T
he US manufactured SV10 LED is
the brightest thru hull LED underwa-
ter light available to owners of GRP and
wood boats. The industry leading SV10
combines the unique qualities of the
latest high density LED chip technology
with a silicone optic. This silicone optic
increases the light output 30% while
protecting the LED's from moisture. Both
technologies are incorporated into the
proven SV10 light body. As with all thru
hull lights servicing and maintenance
can be completed from inside the boat
so this task is not limited to haul out
periods. This light is suitable for all mid
to large vessels including Yachts, sport
fishers and cruising boats that have
available A/C power.
SV10 LED technical specifications
Application for:
GRP / fiberglass / wood hulls
––––––––––––––––––––––––––––––––––––––––––––––
Light source:
High density LED array
––––––––––––––––––––––––––––––––––––––––––––––
Available in:
White, blue, green or RGB
––––––––––––––––––––––––––––––––––––––––––––––
Life length:
Approx. 40,000 + hours
––––––––––––––––––––––––––––––––––––––––––––––
21,685 in white
Lumens:
––––––––––––––––––––––––––––––––––––––––––––––
Kelvin col our temp: 6500 in white
––––––––––––––––––––––––––––––––––––––––––––
Glass lens:
Borosilicate glass
Thickness:
12.7mm / 0.5"
Diameter:
58mm / 2.3"
––––––––––––––––––––––––––––––––––––––––––––––
Power supply:
100 – 277 VAC
50/60 Hz, 1.1 – 0.45 Amp input
Max. 150W output
––––––––––––––––––––––––––––––––––––––––––––––
Casing material:
Marine Bronze / Marine Aluminum
Dimensions:
Flange diameter: 130mm (5.12")
Body length: 258mm (10.16")
––––––––––––––––––––––––––––––––––––––––––––––
SV10 LED
Angles Available: Flush
––––––––––––––––––––––––––––––––––––––––––––––
Code:
SV10 LED
––––––––––––––––––––––––––––––––––––––––––––––
Total shipping weight: 18lbs
––––––––––––––––––––––––––––––––––––––––––––––
Installation:
Recommended at minimum 10" (250mm)
below light load waterline between 3 – 8 feet
(1 – 2.5 meters) apart.
4" (100mm) cut out hole
This is a guideline only, for specific requirements please
contact us.
———————————————————————
All information is subject to change without prior notice,
please confirm details prior to ordering.
3406 SW 26th Terrace, C-6/7, Fort Lauderdale, FL 33312 USA
T. 954 760 4447 Toll Free 1 866 772 0130 F. 954 525 3261
sales@seavision.com www.seavision.com
