Table of Contents
1.
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
2.
Carton Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
3.
Tools and Materials Required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
3.1
Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
3.2
Materials . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
4.
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Rack or Frame Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
4.1
4.2
Install Trunk Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
4.2.1
Trunk Cable Placement with the Pulling Grip . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
4.2.2
Pulling Grip Removal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
4.3
(OPTIONAL) Install CDF Bracket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
4.4
Mount Trunk Cables in the Housing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
4.4.1
Installation of Trunk Cable Using Keyhole Cradle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
4.5
Install EDGE Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
4.5.1
Into EDGE-01U-FP, EDGE-02U-FP and EDGE-04U-FP Housings . . . . . . . . . . . . . . . . 8
4.5.2
Connect Jumpers to EDGE Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
4.6
Install MTP® Adapter Panels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
4.6.1
4.6.2
Trunk to the front of MTP Adapter Panels -Initial Mating . . . . . . . . . . . . . . . . . . . . . . 13
5.
Record Keeping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
5.1
Hardware Labeling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
5.2
Cable/Jumper Labeling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
6.
Troubleshooting and Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
6.1
Replace EDGE Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
6.2 Remove Trunk Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
6.2.1
Cable in Keyhole Cradle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
6.3
Changing the Polarity of an LC Uniboot Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
6.4
Changing the Polarity of an MTP Adapter and Connector . . . . . . . . . . . . . . . . . . . . . . . . 21
6.5
Connector Care and Cleaning - Post Initial Mating . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
EDGE™ Solution
EDGE Secure Solutions FTTD Module
EDGE and EDGE8® Fiber Zone Boxes
EDGE Port Replication Housing
Field Tool For MTP® PRO® Connectors Quick Start Guide
EDGE and EDGE8 Solution Single Module Housing
EDGE Solution Single Module Housing for Splicing
EDGE Splice Cassette/EDGE Field-Terminated Cassette
EDGE Solution Modules in an Enhanced Management Frame
STANDARD RECOMMENDED PROCEDURE 003-888-AEN | ISSUE 8 | APRIL 2020 | PAGE 1 OF 21
EDGE
Solution with
TM
1U/2U/4U Fixed Trays
003-888-AEN, Issue 8
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for CORNING EDGE Solution EDGE-01U-FP
Summary of Contents for CORNING EDGE Solution EDGE-01U-FP
-
Page 1: Table Of Contents
EDGE Solution with 1U/2U/4U Fixed Trays 003-888-AEN, Issue 8 related literature |Search www.corning.com/opcomm. Click on “Resources.” 003-794-AEN EDGE™ Solution 000-276-AEN EDGE Secure Solutions FTTD Module 003-825-AEN EDGE and EDGE8® Fiber Zone Boxes 003-991-AEN EDGE Port Replication Housing 006-407-QSG-AEN Field Tool For MTP® PRO® Connectors Quick Start Guide... -
Page 2: General
General This document describes installation of the EDGE™ 1U/2U/4U Fixed Tray Housing Solutions. Except where installation of another housing is unique, only the 4U housing is illustrated. Carton Contents • EDGE housing, either 1U, 2U, or 4U rack-height (Figure 1) •... -
Page 3: Install Trunk Cables
4 .2 Install Trunk Cables The EDGE™ Trunk Cable is supplied with factory-installed protection/pulling grips (Figure 3) to protect the connectors and their fibers by coupling the pulling load back to the cable. The cradle is used to install the furcation plug into the housing. Figure 3 —... -
Page 4: Trunk Cable Placement With The Pulling Grip
4 .2 .1 Trunk Cable Placement with the Pulling Grip NOTE: This procedure assumes that a pull line has been placed in the duct route and that the equipment necessary to maintain the bend- radius of the pulling grip is in position. Step 1: If necessary, remove the corrugated reel from its protective... -
Page 5: Optional) Install Cdf Bracket
Step 5: Slowly slide the tubing away from the coupler and its connector legs (Figure 8). Figure 8 — Tubing Removal Step 6: Use the tabs on the furcation end of the coupler to separate the coupler’s two halves. Step 7: Remove the coupler halves from the trunk furcation body and dispose of the coupler assembly (Figure 9). - Page 6 CDF brackets support use of extender trunks. If using an IBU (vertical manager) between frames, extender trunks mounted to the CDF bracket on the back side of the frame must transition to the front using a “pass-through” IBU system. Step 1: Align bracket within the same height of the 4U housing.
-
Page 7: Mount Trunk Cables In The Housing
4 .4 Mount Trunk Cables in the Housing 4 .4 .1 Installation of Trunk Cable Using Keyhole Cradle Step 1: Open cradle provided inside the reel and press each trunk cable furcation plug into cradle (Figure 12). Figure 12 — Install Trunk Cables with Keyhole Cradle Step 2: Install trunk backplate into housing. -
Page 8: Install Edge Modules
Step 1: Remove the MTP® connector dust cap by pulling on the dust cap while holding the connector body. For the initial mating, do not clean or scope connectors. Corning® CleanAdvantage™ connectors are shipped with an optimized dust cap to maintain cleanliness for the first use. - Page 9 EDGE Module Installation Figure 13 — Load EDGE Modules Figure 14 — Capture Slack with Straps Step 7: Next, install the removable rear cover over the back deck as illustrated in Figure 15. Figure 15 — Install Rear Cover STANDARD RECOMMENDED PROCEDURE 003-888-AEN | ISSUE 8 | APRIL 2020 | PAGE 9 OF 21...
-
Page 10: Connect Jumpers To Edge Modules
(see page 8, Figure 12A). For the initial mating, do not clean or scope connectors. Corning CleanAdvantage connectors are shipped with an optimized dust cap to maintain cleanliness for the first use. NOTE: Only LC connectors are shown in Figure 16. -
Page 11: Connecting Mtp Trunk Cable To Rear Of Mtp Adapter Panel - Initial Mating
4 .6 .1 Connecting MTP® Trunk Cable to Rear of MTP Adapter Panel — Initial Mating Figure 17 — Install MTP Trunk Cables into Adapter Panel STANDARD RECOMMENDED PROCEDURE 003-888-AEN | ISSUE 8 | APRIL 2020 | PAGE 11 OF 21... - Page 12 Keep dust caps in place on the front of the adapter panel, if applicable. CAUTION: Scoping Corning CleanAdvantage connectors increases the risk of adding contamination to the system. CleanAdvantage technology is designed for mating connectors without cleaning or scoping before the initial installation.
-
Page 13: Connecting Harnesses, Mtp Jumper, Mtp Conversion Harnesses, Or Extender
MTP connector of the harness, jumper, or trunk by pulling on the dust cap while holding the connector body/housing/shroud. (See page 8, Figure 12A) For initial mating, do not clean or scope connectors. Corning CleanAdvantage™ connectors are shipped with an optimized dust cap to maintain cleanliness for the first use. -
Page 14: Record Keeping
Step 4: Route the connected cable either to the right or to the left of the housing. All cables should route in the same direction. Do NOT cross cables in opposite directions. Store the cables or legs in the fiber clips at the front of the tray. Close the tray. Step 5: Mate connectors at the end of the harness, jumper, or trunk in the electronics equipment as illustrated in Figure 22 per instructions provided with that equipment or... - Page 15 • Front door of the housing/chassis has a locating crop mark suggesting a consistent location for the printed identification (ID) label that identifies the location of the chassis within the frame or cabinet. • Module positions within each chassis tray are identified by alphabetical characters A through D from left to right.
- Page 16 Step 1: Frame/Cabinet Location (Figure 24) Identify location of Frame or Cabinet within the floor space grid coordinate system. Preprint labels and adhere to Front and Back of Frame or Cabinet at top and bottom. Figure 24 — Frame/Cabinet Label Location Step 2: Housing/Chassis Location (Figure 25) Identify location within the Frame or Cabinet (in rack units from the bottom) by...
- Page 17 Step 3: Tray Location (Figure 26) Identify location of tray within the housing/chassis. Trays come pre-labeled 01 to 12 from the bottom to the top of the chassis. Figure 26 — Tray Label Location Step 4: Module Location with Fiber or Port Range (Figure 27) Each tray comes pre-labeled A through D to identify Module position within the tray.
-
Page 18: Cable/Jumper Labeling
Step 5: Documentation (Figure 28) Identify remote location termination and determine code to be printed. It should only be necessary to print the remote location. Printed code from label makers may be affixed to the label card on the inside of the front door. Figure 28 —... -
Page 19: Troubleshooting And Maintenance
Troubleshooting and Maintenance 6 .1 Replace EDGE™ Module Step 1: Open front door. Step 2: Press latch on LC connector and pull connector out (Figure 29). If jumper is equipped with MTP connector, simply grasp connector body and pull connector out of the adapter. -
Page 20: Remove Trunk Cable
6 .2 Remove Trunk Cable 6 .2 .1 Cable in Keyhole Cradle If necessary to replace trunk cable or keyhole cradle, remove per the directions in this section (Figure 30). Install new cable or cradle per the directions in Section 4.4. Step 1: Pull back on both latches while pushing cradle in opposite direction. -
Page 21: Changing The Polarity Of An Mtp Adapter And Connector
A complete listing of the trademarks of Corning Optical Communications is available at www.corning.com/opcomm/trademarks. All other trademarks are the properties of their respective owners. Corning Optical Communications is ISO 9001 certified. © 2011, 2016, 2020 Corning Optical Communications.
