Tern Shortbed Tray Quick Start Manual

Shortbed Tray
Manual Version 04
Make sure you have all the latest information
needed to use and enjoy this product!
Visit ternbicycles.com/support
What's Included
Weight Limit
• 35 kg (77 lb) max load on paved roads.
• 17 kg (37 lb) max load on graded and maintained gravel roads.*
* Riding off-road poses unique challenges. Reduce the max load by approximately 50% if riding on unpaved roads to ensure safety.
Refer to the 'Intended Use' section in your bike's QuickStart Guide to learn more about suitable riding terrains.
Safety
Do not use the Shortbed Tray to move your bike.
Place loads evenly and as central on the Tray as possible.
Secure all cargo before riding. Take care that all straps are tied down and any loose item is secured.
Check to ensure all accessories have been correctly installed and securely fastened before riding.
Your bike may behave differently when carrying cargo.
Installation
Tools required (not included)
• 10 mm Wrench
• 4 mm Allen Wrench
Affix Rubber Pads
Clean metal surface with rubbing alcohol to remove dirt and oil. Peel off back of sticker and affix to the locations shown in the diagram below.
Shortbed Tray Gen 1
™
for updated:
Rubber Pad
Inside Tray
Outside Tray
