TWO-DOOR REFRIGERATOR WITH
BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS.
Write Model and Serial Numbers here:
Model No.:
Serial No.:
TOP FREEZER
Models: FF1142PL
User Manual
1
Felix Storch, Inc.
An ISO 9001:2015 registered
company
770 Garrison Ave
Bronx, New York 10474
www.summitappliance.com
Advertisement
Table of Contents
Related Manuals for Summit FF1142PL
Summary of Contents for Summit FF1142PL
- Page 1 TWO-DOOR REFRIGERATOR WITH TOP FREEZER Models: FF1142PL User Manual BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS. Write Model and Serial Numbers here: Felix Storch, Inc. An ISO 9001:2015 registered Model No.: company 770 Garrison Ave Serial No.:...
-
Page 2: Safety Information And Warnings
Contents Cleaning and care Safety information and warnings Helpful tips Installing your new appliance Troubleshooting Description of the appliance Disposal of the appliance Control Panel Using your appliance Safety information and warnings For your safety and correct usage, before installing and first using the appliance, read this user manual carefully, including its hints and warnings. - Page 3 GENERAL SAFETY WARNING —This appliance is intended to be used in household and similar applications such as -staff kitchen areas in shops, offices, and other working environments. -farmhouses and hotels, motels, and other residential-type environments. -bed and breakfast type environments. -catering and similar non-retail applications.
-
Page 4: Electrical Safety
WARNING — The refrigerant and insulation blowing gas are flammable. When disposing of the appliance, do so only at an authorized waste disposal center. Do not expose to flame. WARNING —When positioning the appliance, ensure the supply cord is not trapped or damaged. - Page 5 Daily use Do not store flammable gas or liquids in the appliance, there is a risk of an explosion. Do not operate any electrical appliances in the appliance (e.g., electric ice cream makers, mixers etc.). When unplugging always pull the plug from the mains socket, do not pull on the cable.
- Page 6 this manual. Unpack the appliance and check if there are damages to it. Do not connect the appliance if it is damaged. Report possible damages immediately to the place you bought it. In this case, retain packing. It is advisable to wait at least four hours before connecting the appliance to allow the oil to flow back into the compressor.
-
Page 7: Installing Your New Appliance
Installing your new appliance Before using the appliance for the first time, read the following: 4"(100mm) WARNING! For proper installation, this refrigerator must be placed on a level surface of hard material that is the same height as the rest of the flooring. - Page 8 Climate class Ambient temperature +10°C to +32°C +16°C to +32°C +16°C to +38°C +16°C to +43°C Install your appliance in a dry place to avoid a high amount of moisture. Keep the appliance out of direct sunlight, rain, or frost. Keep the appliance away from heat sources such as stoves, fires, or heaters.
- Page 9 Reversing the door The side at which the door opens can be changed, from the right side (as supplied) to the left side, if the installation site requires it. Warning! When reversing the door, the appliance must not be connected to the electrical grid.
- Page 10 Place the lower door on a smooth surface with its panel upwards. Loosen ○ ○ Part and then loose screws ○ ○ screws , and detach part . Then ○ ○ Remove part and part ○ install part to the corresponding position on the left side together with ○...
- Page 11 13. If reinstalled correctly, it should look similar to step 2. Move the upper hinge ○ cover to the left and affix it with screws ○ ○ and then install the screw cover ○ Finally, move the screw hole cover the right.
-
Page 12: Description Of The Appliance
Description of the appliance Location of Parts Freezer vents Freezer shelf Freezer temperature control Refrigerator vents Refrigerator temperature control Refrigerator shelf Crisper cover Crisper Adjustable bottom feet 10. Freezer door gasket 11. Freezer door 12. Freezer door rack 13. Refrigerator door gasket 14. - Page 13 Please read the recommended temperature settings below. The temperature of the compartments inside the refrigerator can be adjusted by using the control panel. Use the refrigerator as you normally would and set the regulator in the middle position. Condition Refrigeration compartment Summer (Higher than 90°F) ¼...
-
Page 14: Using Your Appliance
Using your appliance Location of Parts Your appliance comes with the accessories shown in the section of this manual, this part of the manual will provide further information about them. We recommend that you read through it carefully before using the appliance Door Rack Ensure that drink bottles are not left in the It is suitable for the storage of eggs,... -
Page 15: Cleaning And Care
Cleaning and care hygienic reasons appliance (including exterior and interior accessories) Interior cleaning should be cleaned regularly (at least every You should regularly clean the appliance two months.) interior. Wipe the inside of the refrigerator WARNING! freezer with a weak solution of bicarbonate The appliance must not be connected to of soda, and then rinse with warm water the power source during cleaning as there... -
Page 16: Replacing The Light Bulbs
the interior is completely dry should the appliance be switched back on and plugged back into the mains socket. Door seals cleaning Be sure to keep door seals clean. Sticky food and drinks can cause seals to stick to the cabinet and tear when you open the door. -
Page 17: Helpful Tips
Helpful tips Energy saving tips: Butter and cheese: We recommend that you follow the tips Should be wrapped in airtight foil or plastic below to save energy. film wrap. Try to avoid keeping the door open Milk bottles: for long periods in order to conserve Should have a lid and be stored in the door energy. - Page 18 To avoid the cross-contamination of food, observe the following instructions: - Regularly clean surfaces that come in contact with food and accessible drainage systems. - Store raw meat and fish in suitable containers in the refrigerator, so that it does not make contact with or drips onto other food.
-
Page 19: Troubleshooting
NOTE: Please store foods according to the compartments or the target storage temperature of your products. - If the refrigerator is going to be left empty for long periods of time, switch it off, defrost it, clean it, dry it, and leave the door open to prevent mold from developing within the appliance. -
Page 20: Disposal Of The Appliance
You may have left the doors open too long or too frequently, or the doors are kept open by some obstruction; or the appliance was The temperature inside installed with insufficient clearance at the sides, back, and top is too warm The temperature inside Increase the temperature by following the “controls panel”... -
Page 21: Limited Warranty
LIMITED WARRANTY ONE-YEAR LIMITED WARRANTY Within the 48 contiguous United States, for one year from the date of purchase, when this appliance is operated and maintained according to instructions attached to or furnished with the product, warrantor will pay for factory- specified parts and repair labor to correct defects in materials or workmanship.
