For more information contact our team: service.ec@foagroup.com
ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
CM-AC804
DIFFICULT
Tools Required For Assembly:
Allen Wrench
Phillips Screwdriver
2 PERSONS RECOMMENDED
Page 1 of 7
(Included)
(Not Included)
Rev:18- 11 -2 9
Advertisement
Table of Contents
Related Manuals for Furniture of America Alyssa CMAC804A
Summary of Contents for Furniture of America Alyssa CMAC804A
- Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM-AC804 ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench assembling a specific product (with 1 being (Included) easy and 5 being difficult).
- Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 7...
- Page 3 Cam Lock Fastener Assembly Board A Cam Lock are fasteners used to join two boards together, usually the edge of one board (A) to the flat side of another board (B). Flat side edge to join Board B Cam Lock Cam Pin To use Cam Lock Step 2 - Fit the...
- Page 4 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #A x 4pcs #1 x 1pc Left Frame Bolt Ø1/4" x 1-3/8" #B x 1pc #2 x 1pc Right Frame Allen Key 4mm #3 x 4pcs...
- Page 5 #C x 10pcs Attach cam pins (#C) to left frame (#1). #C x 5pcs Attach cam pins (#C) to right frame. Page 5 of 7...
- Page 6 Attach cam pin (#C) to lower shelf (#4). #C x 1pc Please refer to page 3 on how to secure cam locks (#D) onto cam pins (#C). #D x 10pcs Align shelves (#3,4) to the frame (#1), then secure by using cam locks (#D). Page 6 of 7...
- Page 7 Align frame (#2) to the shelves, then secure by using cam locks (#D). #D x 6pcs Wall #A x 4pcs #E x 2pcs #F x 4pcs #G x 2pcs #H x 2pcs #I x 2pcs Align and secure the fabric (#I) to each back ends of the unit by using screws (#E) with washers (#F).
