Summary of Contents for PawHut D51-155
- Page 1 IN240400156V01_GL D51-155 US_CA...
- Page 2 ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩...
- Page 3 ① ⑤ ⑤ ⑤ ① EN_Assemble Upper Level Cage. Connect the Upper Section Front Wire Panel to the two Upper Section Side Panels using the "J"shaped wire hooks. Alternate the hooks as you weave the wire connection. FR_Assemblage de la cage de niveau supérieur Connectez le panneau de fil avant de la section supérieure aux deux panneaux latéraux de la section supérieure à...
- Page 4 ⑥ ⑥ EN_Connect the Upper Top and Back Panel to the connected Upper Section Front and Upper Section Side panels by placing the Upper Top and Back Panel onto a flat surface and connecting the back panel to the Side Panels using the "J" shaped wire hooks. Place Upper Top Panel onto a flat surface to connect to the Front and Side Panels.
- Page 5 EN_Weave the Back Panel and the Side Panels together using the "J" Shaped Wire hooks. FR_Tissez le panneau arrière et les panneaux latéraux ensemble à l'aide des crochets en forme de «J». ES_Entreteja el panel trasero y los paneles laterales utilizando los ganchos de alambre en forma de "J".
- Page 6 ③ ② ③ ② EN_Assemble Lower Level Cage Connect the Lower Section Front Wire Panel to one of the Lower Section Side panels using the "J" shaped wire hooks. These hooks are designed to create a woven connection point. Start at the bottom and alternate hooks as you weave the wire connection. FR_Assembler cage de niveau inférieur Connectez le panneau de fil avant de la section inférieure à...
- Page 7 ④ ④ EN_Connect the Lower Section Back Wire Panel to the Lower Section Side Panel using the “J”Shaped wire hooks. Make sure the horizontal wires face towards the outside. FR_Connectez le panneau arrière du fil de la section inférieure au panneau latéral de la section inférieure à...
- Page 8 ② ② EN_Connect the remaining Lower Section Side Panel to the Lower Section Front and Back Wire Panels using the "J" shaped wire hooks. FR_Connectez le panneau latéral de la section inférieure restante aux panneaux de fil avant et arrière de la section inférieure à l'aide des crochets en forme de «J». ES_Conecte el panel lateral de la sección inferior restante a los paneles de cables delantero y trasero de la sección inferior utilizando los ganchos de cable en forma de "J".
- Page 9 ⑧ ⑧ ⑩ ⑩ EN_Place the Top Base onto the Lower Cage Connect the Cage Connectors centered on the short sides of the cage as pictured Clamp the Cage Connectors to secure the Wire to the Base. FR_Placez la base supérieure sur la cage inférieure Connectez les connecteurs de la cage centrés sur les petits côtés de la cage, comme illustré.
- Page 10 EN_Make sure all of the Cage Connectors are secure before moving your assembled cage. Place the assembled Upper Cage into the Top Base with door facing forward. Connect the Cage Connectors centered on the short sides of the cage. Clamp the Cage Connectors to secure the Top Wire to the Base.
