Summary of Contents for Toa PC-1860AB-EB
- Page 3 INSTALLATION ø156 ±3 mm (ø6.14" ± 0.12") Step 1. Using the supplied paper pattern as a guide, open a Ceiling 156 mm (6.14") ±3 mm (0.12") mounting hole in the ceiling panel. Max. 30 mm (1.18") Dome mounting bracket Step 2. Punch out the knockout hole in the fire dome, then install the supplied cable entry rubber grommet in Fire dome the knockout hole.
- Page 4 Step 8. Make wiring. FREQUENCY RESPONSE (1W, 4M) 8-1. Insert the lead-in cables (cables from the amplifier) and lead-out cables (cables to other speakers) into he input connector according to the terminal indication. Note: Hook the two ends of one of the speaker mounting springs into the hooks in the fire dome during connection.
