T
he Sea Vision SV14 LED Weld in
Tank Light for aluminum or steel hulls
is designed for installation in water and
ballast tanks. High density LED chip
technology is utilized and combined with
the latest award winning silicone optics
produce an industry leading lighting effect.
The lights can be welded at adjustable
angles to suit all hull shapes. The hull
shape and positioning will dictate the angle
of the light you require, angles available are
0 to 50 degree. The vessel must be hauled
out for installation although any mainte-
nance can be done in the water from within
the hull. The light body is designed to act
as a cofferdam / secondary containment
for additional security.
SV14 LED Tank Light technical specifications
Application for: Aluminum or Steel hulls
––––––––––––––––––––––––––––––––––––––––––––––
Light source: High density LED array
Available in: White, blue, green, red or RGBW
––––––––––––––––––––––––––––––––––––––––––––––
Life length: approx. 30,000 hours plus
––––––––––––––––––––––––––––––––––––––––––––––
Lumens: 21,685 in white
––––––––––––––––––––––––––––––––––––––––––––––
Kelvin colour temp: 7000
––––––––––––––––––––––––––––––––––––––––––––––
Glass lens: Borosilicate glass
Thickness:
12.7mm / 0.5"
Diameter: 58mm / 2.3"
––––––––––––––––––––––––––––––––––––––––––––––
Power supply: 100-277 VAC 50/60 Hz
Blue/green:
1.1 Amps 120V, 0.55 Amps 230V – 100W
White: 1.87 Amps 120V, 0.91 Amps 230V – 150W
0.55 Amps 120V, 0.30 Amps 230V – 264W
RGBW:
––––––––––––––––––––––––––––––––––––––––––––––
Casing material: Aluminum 5086 or Stainless Steel 316L
––––––––––––––––––––––––––––––––––––––––––––––
Ignition Protection tested to ATEX EXD IIA T30
SV14 LED Tank Light
Angles available: Flush
––––––––––––––––––––––––––––––––––––––––––––––
Cable:
––––––––––––––––––––––––––––––––––––––––––––––
Code:
––––––––––––––––––––––––––––––––––––––––––––––
Total shipping weight: Approx. 25 – 50 lbs
––––––––––––––––––––––––––––––––––––––––––––––
Installation:
––––––––––––––––––––––––––––––––––––––––––––––
This is a guideline only, for specific requirements please contact us.
All information is subject to change without prior notice,
please confirm details prior to ordering.
3406 SW 26th Terrace, C-6/7, Fort Lauderdale, FL 33312 USA
T. 954 760 4447 Toll Free 1 866 772 0130 F. 954 525 3261
sales@seavision.com www.seavision.com
30 degree
38 degree
50 degree
Only required between the light and driver (maximum
distance 16 feet / 5 meters). Marine grade electrical
cable 18/2 stranded copper wire. Normal ships cable
can be used
SV14 LED Tank Light
Recommended at least 24" (610mm) below t he
waterline between 3 – 8 feet (1 – 2.5 meters) apart.
