Magtek iDynamo 5 Quick Installation Manual page 2

Accepting Payments
The steps for reading a card may be different depending on READER
configuration and on the design of the HOST SOFTWARE. Cardholders
should swipe magnetic stripe cards in the MSR swipe path with the
magnetic stripe facing away from the cardholder and into the READER.
Cardholders may swipe in either direction along the path.
Commands
The READER does not have an on-screen configuration interface. The
READER is HOST driven by the HOST SOFTWARE.
LEDs
iDynamo 5 (Gen III) has a single RGB LED acting as the user interface. The
LED will be used to indicate various states of the reader. See the installation
and operation manual found at https://www.magtek.com/content/
documentationfiles/d998200614.pdf
Maintenance
Periodic cleaning of iDynamo 5 (Gen III)'s exterior may be required. To clean
the outside of iDynamo 5 (Gen III), wipe it down with a soft, damp, lint-free
cloth and then wipe it dry. MagTek's double-sided cleaning card 96700004
is designed to clean the magnetic read head in the MSR swipe path.
Keeping the head clean is essential to the device's functioning. MagTek
recommends swiping and inserting a cleaning card once per week to avoid
card misreads.
Compliance
FCC INFORMATION
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) This device must accept
any interference received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
Caution: Changes or modifications not expressly approved by MagTek could void the user's
authority to operate this equipment.
CE STANDARDS
Testing for compliance with CE requirements was performed by an independent laboratory. The
unit under test was found compliant with standards established for Class B devices.
UL/CSA
This product is recognized per UL 60950 1, 2nd Edition, 2011 12 19 (Information Technology
Equipment - Safety - Part 1: General Requirements), CSA C22.2 No. 60950 1 07, 2nd Edition,
2011 12 (Information Technology Equipment - Safety - Part 1: General Requirements).
ROHS STATEMENT
When ordered as RoHS compliant, this product meets the Electrical and Electronic Equipment
(EEE) Reduction of Hazardous Substances (RoHS) European Directive 2002/95/EC. The
marking is clearly recognizable, either as written words like "Pb-free," "lead-free," or as another
clear symbol ( ).
Pb
Please note that the use of this accessory with an Apple product may affect wireless performance. Apple®, Apple Pay®, OS X®, iPhone®, iPad®, iPad Air®, and iPad Pro® are trademarks of Apple Inc., registered in the U.S. and other countries. EMV® is a registered
trademark in the U.S. and other countries and an unregistered trademark elsewhere. The EMV trademark is owned by EMVCo, LLC. The Contactless Indicator mark, consisting of four graduating arcs, is a trademark owned by and used with permission of EMVCo, LLC.
Use and Compliance
MagTek Inc., 1710 Apollo Court, Seal Beach CA 90740 | p 562-546-6400 | support 562-415-6800 | f 562-546-6301 | www.magtek.com
®
MAGTEK: Registered to ISO 9001:2015 © Copyright 2024 MagTek, Inc. PN D998200623 100 3/24
