Adjusting the Tape Position

If you find that your tape is not lining up with the center of the box seems you can use the M18
nut shown in figure 6 to reposition the tape.
1. Remove the tape roll.
2. Loosen the nut.
3. Thread the tape spindle in or out to move the tape to the left or right on the arm.
4. Tighten the M18 nut into place when you have set the desired position.

Setting the Tape Tension

The tape applicators will come to
you already adjusted. You may
find that over time the tension
needs to be adjusted.
To loosen or tighten the tension
of the tape applicators use the
nut on the end of the tension rod.
Turn the nut right to tighten the
spring and to the left to loosen.
www.sneedcoding.com
Figure 6
10
| (833)926-3464
M18 Nut
Tape positioning bolt
| support@sneedcoding.com
Tension Rod
Tape applicator /
roller
