Assembly Instructions
CM-AC214
ASSEMBLY RATING
Tools Required for Assembly:
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
Allen Wrench
assembling a specific product (with 1 being
(Included)
easy and 5 being difficult). For some
products, two persons are recommended.
DIFFICULT
EASY
Page 1 of 6
Rev.14-03-10
Advertisement
Related Manuals for Furniture of America CM-AC214
Summary of Contents for Furniture of America CM-AC214
- Page 1 Assembly Instructions CM-AC214 ASSEMBLY RATING Tools Required for Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench assembling a specific product (with 1 being (Included) easy and 5 being difficult). For some products, two persons are recommended.
- Page 2 Page 2 of 6...
- Page 3 Before you begin, please read Page 2 of “Assembly and Care Advice”. And remember, do not tighten until each step is completed or instructed. Parts List Hardware List #1 x 1 pc #A x 8 pcs Table Top Bolt 1/4”x1-1/2” #2 x 4 pcs #B x 16 pcs Lock Washer...
- Page 4 #B x 4 pcs Step 1 #C x 4 pcs #D x 4pcs Carefully place the table top (#1) on its side on a protective surface. Align the leg (#2) with the 2 pre-drilled holes onto the corner of the table top (#1). Prepare 2 bolt assemblies by inserting a lock washer (#B) onto the bolt (#D) and then the flat...
- Page 5 For this step, you will basically repeat Step 1 to assemble Step 3 the remaining two legs (#2) onto the table top (#1). Enlarged #B x 4 pcs #C x 4 pcs #D x 4 pcs Turn right (clockwise) to tighten For this step, you will basically repeat Step 2 to assemble the Step 4 remaining two legs (#2) onto the two support shelves (#4).
- Page 6 Insert the drawers (#3) onto the table top (#1). For safety reason, there Step 5 are built-in latches underneath the table top (#1) that will prevent the drawers from coming out completely. See the diagram below for the desired position needed for each drawer. LOCK POSITION UNLOCK POSITION Carefully turn the completed table upright.
