SV60 LED Surface Mount Gen II
Ideal for any mid to large size vessel
with limited access from the interior.
• Brightest surface mounted
underwater light available today.
• Robust aluminum bronze housing.
• Available in single color or RGB color
changing.
• Incorporates a unique silicone optic.
A Seavision and industry first.
• Latest High Density LED Chip
technology (COB Chip).
• Reliable 50,000 hour lifespan.
• Two year warranty.
• Easy installation.
SV60 LED Gen II technical specifications
Application for: GRP / fiberglass / wood hulls
––––––––––––––––––––––––––––––––––––––––––––––
Lamp:
COB High intensity LED array
––––––––––––––––––––––––––––––––––––––––––––––
Available in:
White, Blue or RGB
––––––––––––––––––––––––––––––––––––––––––––––
Life length:
Approx. 40,000 + hours
––––––––––––––––––––––––––––––––––––––––––––––
Kelvin colour temp: 6500
––––––––––––––––––––––––––––––––––––––––––––––
Glass lens:
Borosilicate glass
Thickness:
0.19" / 4.8mm
Diameter:
3.5" / 88mm
––––––––––––––––––––––––––––––––––––––––––––––
Power supply:
100-277 VAC 50/60 Hz
Blue/green:
1.1 Amps 120V, 0.55 Amps 230V – 100W
White:
1.87 Amps 120V, 0.91 Amps 230V – 150W
0.55 Amps 120V, 0.30 Amps 230V – 264W
RGB:
Lumens: 19,621 (in white)
Casing material:
Marine Bronze
Dimensions:
Diameter: 5.19" / 132mm
Depth: 1.43" / 36.4mm
––––––––––––––––––––––––––––––––––––––––––––––
Weight:
5.22kg / 11.5 lbs
––––––––––––––––––––––––––––––––––––––––––––––
Code:
SV60 LED / RGB Gen II
––––––––––––––––––––––––––––––––––––––––––––––
Total shipping weight: 5.90 kg / 13lbs
––––––––––––––––––––––––––––––––––––––––––––––
Recommended at least 5 – 6" (125 – 150mm)
below waterline between 3 – 8 feet
(1 – 2.5 meters) apart
The placement of surface mounted underwater lights on the
hull bottom is not recommended.
———————————————————————
All information is subject to change without prior notice,
please confirm details prior to ordering.
3406 SW 26th Terrace, C-6/7, Fort Lauderdale, FL 33312 USA
T.
954 760 4447 Toll Free 1 866 772 0130 F . 954 525 3261
sales@seavision.com www.seavision.com
Advertisement
Table of Contents
Troubleshooting
Related Manuals for Underwater Lights USA sea vision SV60
Summary of Contents for Underwater Lights USA sea vision SV60
- Page 1 SV60 LED Surface Mount Gen II Ideal for any mid to large size vessel with limited access from the interior. • Brightest surface mounted underwater light available today. • Robust aluminum bronze housing. • Available in single color or RGB color changing.
- Page 2 Overall dimensions = 132mm (5.19”) diameter x 36.4mm (1.43”) long - 1818 grams (4 lbs) Power supply = See matching Underwater Lights ® USA, LLC driver box specifications Underwater Lights USA, LLC Underwater Lights Europe Sarl 3406 S.W. 26 Terrace, C-6/7...
- Page 3 60033 GLASS O-RING 60034 M4 x 0.7 x 12 LG SST SFHS *PLEASE CALL FOR OTHER LIGHT COMPONENT CONFIGURATIONS Underwater Lights USA, LLC Underwater Lights Europe Sarl 3406 S.W. 26 Terrace, C-6/7 2323, Chemin de Saint-Bernard Fort Lauderdale, FL 33312 USA...
- Page 4 USA, LLC for an RMA number and then return the ® driver box freight prepaid with the RMA number clearly marked on the outside of the shipping container. Underwater Lights USA, LLC Underwater Lights Europe Sarl 3406 SW 26 Terrace, C-6/7...
- Page 5 M4 x 0.7 x 8LG SST PPHS 18049 3-POLE TERMINAL STRIP 18050 4-POLE TERMINAL STRIP *PLEASE CALL FOR OTHER PRODUCT COMPONENT CONFIGURATIONS Underwater Lights USA, LLC Underwater Lights Europe Sarl 3406 SW 26 Terrace, C-6/7 2323, Chemin de Saint-Bernard Fort Lauderdale, FL 33312 USA...
- Page 6 Underwater Lights USA, LLC. Ciò vale sia per la prima utilizzazione sia per il materiale in prestito o visione a terzi. Qualsiasi infrazione può essere soggetta a sanzioni e/o indennizzi senza considerare la questione del senso di colpa.
