- Page 1 MODEL # CM-AC395 Questions? GIVE US A CALL: 1-888-980-5122 MON-FRI 8:30AM - 5:30PM (PT) Allen Wrench (Included) 2 - People Recommended ASSEMBLY RATING EASY DIFFICULT The Assembly Rating is a 5-point system showing the level of effort needed to assemble a specific product. VERSION # 21-06-29 1 / 8...
- Page 2 America Furniture FOA Intro Thank you for your purchase! We hope you enjoy this new addition to your home for many years to come. Our commitment to providing quality products does not simply end when you purchase our product. We fully stand behind our products from start to finish. Our customer service department is available Monday –...
- Page 3 PRE ASSEMBLY INTRODUCTION We understand building ready-to-assemble furniture can be a challenging experience for some. To help avoid confusion, we have provided some helpful tips that may speed up the process. Teamwork ALWAYS have at least two people to help with transporting and assembling the product to avoid potential injury and/or damage.
- Page 4 4 / X X X X X X X 8...
- Page 5 STORAGE BENCH&OTTOMAN CM-AC395 #1 1pc #2 1pc #3 1pc Bench Small Ottoman Middle Ottoman #4 4pcs #5 8pcs Bench Leg Ottoman Leg #A 12pcs #B 12pcs #C 12pcs #D 1pc Bolt Ø5/16"x2-1/8" Lock Washer Ø5/16" Flat Washer Ø5/16"x22mm Allen Key M4 5 / 8...
- Page 6 Exploded View 6 / 8...
- Page 7 ASSEMBLY INSTRUCTIONS Align legs (#4) to the bench (#1), then secure by using bolts (#A) with washers (#B,C). Part #1 x1pc Part #4 x4pcs Hardware #A x4pcs Hardware #B x4pcs Hardware #C x4pcs Part #2 x1pc Part #5 x4pcs Hardware Align ottoman legs (#5) onto small #A x4pcs ottoman (#2), then secure by...
- Page 8 ASSEMBLY INSTRUCTIONS Align ottoman legs (#5) to the middle Part #3 x1pc ottoman (#3), then secure by using bolts Part #5 x4pcs (#A) with washers (#B,C). Hardware #A x4pcs Hardware #B x4pcs Hardware #C x4pcs 8 / 8...
