- Page 1 USER GUIDE SNEED-JET Titan T6 Series Sneed Coding Solutions 22315 Gosling Rd. Spring TX, 77389 833-926-3464 x2 www.sneedcoding.com support@sneedcoding.com...
- Page 2 To schedule a call: Click to schedule a call Help desk and support videos: Click to visit our help desk...
- Page 3 OUR MISSION: Sneed Coding Solutions was founded with the belief that coding and marking should be simple. Our team of experts is focused on making the complex coding and marking process easy so that you can focus on the things important to you. We are here and available to speak with you whenever the need arises.
-
Page 4: Table Of Contents
Table of Contents Table of Contents ............................3 Printer Introduction ............................4 Message Creation (Edit) ..........................6 Text ................................6 Video Instructions: ..........................6 Time & Date .............................. 6 Video Instructions: ..........................6 Counter ..............................7 Video Instructions: ..........................7 Importing Images ............................ -
Page 5: Printer Introduction
Printer Introduction Welcome and thank you for your purchase of the SNEED-JET Titan T6 printer. This manual will only briefly cover each topic and is meant to be used with the video links in each section. This section of the user guide will give you a brief overview of the printer and its menu screens. - Page 6 Counter – the counter menu will allow you to set the behaviors of your counters as well as view the total print count. Power – Use the power button every time you wish to power the unit down Edit – use this to create messages (edit single file), link multiple messages to print in succession (edit group file), or to make minor edits to images (edit Image) Settings –...
-
Page 7: Message Creation (Edit)
Message Creation (Edit) Text To insert text into your message, select “Text” first. Underneath the print window you will see the “Edit” button, select it to show the keyboard. Once you have entered your text select “finish” to finalize it. Video Instructions: How to program text into your message Time &... -
Page 8: Counter
Counter The counter field will place a counter in your message. You can set the counter behavior from the top of the main menu. The picture below is an example of that menu. From here you will program the counters current value, initial value, step value, max value, and weather you would like to repeat a certain value. -
Page 9: Qr Codes / Data Matrix
QR codes / Data matrix The process for creating QR codes or DM codes are identical, and similar to entering a text filed. Once you have selected either field you will Use the edit button to bring the keyboard forward and enter the desired information. Once you have finalized the information the printer will generate the code and you will simply need to size it to fit the print window. -
Page 10: Video Instructions
Installing your printer onto your conveyor can seem like a daunting task. However, with the correct tools it is very easy. Follow the steps and watch the video linked below and you will be done in no time! 1) Remove the T clamp from your printer kit and use it to mark the holes making sure it is level. 2) Use your center punch directly in the center of your marked holes. -
Page 11: Speed
Speed The lower the speed value the faster the printer ejects ink, one (1) being the fastest setting. The best way to confirm that your speed setting is accurate is to measure the printed code against the code you see on the preview screen. The ruler on the X and Y axis is in mm and accurate to the printed message. See the video instructions for details.
