Universal Floor Pan/Drain - Pm7X2; Touch-Up Paint Carbon Graphite - Wr97X27706 - GE Profile UltraFast Combo PFQ97HSPVDS Accessories Manual

FLOOR PAN
LOW PROFILE FLOOR PAN WITH DRAIN / WHITE
TOUCH-UP PAINT
0.6OZ. BLACK SLATE / CARBON GRAPHITE
• Low profile tray perfectly fits the Combo with or
without riser attached.
• PVC connector included and easily attaches to
floor drain for added protection
• Dimensions: 29" x 33" interior (31" x 35" exterior)
1.64" deep
• Drain location is 1.75" from edge of tray. Drain
exit fitting mates to a 1-1.5" PVC pipe.
1. Remove the floor pan from the packaging.
2. Place it in the final installation location and attach
the drain fittings if so desired.
3. Install the Combo onto the pan being careful not
to damage the unit r tray. It may help to tip the
unit slightly to slide it over the pan lip and slide
into the final location.
• Precision Color wet paint designed specifically to
match your appliance appearance surfaces.
• WR97X27706 Color has been formulated to
hide / fill scratches on the Combo's metal and
plastic panels.
• Applicator brush integrated into the cap.
GE PROFILE UltraFast Combo Accessories Guide |
PM7X2
WR97X27706
www.geappliances.com | 11
