- Page 1 MobileAccess1000 DAS System Installation and Configuration Guide P/N: 709C001504 REV: A0 Date: AUG, 2012...
- Page 2 Preface Corning MobileAccess 8391 Old Courthouse Road, Suite 300, Vienna, VA 22182 Tel: +1(866)436-9266, +1(703)848-0200 TAC: +1(800)787-1266, Fax: +1(703)848-0280 www.corning.com/mobileaccess MA1000 Installation and Configuration Guide...
-
Page 3: Rf Safety
Compliance with RF Safety Requirements · Corning MobileAccess products have no inherent significant RF radiation · The RF level on the down link is very low at the Remote Hub Unit (RHU) downlink ports. Therefore, there is no dangerous RF radiation when the antenna is not connected. -
Page 4: Care Of Fiber Optic Connectors
Preface Care of Fiber Optic Connectors · Do not remove the protective covers on the fiber optic connectors until a connection is ready to be made. Do not leave connectors uncovered when not connected. · The tip of the fiber optic connector should not come into contact with any object or dust. ·... -
Page 5: Standards And Certification
Preface Standards and Certification Corning MobileAccess products have met the approvals of the following certifying organizations: Product Certifications FCC 47 CFR part 15B, 22, 24, 90,27 NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. -
Page 6: About This Guide And Other Relevant Documentation
Preface About this Guide and Other Relevant Documentation This user guide describes how to perform the physical installation of the MA 1000 system. The installation procedures of other units (RIU, 860 WLAN solution) relevant to the system are Additional Relevant Documentation detailed in their user manuals (see below). -
Page 7: Table Of Contents
Preface Table of Contents Preface Material ........................III Installation Safety ..........................III RF Safety ............................III Compliance with RF Safety Requirements ................... III Laser Safety ............................. III Care of Fiber Optic Connectors ......................IV Power Requirements for DC Inputs ....................IV Standards and Certification ......................... - Page 8 Preface 3.3.3 RF Rules .......................... 14 3.4 Power Consumption, Connections and Power Supplies ..............14 3.4.1 Power Safety Instructions ....................14 3.4.2 Power Consumption of Units ..................... 15 3.4.3 Circuit Breakers ........................ 15 3.4.4 Types of Power Supplies ....................15 3.5 Installation Conventions ......................
- Page 9 Preface MA1000 TSX ..........................33 Base Units ..........................33 Remote Hub Unit Modules ......................34 Add-On Modules ........................34 Power Supply Accessories ......................35 Mounting Bracket Accessories ..................... 35 MA1000 Installation and Configuration Guide...
-
Page 10: Introduction To Ma1000 System
About MA1000 The MA1000 provides enterprise level indoor coverage for a wide range of wireless services over a single broadband infrastructure. The MA1000 is a single operator, multi-band system based on combining a number of services, voice and data, and distributing them to each remote location through a common antenna infrastructure. - Page 11 Introduction to MA1000 System 860 WLAN Solution – The 860 and WCE is a wireless LAN module that provides secure · and centralized connections for 802.11a/b/g Access Points and distributes the wireless services over the same coax and broadband infrastructure as the voice services. All services are combined and distributed through the same antenna broadband infrastructure.
-
Page 12: Configuration Options
Introduction to MA1000 System Configuration Options The MA1000/Add-on system includes three basic configuration options: A) Basic configuration The Base Unit drives a single or dual band, MA 1000 RHU. The dual band RHU consists of a low band service (cellular 800, iDEN, Paging, or GSM 900) and a high band service (PCS 1900 or DCS 1800). -
Page 13: Management
MCT – a Java based GUI application provided with both controllers. MCT is used with · the 410 and 430 after the installation procedure to adjust Corning MOBILEACCESS devices according to the installation site characteristics in order to optimize coverage for the site. -
Page 14: System Elements
This chapter describes the MA1000 system basic elements: remote modules (1000 RHU and Add- on) and the Base Units. Your system may include additional elements such as 410, 430 and SC- 450 controllers, RIUs and 860 WLAN solution units; these are described in the corresponding User Guides. -
Page 15: 1000 Rhu Front Panel
Preface Material 2.1.1.1 1000 RHU Front Panel The 1000 RHU front panel contains the fiber optic connections to the BU, four coax connections to the antennas, power connections and status indicators. If 1000 RHU and Add-on units are installed, then the combined services are fed to the coax 1000 RHU antenna ports infrastructure through the . -
Page 16: Ma1000 Rhu Rear Panel
DL to DL, UL to UL. 2.1.2 Add-on The Corning MOBILEACCESS Add-on module is a high power module, supporting a single 1000 RHU frequency band (low or high). It is designed to be integrated with a host module. The 1000 RHU module provides the following functionality for both units: ·... -
Page 17: Add-On Front Panel
MA service personnel). LEDs Power connector MA service connector Figure 7. RHU Add-on Front panels Table 2-3. Corning MOBILEACCESS Add-on Front Panel Indicators Description When blinking, indicates that the RHU is in normal operating mode. Power ON 2.1.2.2 Add-on Rear Panel The RHU Add-on rear panel contains the connections to the 1000 RHU and 860. -
Page 18: Base Units
Preface Material Table 2-4. RHU Add-on Rear Panel Connectors Add-on Control Transmits the control signals between the Add-on module and the 860 and 1000 RHU modules: · From – receives control signals from the 1000 RHU. Connected to the 1000 RHU Add-on Control connector. ·... -
Page 19: Bu Front Panel
Preface Material 2.2.1.1 BU Front Panel The front panel contains the optical connections and indicators. The BU is available in two configurations: Four-port - and Eight-port BUs. The eight-port BU consists of two four-port elements where each four-port element has a dedicated set of indicators (PWR, LSR and Link 1 to Link 4 or Link 5 to Link 8). -
Page 20: Bu Rear Panel
Preface Material 2.2.1.2 BU Rear Panel The BU rear panel contains the RF, NMS, and power connections. Note that there are two uplink and two downlink RF connections to the BTS side (to an Interface Box or RIU) - each individual uplink and downlink connection corresponds to a four-port BU element. -
Page 21: Site Preparation
Preface Material Infrastructure Preparation This following installation rules are based on the assumption that site survey and installation including power requirements planning ( ) have been completed. Installation Requirements The infrastructure preparation consists of two main phases: A. Floor Planning: Planning the distribution of the antennas on each floor to provide the required coverage. -
Page 22: Fiber Optic Rules
Preface Material 3.3.2 Fiber Optic Rules · Either single mode or multimode fiber can be used with Corning MOBILEACCESS 1000M products, while Corning MOBILEACCESS 1000 products can only be used with single mode fiber. · Only Multimode fiber, 50/125 or 62.5/125um complying with ANSI/TIA/EIA-568-B series, EN50173-1 or ISO/IEC 11801 can be used. -
Page 23: Rf Rules
Use coax RG223, 50ohm, male-to-male N-type for RF connections from the BUs to the BTS/RBS and to the RIU. When using the Corning MOBILEACCESS system in an environment in which other indoor · coverage systems are installed, it is recommended (where possible) that the antennas... -
Page 24: Power Consumption Of Units
2A circuit breaker. 3.4.4 Types of Power Supplies Corning MobileAccess supplies various power supplies that can be installed in a rack or mounted on a wall, depending on your configuration. Installation Conventions Some of the basic installation conventions are listed below for the 1000 system: Base Units –... - Page 25 Preface Material of strands coves floors 1, 2 and 3; the next group will cover floors 4, 5 and 6 through an additional splice box. Figure 12. Illustration of Fiber Optic Routing For remote power supply configuration - cable bundles are routed from the main ·...
-
Page 26: System Installation
By understanding the two generic installations you will be able to address any variations in system deployment. Communication Room Installation It is recommended to install the following Corning MOBILEACCESS system modules in a 19” rack in the communication room ·... -
Page 27: Rack Installation General Instructions
Verify that the rack height can support all the units to be installed, where you may also want to consider future expansions. Figure 13 shows the recommended physical location of the Corning MOBILEACCESS elements in connections. the rack in order to facilitate and simplify the cabling The configuration is for a single operator. -
Page 28: Rack Installation Safety Instructions
Preface Material 4.2.2 Rack Installation Safety Instructions Review the following guidelines to help ensure your safety and protect the equipment from damage during the installation. · Only trained and qualified personnel should be allowed to install or replace this equipment. ·... -
Page 29: Multi-Building Rack Installation
Preface Material 4.2.4 Multi-Building Rack Installation The figure below provides an example of a multi-building solution which distributes two bands from a main site over two remote sites up to 20Km away. The 330 units extend the RF signal from the Main to the Remote buildings over a single strand of fiber. Uplink and downlink signal are placed on the single fiber at 1310 and 1550 respectively. -
Page 30: Riu Connections
Preface Material 4.2.5 RIU Connections Refer to the RIU Products Installation and Configuration Guide for detailed instructions on connecting the RIU model in your installation. 4.2.6 BU Connections NOTE: It is assumed that the patch panel cabinet (SC/APC adaptors) for fiber optic cable connections is installed in the rack near the BUs. -
Page 31: Remote Site Installation
Preface Material Remote Site Installation 4.3.1 MA1000 RHU Installation Mount and install each RHU on the wall in the communication shaft or communication room. The following provides the dimensions for the RHU unit. Figure 16: MA1000 RHU Dimensions MA1000 Installation and Configuration Guide... -
Page 32: Wall Mount
Preface Material 4.3.1.1 Wall Mount MA1000 RHU is usually mounted on a wall in a clean indoor environment – RF ports facing down. Assembly instructions 1. Place the unit against the wall and mark the four holes to be drilled in the wall. 2. -
Page 33: Add-On Installation
Preface Material 4.3.2 Add-on Installation The following figure provides the dimensions for the Add-On unit. Figure 18. Add-On Dimensions MA1000 Installation and Configuration Guide... -
Page 34: Assembly And Connections
Preface Material 4.3.2.1 Assembly and Connections Refer to Figure 19. ATTENTION! To prevent damaging the SMA connectors, be sure to tighten using a torque of 8lb. 1. Position the supplied bracket on the 1000 RHU and secure the bracket to the 1000 RHU using the four supplied 6-32 NC screws. -
Page 35: 860 Wlan Solution Installations
Preface Material Figure 20. RHU Add-on to 1000 RHU Completed Assembly 4.3.3 860 WLAN Solution Installations Refer to the corresponding User Manual for detailed instructions on installing the unit. 4.3.4 Antenna Connections without For systems the 860 WLAN solution modules - connect the antenna connections ·... -
Page 36: Appendix A: System Specifications
Appendix A: System Specifications RF Frequency Ranges Band Uplink Downlink Low Band Services LTE SISO* 698-716 728-757MHz 777-787MHz CELL 824-849 869-894 Telstra 850M 824-849 869-890 iDEN (SMR800) 806-824 851-869 890-915 935-960 E-GSM 880-915 925-960 896-902 929-941 iDEN SMR900/Paging High Band Services 1710-1785 1805-1880 1850-1910... -
Page 37: Rf Parameters Per Service
Appendix A: System Specifications RF Parameters per Service Low Band Services MA1000 RF Parameters - Low Band Services CELL TDMA / GSM / LTE 700 MHz CDMA / WCDMA / SMR 800 SMR 900 E-GSM RF Parameter GSM800 Max Output Power / Antenna Port 1 (Composite) 2 Carriers... -
Page 38: High Band Services
Appendix A: System Specifications High Band Services MA1000 RHU RF Parameters - High Band Services UMTS and G-PCS G-PCS CDMA / GSM / MA1000 RHU CDMA/WCDMA GSM/TDMA WCDMA TDMA CDMA/WCDMA RF Parameter Max Output Power / Antenna Port 1 (Composite) 2 Carriers 4 Carriers 8 Carriers... -
Page 39: Optical Specifications
· All Bulkhead adapters must be single mode SC/APC (Green) adapters · All terminations, cross connections or patches must be direct fusion splice or one of the Corning MOBILEACCESS cords listed below 900 micro patchcord for splicing, 2 meters, 2xSC/APC 62.5/125/900... -
Page 40: Ma1000 Component Specifications
Appendix A: System Specifications MA1000 Component Specifications Base Unit Models: 4-port; 8-port model Supported Services: Wideband device supporting all services supported by MA systems Power: Input power 20 to 48V DC Power 14W (8-port BU) Consumption RF Connections: N-Type Female, 50 ohm – interface to RIU or to passive BTS Interface Optic Connections: Four or eight (depending on the model) SC/APC optic connections Remote Management Controller:... -
Page 41: Add-On
Appendix A: System Specifications Add-On Supported Services: Single service corresponding to the model Power: Input power: 25-48VDC Power Consumption: RF Connections: To RHU: SMA 50 ohm Remote Management: SNMP, NMS via RHU connection Physical Characteristics: (WxDxH) 10.98” 8.66” 2.71” Dimensions (278.9x219.9x68.8mm) 6.17 lb Weight:... -
Page 42: Ordering Information
Appendix A: System Specifications Ordering Information MA1000 QSX Supported Part Number Description Services MA1000 Quad-service package supporting CELL, PCS, CELL/PCS/700 1000-C85P19L70A17-A 700 MHz LTE and AWS. LTE/AWS MA1000 Quad-service package supporting CELL, PCS, 1000M-C85P19L70A17-A 700 MHz LTE and AWS with MMF. MA1000 TSX Supported Part Number... -
Page 43: Remote Hub Unit Modules
Appendix A: System Specifications Remote Hub Unit Modules Part Number Description 1000-CELL-4E Single band CELL, 4 ports, PCS Add-on support 1000-PCS-4E Single band PCS, 4 ports, AWS Add-on support 1000-DCS-4E Single band DCS, 4 ports, UMTS Add-on support 1000M-DCS MMF Single band DCS, 4 ports, UMTS Add-on support 1000-CELL-PCS4E-HL Dual band CELL/PCS, 4 ports, AWS Add-on support 1000M-CELL-PCS4E-HL... -
Page 44: Power Supply Accessories
Appendix A: System Specifications Power Supply Accessories Part Number Description LPS-48V-66W Local AC/DC Converter 66W LPS-48V-100W Local AC/DC Converter 100W AC Power Cord for 66W and 100W Power Supplies, European AK-PWR-CORD-EU Connector AK-PWR-CORD-UK AC Power Cord for 66W and 100W Power Supplies, UK Connector Mounting Bracket Accessories Part Number Description...
