Assembly Instructions
2-person assembly
47 ¼"
PH #2
Model #
Finish
MC0603
Brushed White
MC0605
Brushed Walnut
Thank you for choosing Grain Wood Furniture, it is an honor to be in your home!
If you have any questions, feedback, or need replacement parts please contact us at:
grainwoodfurniture.com/help or
support@grainwoodfurniture.com
Mid Century
King Bed
Made in Brazil
REV - 05/2022
page 1/10
Advertisement
Related Manuals for GrainWood MC0603
Summary of Contents for GrainWood MC0603
- Page 1 2-person assembly 47 ¼" PH #2 Model # Finish MC0603 Brushed White MC0605 Brushed Walnut Thank you for choosing Grain Wood Furniture, it is an honor to be in your home! If you have any questions, feedback, or need replacement parts please contact us at: grainwoodfurniture.com/help or...
- Page 2 PLEASE READ BELOW BEFORE BEGINNING ASSEMBLY Enlist help from a friend or family member as most items require two Ÿ people for proper assembly. Choose a spacious, open area near where the piece will be located once Ÿ assembled. It is easier to move parts than to relocate the furniture after it is fully assembled.
- Page 3 HARDWARE LIST 14 + 1 3,5x16 16 + 1 3,5x35 4 + 1 4,0x45 4 + 1 1/4" 1/4"110 7,0x70 1/4"50 24 + 2 10x40 ATTENTION WARNING: Before starting assembly For missing hardware please CHOKING HAZARD please verify the hardware contact us at Small parts, not for children.
- Page 4 Box A - 1 of 2 Box B - 2 of 2 Qty. Qty. Description Description Part # Part # Headboard Right headboard post Slat roll Left headboard post Right footboard post Left footboard post Footboard cross piece Headboard cross piece Side rail Center rail Center support...
- Page 5 Tip : Use a hammer in case dowels are hard to install by hand. 10x40 upper side Tip: Choose the side with the best finish quality to be the top of the footboard. 3,5x16 1/4"x50 page 5/10...
- Page 6 Attention: There are no predrilled holes for the A40 screws on parts 01 and 02. 3,5x16 1/4"x50 4,0x45 page 6/10...
- Page 7 3,5x16 page 7/10...
- Page 8 G8+B7 G8+B7 G8+B7 G8+B7 1/4" 1/4"x110 page 8/10...
- Page 9 G8+B19 G8+B19 G8+B19 G8+B19 G8+B19 G8+B19 7,0x70 Attention: There are no predrilled holes for the A9 screws on part 09. 3,5x16 page 9/10...
- Page 10 Attention: There are no predrilled holes for the A14 screws on parts 08. 3,5x35 page 10/10...
