4. Timer: Press this button to set a timer between 1-7 hours. Once the time is up, the
appliance will switch to standby. Each time the button is pressed, the time increases by
one hour – the indicator will light on the screen. To cancel the timer, press the button
until the indicator turns off.
5. Swing: When this button is pressed, the air control blades are activated and the swing
indicator is on – air will flow to the left and right. Press the button again to stop the
oscillation. The control blades direct the air flow up and down – it must be set manually.
6. Cooler: When this button is pressed, the pump will take water from the tank and pour it
onto the cooling pad. This will absorb the heat of the water and the evaporated water is
blown out by the fan. The cool breeze will drop the ambient temperature, creating a
relaxing and cooling effect.
HOW TO FILL WATER TANK
Take out the tank from the bottom of the air cooler (at the back) and fill with 1/3 of water.
● Pay attention to the water level indicator when filling.
● The water level of tank must be less than 'MAX'.
● The water level of tank must be more than 'MIN'.
● For cooler wind, place ice boxes (or ice) into the tank.
HOW TO USE ICE BOXES
● Ice boxes will reduce the water temperature, so the air is cooler from the appliance.
● Place ice boxes, filled with water, in the freezer.
● Once frozen, take out the ice boxes.
● Take out the tank and place the ice box inside.
● There are two ice boxes, so you can rotate them and have continuous cool air.
CLEANING
1. Clean air filter
Take out the plug and pull the holder of the air filter. Once the filter is out, clean with a
neutral cleaner and soft brush. Next, rinse with water, then place the air filter back into the
appliance.
2. Clean the wet curtain paper
Take out the plug and remove the air filter, then remove the wet curtain paper. Clean the
wet curtain paper with a neutral cleaner, soft brush and water, then place it back into the
appliance.
