- Page 1 Libretto Istruzioni Instruction Manual Manuel d’Instructions Bedienungsanleitung Gebruiksaanwijzing Manual de instrucciones KSEV96X...
- Page 2 Dear Customer, If you follow the recommendations contained in this Instruction Manual, your appliance will give you constant high performance and will remain efficient for many years to come. CONTENTS RECOMMENDATIONS AND SUGGESTIONS CHARACTERISTICS INSTALLATION MAINTENANCE...
-
Page 3: Recommendations And Suggestions
RECOMMENDATIONS AND SUGGESTIONS INSTALLATION • The manufacturer will not be held liable for any damages resulting from incorrect or improper installation. • The minimum safety distance between the cooker top and the extractor hood is 650 mm. • Check that the mains voltage corresponds to that indicated on the rating plate fixed to the inside of the hood. - Page 4 CHARACTERISTICS Dimensions Components Ref. Q.ty Product Components Hood Body, complete with: Controls, Light, Blower, Filters Telescopic Chimney comprising: Upper Section Lower Section Damper 14.1 Air Outlet Connection Extension Air Outlet Connection Ref. Q.ty Installation Components 7.2.1 Upper Chimney Section Fixing Brackets Wall Plugs Screws 4,2 x 44,4 Screws 2,9 x 9,5...
-
Page 5: Installation
INSTALLATION Wall marking: • Draw a vertical line on the supporting wall up to the ceiling, or as high as practical, at the centre of the area in which the hood will be installed. • Draw a horizontal line at: 965 mm above the hob for installation without the back panel, 965 mm above the surface on which the pack panel rests, for installation with the back panel. -
Page 6: Mounting The Hood Body
• Before attaching the hood body, tighten the two screws Vr located on the hood body mounting points. • Hook the hood body onto the screws 12a • Fully tighten support screws 12a • Adjust screws Vr to level the hood body. DUCTED VERSION AIR EXHAUST SYSTEM In order to install the ducted version, connect the hood to the chimney using either a flexible or rigid pipe ø... -
Page 7: Electrical Connection
• Connect the hood to the mains through a two-pole switch having a contact gap of at least 3 mm. Upper exhaust flue • Slightly widen the two sides of the upper flue and hook them behind the brackets 7.2.1, making sure that they are well seated. -
Page 8: Control Panel
Light Switches the lighting system on and off. S1 Led Motor running led. It flashes once after 100 working hours of the hood to indicate that the grease filters need washing. It flashes twice after 200 working hours to indicate that the grease filters need washing and that the anti-odour charcoal filters, if any, need changing. -
Page 9: Maintenance
MAINTENANCE CLEANING METAL SELF- SUPPORTING GREASE FILTERS Alarm signal reset • Switch off the lights and extractor motor. • Press button V2 for at least 3 seconds, until the leds start to flash. Cleaning the filters • The filters must be cleaned when led S1 flashes or at least every 2 months of operation, or more frequently for particularly heavy usage. -
Page 10: Activated Charcoal Filter (Recirculation Version)
Activated charcoal filter (Recirculation version) REPLACING THE ACTIVATED CHARCOAL FILTER • The filter is not washable and cannot be regenerated. It must be replaced when led S1 flashes twice or at least every 4 months. The alarm signal will only light up when the extractor motor is switched on. - Page 11 Quest’apparecchio è conforme alla norma europea sulla bassa tensione C.E.E. 73/23 relativa alla sicurezza elettrica e alle norme europee: C.E.E. 89/336 relativa alla compatibilità elettromagnetica e C.E.E. 93/68 relativa alla marcatura CE. This appliance conforms to European Low Voltage Directive 73/23/CEE governing electrical safety, European Directive 89/336/CEE on Electromagnetic Compatibility and Directive 93/68/CEE regarding CE Marking.
