Rf-t KAMOUFLAGE MP Manual

Motorised, aesthetic and ce marked smoke control shutter that can be perfectly integrated in many smoke control systems
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
KAMOUFLAGE MP
Motorised, aesthetic and CE marked smoke control shutter that can be perfectly
integrated in many smoke control systems.
www.rft.eu
Rf-Technologies nv  Lange Ambachtstraat 40  9860 Oosterzele  Belgium  Tel +32 9 362 31 71  info@rft.eu

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KAMOUFLAGE MP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Rf-t KAMOUFLAGE MP

Summary of Contents for Rf-t KAMOUFLAGE MP

  • Page 1 KAMOUFLAGE MP Motorised, aesthetic and CE marked smoke control shutter that can be perfectly integrated in many smoke control systems. www.rft.eu Rf-Technologies nv  Lange Ambachtstraat 40  9860 Oosterzele  Belgium  Tel +32 9 362 31 71  info@rft.eu...

  • Page 2: Table Of Contents

    Table of content Table of content Declaration of performance Product presentation KAMOUFLAGE MP Range and dimensions KAMOUFLAGE MP Evolution - kits Options - at the time of order Storage and handling Installation Operation: manual opening Operation: manual closing Electrical connection...
  • Page 3 Explanation of the abbreviations and pictograms Explanation of the abbreviations and pictograms Wn = nominal width ved = vertical duct OP = option (delivered with the product) Hn = nominal height hod = horizontal duct KIT = kit (delivered separately for repair or Sn = free air passage vew = vertical wall penetration upgrade)

  • Page 4: Declaration Of Performance

    Declaration of performance Harmonised standard EN 12101-8:2011 max 2...

  • Page 5: Product Presentation Kamouflage Mp

    Product presentation KAMOUFLAGE MP The Kamouflage MP is a motorised, aesthetic and CE marked smoke control shutter that can be perfectly integrated in many smoke control systems. It is certified in accordance with EN12101-8, suitable for vertical mounting in ducts or concrete shafts. Offering 60 or 120 minutes fire resistance at minimum pressure loss, it is classified as suitable for multi-compartment applications.

  • Page 6: Range And Dimensions Kamouflage Mp

    Range and dimensions KAMOUFLAGE MP Range and dimensions KAMOUFLAGE MP 1. Refractory material 2. Sealing if mounting frame 3. Mounting frame EASY-KAP ME/MP (optional) 4. EASY-KGC ME/MP mounting frame with drop guard (optional) 5. Nominal dimensions shutter Wn x Hn 6.

  • Page 7: Storage And Handling

    ∎ Rf-t smoke dampers may be applied to smoke control ducts that have been tested according to EN 1366-8 and EN 1366-9 as appropriate, constructed from similar materials with a fire resistance, thickness and density equal or superior to these of the tested materials.

  • Page 8: Operation: Manual Opening

    Installation Operation: manual opening 20° 1. Remove the finishing cap from the shutter. To do this, use the 2. Unlocking 1V hook with key ring that is delivered with the product. You may Turn the key 20° anti-clockwise and push the shutter into its attach this tool to the key through its handy key ring.

  • Page 9: Electrical Connection

    Installation Electrical connection 1. The electrical connection is possible via the 2 corners at the 2. Drill a hole in the refractory material at the chosen corner(s). side of the hinges. The galvanised part at the inside of the shutter is already indented.

  • Page 10: Position In The Shaft

    Installation Position in the shaft ≥125 mm ≥125 mm ≥125 mm 1. The shutter is affixed to the smoke control duct through a sleeve. That sleeve can be installed either in the duct, in the axis of the duct or outside the duct (or duct extension). 3.

  • Page 11: Installation Into Vertical Concrete Shaft With Mounting Frame

    Shaft EI 120 (v i n o) S 1500 C10000 AA multi concrete ≥ 100 mm EASY-KAP ME/MP KAMOUFLAGE MP Mortar A=20-100 mm A=20 mm 1. In case the mounting frame is screwed: 2. The mounting frame should always be fastened to the Make an opening with dimensions (W+20) x (H+20) mm.
  • Page 12 Installation 3. Put aside the screws that are affixed to one of the cross slats, 4. Rotate the four fastening plates on the damper 90° (to the then unscrew the 4 cross slats of the mounting frame and fold upright position). the 8 fastening plates in the frame.

  • Page 13: Installation Into Vertical Concrete Shaft Without Mounting Frame

    EI 120 (v i n o) S 1500 C10000 AA multi concrete ≥ 100 mm KAMOUFLAGE MP 1. Rotate the four fastening plates on the damper 90° (to the 2. With the prepared opening the shutter can be handled upright position).

  • Page 14: Installation Into Vertical Duct With Built-In Mounting Frame: General Instructions For All Types Of Ducts (Other Than Concrete)

    Installation Installation into vertical duct with built-in mounting frame: general instructions for all types of ducts (other than concrete) EASY-KAP ME/MP KAMOUFLAGE MP ≥ 125 mm 1. Make an opening with dimensions (W+A) x (H+A) mm. 2. Two fixing lugs are provided at the bottom and at the top of A = 2 x thickness sleeve (e) + 20 mm .
  • Page 15 Installation 5. Open the shutter and position it in the mounting frame. Fasten the shutter onto the mounting frame with the 4 screws supplied, as shown in the drawing. Tightening the screws pulls the shutter towards the wall until its final position. You can also slightly correct the angle of the shutter with respect to the mounting frame.

  • Page 16: Installation Into Vertical Duct (Without A Mounting Frame): General Instructions For All Types Of Ducts (Other Than Concrete)

    Installation Installation into vertical duct (without a mounting frame): general instructions for all types of ducts (other than concrete) KAMOUFLAGE MP ≥ 125 mm 1. Rotate the four fastening plates on the damper 90° (to the 2. Make an opening with dimensions (W+A) x (H+A) mm. A = 2 upright position).

  • Page 17: Installation Into Vertical Duct Promatect L500 With Built-In Mounting Frame

    Promatect L500 ≥ 50 mm EI 120 (v i n o) S 1500 C10000 AA multi EASY-KAP ME/MP KAMOUFLAGE MP ≥ 125 mm 1. Assemble the sleeve with staples and affix the assembled sleeve to the duct wall with staples.

  • Page 18: Installation Into Vertical Duct Promatect L500 (Without A Mounting Frame)

    350x385 mm ≤ Kamouflage 1V MP ≤ 700x1075 mm Duct Promatect L500 ≥ 50 mm EI 120 (v i n o) S 1500 C10000 AA multi KAMOUFLAGE MP ≥ 125 mm 1. Assemble the sleeve with staples and affix the assembled sleeve to the duct wall with staples.

  • Page 19: Installation Into Vertical Duct Geoflam (Light) / Geotec With Built-In Mounting Frame

    EI 120 (v i n o) S 1500 C10000 AA multi EASY-KAP ME/MP KAMOUFLAGE MP ≥ 125 mm 1. Coat the edges of the opening with adhesive plaster type PLACOL (in case of Geoflam) or GEOCOL (S) (in case of Geotec).

  • Page 20: Installation Into Vertical Duct Geoflam (Light) / Geotec (Without A Mounting Frame)

    Geotec ≥ 45 mm EI 120 (v i n o) S 1500 C10000 AA multi KAMOUFLAGE MP ≥ 125 mm 1. Coat the edges of the opening with adhesive plaster type PLACOL (in case of Geoflam) or GEOCOL (S) (in case of Geotec).

  • Page 21: Installation Into Vertical Duct Tecniver With Built-In Mounting Frame

    EI 120 (v i n o) S 1500 C10000 AA multi EASY-KAP ME/MP KAMOUFLAGE MP ≥ 125 mm 1. Put glue type CF GLUE on the uprights and cross pieces and between the lining and the wall. Screw the sleeve using chipboard screws Ø5 x 70 mm at 150 mm intervals.

  • Page 22: Installation Into Vertical Duct Tecniver (Without A Mounting Frame)

    Tecniver ≥ 50 mm EI 120 (v i n o) S 1500 C10000 AA multi KAMOUFLAGE MP ≥ 125 mm 1. Put glue type CF GLUE on the uprights and cross pieces and between the lining and the wall. Screw the sleeve using...

  • Page 23: Installation Into Vertical Duct Glasroc F V500 With Built-In Mounting Frame

    EI 120 (v i n o) S 1500 C10000 AA multi EASY-KAP ME/MP KAMOUFLAGE MP ≥ 125 mm 1. Put glue type GLASROC F V500 on the uprights and cross pieces and between the lining and the wall. Screw the sleeve using chipboard screws Ø5 x 70 mm at 150 mm intervals.

  • Page 24: Installation Into Vertical Duct Glasroc F V500 (Without A Mounting Frame)

    Glasroc F V500 ≥ 50 mm EI 120 (v i n o) S 1500 C10000 AA multi KAMOUFLAGE MP ≥ 125 mm 1. Put glue type GLASROC F V500 on the uprights and cross pieces and between the lining and the wall. Screw the sleeve...

  • Page 25: Installation Into Vertical Duct Exthamat With Built-In Mounting Frame

    Exthamat ≥ 35 mm EI 120 (v i n o) S 1500 C10000 AA multi EASY-KAP ME/MP KAMOUFLAGE MP ≥ 125 mm 1. Coat the edges of the opening with adhesive plaster. Seal the joints between uprights and cross pieces and between the lining and the wall with vegetable fibre caulking and plaster.

  • Page 26: Installation Into Vertical Duct Exthamat (Without A Mounting Frame)

    Exthamat ≥ 35 mm EI 120 (v i n o) S 1500 C10000 AA multi KAMOUFLAGE MP ≥ 125 mm 1. Coat the edges of the opening with adhesive plaster. Seal the joints between uprights and cross pieces and between the lining and the wall with vegetable fibre caulking and plaster.

  • Page 27: Installation Into Vertical Duct Desenfire (Hd/Thd/Str) With Built-In Mounting Frame

    Desenfire ≥ 45 mm EI 120 (v i n o) S 1500 C10000 AA multi EASY-KAP ME/MP KAMOUFLAGE MP ≥ 125 mm 1. Coat the edges of the opening with adhesive plaster, type FACILIS. Seal the joints between uprights and cross pieces and between the lining and the wall with vegetable fibre caulking and plaster.

  • Page 28: Installation Into Vertical Duct Desenfire (Hd/Thd/Str) (Without A Mounting Frame)

    Duct Desenfire ≥ 45 mm EI 120 (v i n o) S 1500 C10000 AA multi KAMOUFLAGE MP ≥ 125 mm 1. Coat the edges of the opening with adhesive plaster, type FACILIS. Seal the joints between uprights and cross pieces and between the lining and the wall with vegetable fibre caulking and plaster.

  • Page 29: Installation At Minimal Distances

    Installation Installation at minimal distances Wn+A Hn+A A=10 mm (KAM ME/MP - AVA MP) A=20 mm (KAM ME/MP - AVA MP + EASY KAP ME/MP) 1. The shutters can be installed at minimal distance on top of 2. In case several shutters are mounted at a minimal distance, or next to each other, if they are mounted in separate sleeves the bearing and reinforcement points of the duct must be made from the duct material with the required fire resistance.

  • Page 30: Finishing

    SHEV system. For example, BS7346 part 8, NF S 61-933 and EN 13306. Kamouflage MP dampers are virtually maintenance free, however, they will require occasional operation and maintenance as part of a system specific routine operational test and maintenance procedure.

  • Page 31: Operation And Mechanisms

    Caution : please note dampers must be fully open before starting supply and/or extract fans. † VA MP MEC Mechanism for remote controlled unlocking and resetting. Mechanism for the smoke control shutters AVANTAGE MP and KAMOUFLAGE MP. Remote controlled unlocking and resetting. Options - at the time of order VD24...

  • Page 32: Electrical Connection

    Electrical connection Electrical connection VA MP MEC 2 WIRES 3 WIRES 2 WIRES 3 WIRES 24/48VDC -10/+15% Option: TL DC : Switch closed position smoke evacuation shutter FC : Switch open position smoke evacuation shutter Power Power Nominal voltage motor Nominal voltage magnet consumption consumption...

  • Page 33: Weights

    Weights Weights KAMOUFLAGE MP 1V60 - 1V120 with ATOUT 1V MP RAL9010 Hn\Wn [mm] 385 kg 10,4 11,2 12,0 12,6 13,5 14,2 14,9 15,5 415 kg 11,0 11,8 12,6 13,3 14,2 14,9 15,7 16,3 445 kg 11,4 12,3 13,1 13,8...
  • Page 34 0,712 0,634 0,573 0,522 0,48 1075 ζ [-] 1,122 0,926 0,792 0,692 0,616 0,556 0,508 0,467 KAMOUFLAGE MP 1V60 - 1V120 Hn\Wn [mm] 385 Sn [m²] 0,1080 0,1260 0,1430 0,1600 0,1780 0,1950 0,2120 0,2300 415 Sn [m²] 0,1180 0,1360 0,1550...

  • Page 35: Sample Order

    Sample order Sample order KAMOUFLAGE MP 1V 685 VD24 MP FDCU TL product 1 shutter fire resistance of 60 or 120 minutes width height option: type magnet and voltage motor: MP limit switch ‘open/closed’ option: trailing lead 3 m Approvals and certificates All our products are submitted to a number of tests by official test institutes.
