NO gaps. û ü 10x10 10x10 page 11/14...
- Page 12 Attention: There are no predrilled holes for the A1 screws on part 08. 4,0x30 page 12/14...
- Page 13 Flip the assembled drawer upside down to install glides. Need help? Scan the QR code. Drawer RIGHT Drawer LEFT 6,0x10 page 13/14...
- Page 14 M4x22 PZ04 page 14/14...
