Electro-Voice EVERSE8-RAINCVR Quick User Manual

Safety
Correct rain cover usage
– Use the speaker in upright (shown left) or kickback
(shown right) orientations only.
– Do not use the speaker in monitor mode in damp or
wet conditions.
– Route the cables out of the bottom of the amp
pocket. Make sure that the zippers are tight around
the cables.
– Do not route the cables out of the sides of the amp
pocket. Do not leave the amp pocket unzipped.
– Do not submerge the speaker in water or spray with
a water hose.
Cleaning and drying instructions
– Clean with a damp cloth.
– Air-dry only.
– Do not machine wash.
– Do not tumble dry.
Drain holes
The EVERSE rain cover was designed with four drain
holes. The goal is to drain any water that may penetrate
the inside of the rain cover.
IP rating
The EVERSE loudspeaker with the rain cover installed is
rated for IP44, but only in upright and kickback orienta-
tions, and only when used properly as defined in the in-
cluded Quick user guide.
Some water may pool at the bottom of the rain cover
when exposed for an extended period of time. Remove
the speaker from the bag to allow both to dry properly.
When using the rain cover, the weatherized input cover
is optional to achieve the IP44 rating.
Weatherization
When the rain cover is installed, the EVERSE loud-
speaker is designed to be weather resistant to IP44
standards, but not waterproof. The weather resistance
may be reduced by damage, repair, improper disas-
sembly, and regular wear and tear. Always inspect the
EVERSE loudspeaker and accessories before and after
every use. Allow the loudspeaker and components to dry
before storage or between uses.
The EVERSE loudspeaker with rain cover installed is in-
tended only for temporary use in wet or damp environ-
ments. The loudspeaker is not intended to be exposed
continuously to moisture over long periods of time. Do
not expose to salt water or spray, do not expose to
chlorine or use in high chlorine environments.
Using the rain cover
To use the rain cover:
1. Unzip the rain cover and insert the speaker.
Make sure the grill is facing the front flap.
2. Zip the rain cover.
