SV18 RGB LED Driver Box
Introduction:
Congratulations on the purchase of your new three color (Red, Green, Blue) LED light driver box. Underwater Lights
takes pride in providing well designed, high quality and thoroughly tested lights that allow you to "enhance your boating
experience". These lights can be installed in your vessel for aesthetics, to attract fish, for security and safety.
Features Include:
Latest DMX control technology and electronic component construction to guarantee high levels of performance.
Universal VAC input with short circuit, over current, over voltage and over temperature protections.
Electrical wiring terminal blocks and VAC input fused protection.
General Safety Information:
This driver box is specifically designed for use with matching Underwater Lights
Always ensure that VAC power is disconnected and locked out before performing driver box installation and/or service.
The driver box should be opened and visually inspected every six months.
Driver box electrical cabling should be visually inspected for proper operating condition every six months.
Technical Specifications:
Box Dimensions = 260mm (10.2") long x 160mm (6.3") wide x 91mm (3.6") deep - 3.5 kilograms (7.7 pounds)
Box Construction = Gray painted diecast aluminum alloy with polyurethane gasket, IP66/NEMA 4X rated
Driver = 100-277 VAC 50/60 Hz - RGB: 0.55 Amps 120V, 0.30 Amps 230V - 264W - Minimum operating temperature -30°C (-22°F)
Power Cable to Driver Box = Marine grade electrical cable, 16/3 stranded copper wire, with as short a length as possible
Cable from DMX Control to Driver Box = Marine grade electrical cable, shielded 18/3 stranded copper wire is recommended
Driver Box Cable to LED Light = Marine grade electrical cable, 18/4 stranded copper wire, 5 meters (16 feet) maximum length
Terminal Block Fuse = Fast blow 10 Amp cylindrical, 6.3mm diameter x 25mm or 32mm long (0.25" diameter x 1.0" or 1.25" long)
Troubleshooting:
Please contact our technical support staff in Florida at 1-954-760-4447, Monday to Friday from 8:00 am to 5:00 pm EST.
Warranty:
Underwater Lights USA, LLC warrants this driver box to be free from defects in workmanship and materials for a period of two
®
years from the date of original purchase. Further, misuse, abuse, improper installation, neglect, improper shipping, damage caused
by disasters such as fire, flood and lightning, unauthorized repair or modifications will void said warranty. Should your driver box
prove defective during the warranty period, promptly contact Underwater Lights
driver box freight prepaid with the RMA number clearly marked on the outside of the shipping container.
Underwater Lights USA, LLC
3406 SW 26 th Terrace, C-6/7
Fort Lauderdale, FL 33312 USA
Phone: 1-954-760-4447
Fax: 1-954-525-3261
Internet: www.seavision.com
Email: sales@seavision.com
120-230VAC
® USA, LLC brand LED lights only.
USA, LLC for an RMA number and then return the
®
DOC:092305-1
Underwater Lights Europe Sarl
2323, Chemin de Saint-Bernard
Space Antipolis 6, 06220 Vallauris, France
Phone: 33-(0)-4-97-21-02-96
Fax: 33-(0)-4-97-21-10-96
Internet: www.seavision.com
Email: sales@seavisioneurope.com
® USA, LLC
