Aqua-Scope AQSWIE02 Manual

Wifi water leakage monitor
Hide thumbs Also See for AQSWIE02:
Table of Contents

Advertisement

Quick Links

Download this manual
WIFI Water Leakage Monitor
AQSWIE02
automatically created 2024.02.16, 09:53:54 @ www.aqua-scope.com/manuals
WIFI Water Leakage Monitor
Product Description
The Aqua-Scope water leak monitor detects water leaks and records the
temperature and water pressure. In combination with an Aqua-Scope remotely
controlled shut-off valve, the system regularly searches for microleaks and shuts off
the water if necessary. The user is then alerted via radio, both during such incidents
and when pressure anomalies are detected. An additional wired flood sensor can be
connected directly to the device. Furthermore, up to 10 additional wireless sensors
can be distributed and connected throughout the building to detect water leakage
and report it to the monitor via radio. The device consists of two parts:
Main Unit (Monitor): Detects water consumption and leaks by analyzing
pressure waves; Records temperature, water consumption, and water
pressure continuously; Wireless alerts for detected leaks or when pressure or
temperature thresholds are exceeded or not reached; Option to connect an
additional wired flood sensor directly to the device.
External Sensor Head: Connected to the water pipe, installed somewhere in
the building at a 1/4-inch inspection opening, or with a provided T-piece
under any sink at the angle valve.
SKU: AQSWIE02
Version: 1.1.0
1 / 14

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AQSWIE02 and is the answer not in the manual?

Questions and answers

Related Manuals for Aqua-Scope AQSWIE02

Summary of Contents for Aqua-Scope AQSWIE02

  • Page 1 SKU: AQSWIE02 Version: 1.1.0 Product Description The Aqua-Scope water leak monitor detects water leaks and records the temperature and water pressure. In combination with an Aqua-Scope remotely controlled shut-off valve, the system regularly searches for microleaks and shuts off the water if necessary. The user is then alerted via radio, both during such incidents and when pressure anomalies are detected.

  • Page 2: Installation

    It is recommended to choose a location as low as possible in the apartment (ideally in the basement or on the first floor). Attention! If a pressure reducing valve (PRV) is installed, the Aqua-Scope monitoring device must be installed between the pressure reducer and the individual outlets.

  • Page 3: Connecting To Wlan

    5. Connect the metal hose to the top of the connector and secure it with the 19mm wrench. 6. Screw the Aqua-Scope pressure sensor head into the side opening of the connector and secure it by hand. It is not necessary to tighten it too much.
  • Page 4 Now, enter the SSID and WPA key of the home Wi-Fi. If you want to control your device later via the Aqua-Scope app, you need to have an Aqua-Scope account and provide this email address so that the device can be associated with your account.

  • Page 5: Device Usage

    WIFI Water Leakage Monitor AQSWIE02 automatically created 2024.02.16, 09:53:54 @ www.aqua-scope.com/manuals there is more information on this. The 'Save' button saves and activates the values. If they were correct, the red/green blinking stops. Otherwise, the process must be repeated with the correct SSID and WPA key.
  • Page 6 When the monitor is connected to the local Wi-Fi, its functions can be used through various communication methods (even parallel): 1. Mobile Phone App: You won't find the Aqua-Scope app in your phone's app store. We use a Progressive Web App (PWA, more at wikipedia.org/wiki/Progressive_web_app).
  • Page 7 WIFI Water Leakage Monitor AQSWIE02 automatically created 2024.02.16, 09:53:54 @ www.aqua-scope.com/manuals shortcut of the website must be added to the desktop to receive push notifications if allowed. 2. MQTT Server: When configured accordingly, the sensor's status information is sent to the configured MQTT server. The MQTT service must be active, and your own MQTT server/port/login must be set in the device.
  • Page 8 Therefore, installing the monitor on an upper floor and a shut-off motor directly at the water meter in the basement is not a problem. The motor needs to be paired with the monitor through the Aqua-Scope App. In the app's configuration menu, there is an option for "New Sub-Device." Only the QR code/ID on the device needs to be entered, and the motor is ready for operation.

  • Page 9: Battery Operation

    WIFI Water Leakage Monitor AQSWIE02 automatically created 2024.02.16, 09:53:54 @ www.aqua-scope.com/manuals done through "New Sub-Device" in the app, and the app automatically recognizes the type of device to be paired. Pipe-Check The detection of micro-leaks in the pipe system requires a special measurement method called 'Pipe-Check.' This process takes about 240 seconds, and during this...
  • Page 10 Device Specific Alarms and Parameters If you want to use the device within a machine-2-machine environment (MQTT, JSON Web Services) the Aqua-Scope Developers Manual will provide you with all the required information that apply to all Aqua_Scope devices. Here you find the missing device-specific information complementing the description within the Aqua- Scope Developers Manual.

  • Page 11: Scope Of Delivery

    WIFI Water Leakage Monitor AQSWIE02 automatically created 2024.02.16, 09:53:54 @ www.aqua-scope.com/manuals general format of alarm message and general alarm types please refer to the ‘Aqua- Scope Developer manual’): Type = 1 (mask = 0x001): One of the external water sensors has tripped, indicated water nearby the device.

  • Page 12: Support And Contact

    The reproduction and distribution of the documentation and software supplied with this product and the use of its contents is subject to written authorization from Aqua-Scope. We reserve the right to make any alterations that arise as the result of technical development.
  • Page 13 ακόλουθη ιστοσελίδα στο διαδίκτυο: www.aqua-scope.com/ce Français Le soussigné, Aqua-Scope Technology OÜ, déclare que l'équipement radioélectrique du type AQSWIE02 est conforme la directive 2014/53/UE. Le texte complet de la déclaration UE de conformité est disponible l'adresse internet suivante: www.aqua-scope.com/ce Hrvatski Aqua-Scope Technology OÜ ovime izjavljuje da je radijska oprema tipa AQSWIE02 u skladu s Direktivom 2014/53/EU.

  • Page 14: Disposal Guidelines

    Português O(a) abaixo assinado(a) Aqua-Scope Technology OÜ declara que o presente tipo de equipamento de rádio AQSWIE02 está em conformidade com a Diretiva 2014/53/UE. O texto integral da declarao de conformidade está disponível no seguinte endereo de Internet: www.aqua-scope.com/ce Română...
