- Page 1 VISIO UNIQ 3:1 INSTALLATION GUIDE (UK)
-
Page 2: Production Number
PRODUCTION NUMBER Production number The production number is found in the bottom left corner of the fireplace insert. See drawing. It is also found at the front of the user manual. Revision: Date: 25-01-2024 We reserve the right to make printing errors. 2 - EN... - Page 3 INSTALLATION GUIDE INSTALLATION GUIDE General information ..........Chimney .
-
Page 4: General Information
INSTALLATION GUIDE INSTALLATION GUIDE Thank you for choosing your new RAIS or ATTIKA product! This installation instructions manual will ensure that your fireplace insert is installed correctly and that it will provide you with comfort and pleasure for many years to come. - Page 5 Due to risk of fire, flammable items (e.g. furniture) may not be positioned closer to the insert than specified in the sections on placement. When deciding where to install your RAIS/ATTIKA fireplace insert, you should consider being able to heat other rooms in your home to get the most out of your new fireplace insert.
-
Page 6: Technical Data
TECHNICAL DATA SPECIFICATIONS Danish Technological Institute ref.: 300-ELAB-2646-EN VISIO UNIQ 3:1 Nominal output (kW) 11,3 Heating area (m Fireplace insert W x D x H (mm) 631 X 1062 X 1637 Combustion chamber W x D x H (mm) 237 X 638 X 234** Min. - Page 7 TECHNICAL DATA n 198 1637 DIMENSIONAL SKTECHES 1580 1561 n 198 n 198 1637 1637 1580 1580 1561 1561 1453 737 (G) 737 (G) 737 (G) 431 (G) 431 (G) 431 (G) The top section of the flue collar can be moved around in a radius of 149 mm around the centre of the flue outlet.
-
Page 8: Information Plate
Suitable for connection to a shared fl ue, on the condition that both devices have Poêle pour combustibles solides the same owner. Produced for: ATTIKA FEUER AG, Brunnmatt 16, CH-6330 Cham / RAIS A/S, Industrivej 20, DK-9900 Frederikshavn 8 - EN... -
Page 9: Installation
INSTALLATION INSTALLATION The following section explains how to install the fireplace insert and includes information about packaging, placement distances, etc. PACKAGING AT DELIVERY Upon delivery, the fireplace insert is secured to a transport pallet us- ing four transport safety fittings. The safety fittings are attached with screws which must be unscrewed. -
Page 10: Transport Security
INSTALLATION TRANSPORT SECURITY IMPORTANT! On delivery, the door is locked for transport and must be released before in- stallation. This is done by removing the two transport screws in the counter- weights on the back of the oven! 10 - EN... - Page 11 INSTALLATION AIR CONCENTRATOR PLATE IMPORTANT! The oven comes with an air concentrator plate that must be removed before use. The installation of Visio Uniq 3:1 may differ depending on the country in which it is installed. In Norway pursuant to Norway’s open-plan office rules requires the insertion of a mechanical stopper in the flue.
- Page 12 CHOICE OF MATERIAL FOR INSTALLATION The material can be panels/brick with an insulation value greater than 0.03 m² x K/W. The insulation is defined as wall thickness (in metres) divided by the wall’s Lambda value. Consult your installation technician/chimney inspector. During testing, the fireplace insert is installed in a cabinet made of non- flammable 50 mm calcium silicate panels (Skamotec 225).
-
Page 13: Installation Dimensions
INSTALLATION DIMENSIONS INSULATED FLUE INSTALLATION DIMENSIONS Applies to installation into non-flammable panels. Minimum cavity dimensions (H x W x D): . 560 x 631 x 887 mm A fireplace insert must never be tightly inserted into a cavity, as steel expands when heated. - Page 14 SET-UP INSULATED FLUE A non-combustible plate must be installed directly above the convection air draft. ATTENTION! The insulated chimney must extend all the way down to the flue outlet adapter. 14 - EN...
- Page 15 convection air SET-UP INSULATED FLUE discharge area = If the insulation value is complied with (greater than 0.03 m² x K/W), the cabinet may be installed against a flammable wall provided that the inte- rior distance from stove to cabinet is respected. Minimum distance Distance from door to furniture Distance from side glass to furniture...
- Page 16 INSTALLATION DIMENSIONS UN-INSULATED FLUE INSTALLATION DIMENSIONS: Applies to installation into non-flammable panels. Minimum cavity dimensions (H x W x D): . 560 x 631 x 887 mm mm A fireplace insert must never be tightly inserted into a cavity, as steel expands when heated.
- Page 17 SET-UP UN-INSULATED FLUE A non-combustible plate must be installed directly above the convection air draft. ATTENTION! The insulated chimney must pass through the non-combustible plate. EN - 17...
- Page 18 SET-UP UN-INSULATED FLUE convection air discharge area If the insulation value is complied with (greater than 0.03 m² x K/W), the cabinet may be installed against a flammable wall provided that the interior distance from stove to cabinet is respected. Minimum distance Distance from door to furniture convection air...
- Page 19 HEAT DISTRIBUTOR HEAT DISTRIBUTOR By installing a heat distributor unit above the fireplace insert, heat can be ‘transported’ to other rooms. COLD AIR WARM AIR EN - 19...
- Page 20 CONVERT TO SELF-CLOSING DOOR BEFORE BUILDING IN THE INSERT Convert the door to self-closure by removing some of the door’s counterweights. There are counterweights on both sides. 1. Remove the transport safety fittings and retainer screws for the counter- weight cover Transport safety fitting.
- Page 21 CONVERT TO SELF-CLOSING DOOR AFTER BUILDING IN THE INSERT Convert the door to self-closure by removing some of the door’s counterweights. There are counterweights on both sides. 1. Remove the side Skamol panel. 2. Remove the access panel. Access panel. 3.
- Page 22 EXTERNAL AIR CONNECTION, AIRSYSTEM EXTERNAL AIR CONNECTION, AIRSYSTEM All RAIS/ATTIKA fireplace inserts can have an external air connection for combustion. We call this external air supply AirSystem. The system can be connected to the underside of the fireplace insert. 150 mm flexi hose (metal)
-
Page 23: Declaration Of Performance
DECLARATION OF PERFORMANCE EN - 23... -
Page 24: Test Certificate
Declare that the DoC is issued under our sole responsibility and belongs to the foliowing produet: Rais project number: Models: RAIS VISIO Uniq 3:1 ATTIKA VISIO Uniq 3:1 Type lnset aooliance burninq solid fuel without hot water supply Serial number: All staves have a unique serial number that is affixed to the stove. - Page 25 TEST CERTIFICATE A R T I R E The object of the declaration described above is in conformity with the relevant top-level directives and regulations DIR 2009/125/EC 21/10/2009 Energy Related Produets Direetive (eeodesign) � REG (EU) 305/2011 9/3/2011 Construetion Produets Regulation (CPR) �...
-
Page 26: Spare Parts List
SPARE PARTS LIST SPARE PARTS VISIO UNIQ 3:1 If spare parts other than those recommended by RAIS are used, the war- ranty is void. All replaceable parts can be purchased as spare parts from your RAIS dealer. See spare parts drawing. POS. -
Page 27: Spare Parts Drawing
SPARE PARTS DRAWING 10-11 EN - 27... - Page 28 RAIS A/S ATTIKA FEUER AG Industrivej 20 Brunnmatt 16 DK-9900 Frederikshavn CH-6330 Cham Denmark Switzerland www.rais.com www.attika.ch...
