Blue Giant BG-770D Operator's Manual & Parts List

Mobile lift table
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ACTUAL PRODUCT MAY NOT APPEAR EXACTLY AS SHOWN
WARNING
Do not operate or service this product unless you have
read and fully understand the entire contents of this
manual. Failure to do so may result in bodily injury or
death.
STARTING FROM MARCH 19, 2024 / SERIAL # 0.
OPERATOR'S MANUAL/PARTS LIST
BG-770D/BG-770DB MOBiLE LifT TABLE
ISSUE DATE: MARCH 19, 2024 REv. 1.1 (PART # 038-1217EO)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BG-770D and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Blue Giant BG-770D

Summary of Contents for Blue Giant BG-770D

  • Page 1 OPERATOR'S MANUAL/PARTS LIST BG-770D/BG-770DB MOBiLE LifT TABLE ACTUAL PRODUCT MAY NOT APPEAR EXACTLY AS SHOWN WARNING Do not operate or service this product unless you have read and fully understand the entire contents of this manual. Failure to do so may result in bodily injury or death.

  • Page 2: Table Of Contents

    BG-770D/BG-770DB MOBILE LIFT TABLE —OPERATOR'S MANUAL/PARTS LIST TABLE OF CONTENTS 1. SAfETY PROCEDURES 2. OWNER’S PURCHASE RECORD 3. EXCLUSiON Of LiABiLiTY 4. WARRANTY 5. CHECK SHiPMENT BEfORE ASSEMBLY AND/OR USE 1. RANGE Of USE 2. OPERATiON CONDiTiONS 3. BG-770D SPECifiCATiONS 4.

  • Page 3: Safety Procedures

    BG-770D/BG-770DB MOBILE LIFT TABLE —OPERATOR'S MANUAL/PARTS LIST 1. SAFETY PROCEDURES Do not operate this lift table unless you have been trained and authorized to do so. Do not operate this lift table until you have read and understood all of the safety information and instructions contained herein and on the lift table.

  • Page 4: Warranty

    Warranty Registration at www.bluegiant.com. For more information about Blue Giant Warranty Support, please contact your local Blue Giant Equipment dealer, representative or authorized partner near you. You may also visit www.bluegiant.com or phone 1.905.457.3900.

  • Page 5: Operation Conditions

    BG-770D/BG-770DB MOBILE LIFT TABLE —OPERATOR'S MANUAL/PARTS LIST improves working efficiency. 2. OPERATION CONDITIONS a. It should be operated on the solid and flat ground. b. The ambient temperature for operation should be -20~40°C. 3. BG-770D SPECIFICATIONS Specification / Model BG-770D...

  • Page 6: 770Db Specifications

    BG-770D/BG-770DB MOBILE LIFT TABLE —OPERATOR'S MANUAL/PARTS LIST 4. BG-770DB SPECIFICATIONS Model BG-770DB Maximum load capacity 350Kg (770 lbs) Dimension (mm) 1367×500×1101 Lifting height (h3) (mm) Minimum height (h13) (mm) Maximum height (h12) (mm) 1320 Handle height (h14) (mm) 1101 Platform size (l×b5×s) (mm) 910×500x56...

  • Page 7: Points For Attention

    BG-770D/BG-770DB MOBILE LIFT TABLE —OPERATOR'S MANUAL/PARTS LIST 5. POINTS FOR ATTENTION Don’t overload the lift table and it should be used within the rated load. Do not stand or sit on the platform when working. Do not put your hands or legs under the platform.

  • Page 8: Operating Instructions

    Always clean all side openings of dirt and debris. • Always clean up dry and liquid spills immediately after they occur. • If a procedure is not clearly defined in this manual, contact your Blue Giant Dealer. Manual Hydraulic Raising the table verify that the brake is engaged.
  • Page 9 BG-770D/BG-770DB MOBILE LIFT TABLE —OPERATOR'S MANUAL/PARTS LIST Lowering the table Lift the handle knob upward slowly, and open the one-way valve to make the working table descend slowly. Release the brake before moving the lift table. Brake operation Do not raise nor lower table without brake in operation. Do NOT put any part of the foot and body on the brake.

  • Page 10: Maintenance And Servicing

    Failure to properly secure the mobile lift table prior to working underneath it may result in bodily injury or death. • Engage the Maintenance Strut before working. If it cannot be successfully engaged, contact your Blue Giant Dealer. WARNiNG •...

  • Page 11: Troubleshooting

    BG-770D/BG-770DB MOBILE LIFT TABLE —OPERATOR'S MANUAL/PARTS LIST tightness of the electric terminals. If there is any looseness, tighten the electric terminals before charging. The charging voltage is 220v single-phase AC. If there is any deformation and bending on every parts of the lift table.
  • Page 12 BG-770D/BG-770DB MOBILE LIFT TABLE —OPERATOR'S MANUAL/PARTS LIST BG-700DB Final Assembly 12 ISSUE DATE: MARCH 19, 2024 REv. 1.1 (PART # 038-1217EO)
  • Page 13 BG-770D/BG-770DB MOBILE LIFT TABLE —OPERATOR'S MANUAL/PARTS LIST BG-700DB Final Assembly Description Description Handle assembly Circlip for axle 16 inner hexagon screw M5×10 Table Door inner hexagon screw M6×12 Diverter tiein Spring washer 6 H.P . oil pipe L-pin roll Cushion...

  • Page 14: 770D Hardware

    9. BG-770D HARDWARE Foreword Usage This section lists the components of BG-770D hydraulic double scissor lift table, including its handle, lift table frame, fork arm, jack and so on. How to book a component When you need to book any component, you should specify in your order the lift table model, series number, quantity, part material number, and the name of the component.
  • Page 15 BG-770D/BG-770DB MOBILE LIFT TABLE —OPERATOR'S MANUAL/PARTS LIST GB-770D General Assembly item NO. Part NO. Part name Specification Q’ty 31070201028 Knob assembly 1340 (1135) 31020207008 Pedal rod assembly 0908420264 Screw M12X30 0908370015 Washer 12 31010206010 Washer 0908420031 Screw M8X25 0908350013 Washer 8...
  • Page 16 BG-770D/BG-770DB MOBILE LIFT TABLE —OPERATOR'S MANUAL/PARTS LIST item NO. Part NO. Part name Specification Q’ty 0905060004 Wheel nylon core PU (Standard Configuration) nylon core PU 0905020104 Wheel iron core PU (Optional) iron core PU 0909030017 Trimming matching iron core PU (Optional)
  • Page 17 BG-770D/BG-770DB MOBILE LIFT TABLE —OPERATOR'S MANUAL/PARTS LIST Knob Assembly Part# 31070201028 item NO. Part NO. Part name Q’ty 1132450002 Handle assembly 31050302008 Guard plate for EU type (safe type) Not provided 0908500038 Pin 6X30 0909170004 Knob 0909180026 Shaft ISSUE DATE: MARCH 19, 2024 REv. 1.1 (PART # 038-1217EO)
  • Page 18 BG-770D/BG-770DB MOBILE LIFT TABLE —OPERATOR'S MANUAL/PARTS LIST Pedal Rod Assembly Part# 31020207008 item NO. Part NO. Part name Q’ty 0904120002 Sleeve 0906230097 Pedal rod 0908420034 Screw M8X35 0908350013 Washer 8 0908370011 Washer 8 0908030013 Nut M8 0904120004 Crash pad 31020207018...
  • Page 19 BG-770D/BG-770DB MOBILE LIFT TABLE —OPERATOR'S MANUAL/PARTS LIST item NO. Part NO. Part name Specification Q’ty Upper cover plate Steel ball 8 Oiler M6 Wheel carriage assembly Steel ball 1/4 Lower raceway plate 0905080005 (Provided in whole) Screw M16X25 Nut M16...
  • Page 20 BG-770D/BG-770DB MOBILE LIFT TABLE —OPERATOR'S MANUAL/PARTS LIST Lower fork Arm Assembly Part# 31020204002 item NO. Part NO. Part name Q’ty 0907040014 Bearing Sf-1-16.12 0907040090 Bush 31020201064 Lower fork arm welding 0909040019 Lock catch 0908280012 Screw M5X8 1199400039 Support rod 0909030007...
  • Page 21 BG-770D/BG-770DB MOBILE LIFT TABLE —OPERATOR'S MANUAL/PARTS LIST Jack Assembly Part# 310302008 item NO. Part NO. Part name Specification Q’ty 1109400003 Hood 0902060018 Seal ring 32X45X6 0902050059 O-ring 31.5X3.55 0901120023 Screw 0902050011 O-ring 7.5X2.65 1131400004 Sleeve 1113400004 Oil cylinder 0901010049 Piston rod...
  • Page 22 BG-770D/BG-770DB MOBILE LIFT TABLE —OPERATOR'S MANUAL/PARTS LIST item NO. Part NO. Part name Specification Q’ty 31030401271 Damping valve aperture specification 0.8 0902010009 Washer 20 0901120015 Screw 0907010015 Steel ball 3/8 0903130012 Spring 0907010021 Steel ball 1/2 0908220005 Screw M16X18 0907010009...

  • Page 23: 770Db Hardware

    BG-770D/BG-770DB MOBILE LIFT TABLE —OPERATOR'S MANUAL/PARTS LIST 10. BG-770DB HARDWARE Foreword Usage This section lists the components of BG-770DB electric double scissor lift table, including its handle, lift table frame, fork arm, jack and so on. How to book a component When you need to book any component, you should specify in your order the lift table model, series number, quantity, part material number, and the name of the component.
  • Page 24 BG-770D/BG-770DB MOBILE LIFT TABLE —OPERATOR'S MANUAL/PARTS LIST GB-770DB General Assembly item NO. Part NO. Part name Specification Q’ty Brake 31060201152 nylon core 31070201022 Universal wheel assembly standard configuration PU standard configuration iron core PU 31070201023 Universal wheel assembly optional optional...
  • Page 25 BG-770D/BG-770DB MOBILE LIFT TABLE —OPERATOR'S MANUAL/PARTS LIST item NO. Part NO. Part name Specification Q’ty 0908350021 Washer 12 31050402001 Shaft 0905060004 Wheel (standard configuration) nylon core PU 0905020104 Wheel (optional) iron core PU 0907020004 Bearing 6203-2RS 0909020002 Bush 0906230011 Shaft...
  • Page 26 BG-770D/BG-770DB MOBILE LIFT TABLE —OPERATOR'S MANUAL/PARTS LIST Universal Wheel Assembly Part# 31070201022 nylon core PU standard configuration or Part# 31070201023 iron core PU optional item NO. Part NO. Part name Specification Q’ty Upper cover plate Steel ball 8 Oiler M6...
  • Page 27 BG-770D/BG-770DB MOBILE LIFT TABLE —OPERATOR'S MANUAL/PARTS LIST Oil Cylinder Assembly Part# 31030401272 item NO. Part NO. Part name Specification Q’ty 0907040016 Bearing Sf-1-16.16 0902040025 Dust ring DHS40-48-5/6.5 0902030034 Seal ring UHS40-50-6 31060501084 Guide tape BST5918-18-2.5 Ø43 0902050094 O-ring 54.5X3.55 0901010063...
  • Page 28 BG-770D/BG-770DB MOBILE LIFT TABLE —OPERATOR'S MANUAL/PARTS LIST Lower fork Arm Assembly Part# 31020402003 item NO. Part NO. Part name Q’ty 51030503018 Lower fork arm welding 0907040014 Bearing Sf-1-16.12 0907040024 Bearing Sf-1-20.12 0908360004 Washer 16 0907040019 Bearing Sf-1-16.24 31050402010 Pulley 28 ISSUE DATE: MARCH 19, 2024 REv. 1.1 (PART # 038-1217EO)
  • Page 29 BG-770D/BG-770DB MOBILE LIFT TABLE —OPERATOR'S MANUAL/PARTS LIST Upper fork Arm Assembly Part# 31020402006 item NO. Part NO. Part name Q’ty 907040024 Bearing Sf-1-20.12 0907040014 Bearing Sf-1-16.12 51030503019 Upper fork arm welding 0908360004 Washer 16 0907040019 Bearing Sf-1-16.24 31050402010 Pulley ISSUE DATE: MARCH 19, 2024 REv. 1.1 (PART # 038-1217EO)
  • Page 30 BG-770D/BG-770DB MOBILE LIFT TABLE —OPERATOR'S MANUAL/PARTS LIST Electric Part Box Assembly Part# 51030503015 item NO. Part NO. Part name Q’ty 31020401006 Casing assembly 0908030013 Nut M8 0908350013 Washer 8 0908370011 Washer 8 31050401028 Platen 061325023 Oil pipe 061309050 Joint 0602323...
  • Page 31 BG-770D/BG-770DB MOBILE LIFT TABLE —OPERATOR'S MANUAL/PARTS LIST Electrical System item NO. Part NO. Part name Q’ty 060701530 instrument 060907025 Emergency stop button switch TN3BKR-1C 060902016 Button switch LAY40-10MU 060902017 Button switch LAY40-10MD 0606078 Charger 0908280059 Screw M4X12 0908350008 Washer 4...
  • Page 32 Corporate 410 Admiral Blvd USA 9201 National Turnpike Mississauga, ON, Canada L5T 2N6 Louisville, KY 40118 t 905.457.3900 f 905.457.2313 www.bluegiant.com If calling within North America: t 1.800.872.2583 f 1.888.378.5781 © Copyright Blue Giant Equipment Corporation 2024...
