Ruby R
AL5248 - AL4992
Weight / Peso
Housing / Corpo proiettore
IK class / classe IK
IP rating / grado IP
Ambient temp./ Temperatura ambientale
Power supply / Alimentazione
Inrush current / Corrente di spunto
Power / Potenza massima
Nominal current / Corrente nominale
Power factor / Rifasamento
Thermal protection / Protezione termica
Electrical class / Classe elettrica
Cable / Cavo
Control / Sistema di controllo
Channels / Canali
Color range / Colori
Optics/ Ottiche
Dimensions
Griven S.r.l. - Via Bulgaria, 16
46042 Castel Goffredo
Mantova - Italy
User Manual
551056 Rev. 1.1
Date: 15/09/2020
70A @230VAC cold start
6 High output multichip LEDs additive synthesis: RGBW-
millions of colours, DW- from 2700°K to 6500°K
spot, narrow, medium, wide
280mm
11"
280mm
11"
Tel. +39.0376.779483
© Copyright Griven 2018 - Griven reserves the right to make
changes to this product and related instructions at any time
Fax +39.0376.779682
without prior notice and such changes shall be effective
E-mail: sales@griven.com
immediatly
Web: www.griven.com
AL5248 Ruby MC R
5 Kg (11 Lbs)
Stainless steel/Alluminum, scratch resistant paint
-40°C to 50°C ( -40°F to122°F)
100-277 VAC 50/60Hz
58 W
0,26A@230VAC
cos.φ=0,97
0,3 m. Power , 1 m. DMX
USITT DMX-512
4-5-6 (RGBW), 2-3 (DW), 1 (Monochromatic)
.
AL4992 Ruby R
4,6 Kg ( 10,14 Lbs)
IK09
IP67
50A @230VAC cold start
0,17A@230VAC
cos.φ=0,9
Electronic
I
20 High output LEDs additive synthesis: RGBW-millions
of colours, DW- from 2700°K to 6500°K
spot, narrow, medium, wide, extra wide, elliptical, ellipti-
cal wide, wall wash
120mm
4 3/4"
153mm
6"
36 W
Advertisement
Related Manuals for Griven Ruby MC R AL5248
Summary of Contents for Griven Ruby MC R AL5248
- Page 1 11" 6" Griven S.r.l. - Via Bulgaria, 16 Tel. +39.0376.779483 © Copyright Griven 2018 - Griven reserves the right to make changes to this product and related instructions at any time 46042 Castel Goffredo Fax +39.0376.779682 without prior notice and such changes shall be effective Mantova - Italy E-mail: sales@griven.com...
- Page 2 Important notices / Avvertimenti importanti - This product must be installed in accordance with applicable national and local electrical and construction codes by a person familiar with the construction and operation of the product and the hazards involved. Failure to comply with the following installation instructions may result in death or serious injury. Questo prodotto deve essere installato secondo le normative locali, da personale specializzato.
- Page 3 Connecting -The power and signal connections can be carried out by using the connection kit enclosed in the box. Follow the instructions provided along with the connection kit. -Le connessioni dei cavi di alimentazione e segnale possono essere eseguite utilizzando il kit di connessione in dotazione al proiettore.
- Page 4 -We suggest to follow the instruction below when installing the formwork in the ground. The non observance of this rule it will result in an uncorrect light projection. -Suggeriamo di seguire le istruzioni a seguito durante l’installazione della cassaforma. La mancata osservanza di queste rego- le provocherà...
-
Page 5: Line Terminator
Configurations MASTER/SLAVE - FIXED COLOR mode Fixture 1 Fixture 2 Fixture 3 Fixture n MASTER CH001 CH01 CH01 CH001 Line terminator DMX cable DMX cable DMX cable 120Ω (not included) WARNING ! in this mode, no other DMX control device must be present along the line. ATTENZIONE ! in questa modalità... - Page 6 Setup -Ruby must be configured only by using AL1321 IR remote control ( sold separately ) or from any DMX-RDM compatible controller. -Ruby deve essere configurato solo utilizzando AL1321 IR remote control ( venduto separatamente) oppure tramite una cen- tralina DMX-RDM. 5’...
- Page 7 · On/Off identifi cation: questo comando è usato per rintracciare l’unità sulla quale si vuole operare ( il proiettore si metterà in evidenza accendendo tutti i LED a massima intensità). · Manufacturer: viene mostrato in nome del produttore ( Griven ). · Model description: viene mostrato il modello del proiettore.
- Page 8 (only Ruby MC R PE ) Polar Edition features ( only for PE fi xtures ) The POLAR Edition is fi tted with a thermal glass which is particularly useful for outdoor applications. In fact, by warming up, the glass melts ice and snow which might interfere with the projection. When the projector is on, if required by the weather conditions, the glass is automatically warmed up.
