MEIKO M-iClean PF
Utensil washer
Original operating instructions
For the types in the series: M009DWFL10M1-****
EN
CAUTION - Before using the machine, read the
Operation, Product description and Safety chapters
carefully!
9020879 / Valid from: 2021-09 / Update: 2023-09
PF-S
www.meiko.info

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M-iClean PF M1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Meiko M-iClean PF M1

Summary of Contents for Meiko M-iClean PF M1

  • Page 1 MEIKO M-iClean PF Utensil washer Original operating instructions PF-S For the types in the series: M009DWFL10M1-**** CAUTION - Before using the machine, read the Operation, Product description and Safety chapters carefully! 9020879 / Valid from: 2021-09 / Update: 2023-09 www.meiko.info...

  • Page 2: Table Of Contents

    Contents NOTES ON THE OPERATING INSTRUCTIONS ........5 Product identification Delivery contents Related documents Presentation conventions 1.4.1 Safety symbols in the instructions SAFETY ....................... 7 Intended use Misuse Safety information What to do in the event of an emergency Requirements for the personnel PRODUCT DESCRIPTION ...............
  • Page 3 MEIKO M-iClean PF 3.10.2 Rinse aid 3.10.3 Dosing equipment 3.10.4 Suction lances 3.10.5 Change of products TECHNICAL DATA ................... 26 EC/EU declaration of conformity TRANSPORT ..................... 28 ASSEMBLY ....................28 Requirements for the installation site Requirements to the electrical connection...
  • Page 4 Adjust dosing quantity Changing the programme assignment CLEANING ....................57 10.1 Cleaning the interior 10.2 Cleaning the glass operating panel 10.3 Cleaning the exterior stainless steel surfaces 10.4 Cleaning the surrounding area 10.5 Descaling NON-USE FOR SEVERAL DAYS ............. 65 11.1 Break in operation (e.g.

  • Page 5: Notes On The Operating Instructions

    Product identification These operating instructions apply to the following machine types: M-iClean PF Type M1: M009DWFL10M1-10 Delivery contents • MEIKO M-iClean PF Type M1 utensil washer • Rack • Connection hoses for fresh water and waste water • Spanner for changing pre-filter (only with GiO MODULE option) •...

  • Page 6: Presentation Conventions

    Presentation conventions Warnings DANGER – indicates an imminently hazardous situation which, if not avoided, will result in serious injury or death. WARNING – indicates a potentially hazardous situation which, if not avoided, could result in serious injury or death. CAUTION – indicates a possible hazardous situation which, if not avoided, could result in minor or moderate injury or damage to property.

  • Page 7: Safety

    The washware must be suitable for commercial dishwashing machines. MEIKO does not accept any liability for damages resulting from improper use or incorrect operation. Any other use, conversions and modifications are not per- mitted and are dangerous.

  • Page 8: Safety Information

    According to the standards DIN 10510, 10511 and 10512, performance opti- misation systems must not lead to a reduction in the necessary operating temperatures. If performance optimisation systems are used, MEIKO does not accept any responsibility for a possible reduction in the quality of the wash and hygiene.
  • Page 9 MEIKO M-iClean PF Transport • During transport, it is essential to pay attention to the centre of gravity and thus to a secure position on the forks. To avoid damage, do not unpack the parts of the machine until you reach the installation site.
  • Page 10 • As an alternative to equipotential bonding, the operator can, acting on its own responsibility, use a mains-side residual current device (RCM or RCD) for personal protection. A type “A” according to IEC 60755 is sufficient. • Installation components must be suitable and permitted in accordance with local regulations.

  • Page 11: What To Do In The Event Of An Emergency

    MEIKO M-iClean PF Maintenance and repair (troubleshooting) • Only use original spare parts from the manufacturer. • Observe the maintenance specifications and intervals, including those of op- tional bought-in parts. • Before opening the housing parts, ensure the local main switch has been disconnected and secured so that it cannot be turned on again.

  • Page 12: Requirements For The Personnel

    Requirements for the personnel Installation, commissioning, instruction, repair and maintenance of MEIKO prod- ucts may only be carried out by authorised service partners. The operator must check the area around the machine or system for hazards to other persons, e.g. children or persons with reduced physical, sensory or men- tal capabilities, or with a lack of experience or knowledge.

  • Page 13: Product Description

    MEIKO M-iClean PF Note The instructions must be acknowledged in writing. Qualified staff, as defined by the operating instructions, are persons: • Over 14 years of age. • Due to their training, experience and instruction are able to perform the re- quired activities.

  • Page 14: Overview Illustration

    Overview illustration Exterior view 1 Glass operating panel, see page 2 Height-adjustable foot 3 Pre-filter for GiO reverse osmosis 4 GiO reverse osmosis module (op- module tion) 6 Exhaust air heat recovery system 5 Door (option) 7 Interior 8 Programme start button 9 Rack 10 Door in 90°...
  • Page 15 MEIKO M-iClean PF Interior view 1 Filter 2 Heating element 3 Air gap 4 Tank cover sieve (two-part) 5 Wash pipes (bottom and top) 6 Rinse arms (bottom and top) 7 Tank (on left in illustration) Connections 1 Connections for dosing pipes...

  • Page 16: Glass Control Panel

    Rack 1 Hold-down grid for light washware 2 Rack with wheels (option) Glass control panel READY FOR OPERATION OPERATION Progress bar shows programme progress 16 / 76 9020879...
  • Page 17 MEIKO M-iClean PF Keys Meaning Meaning Service access key On/off key (MEIKO key) • Filling/heating on • Machine off • Programme inter- ruption Programme start key Confirmation keys • Flashing green: fill- • Meaning/function is ing/heating active / shown on the dis-...

  • Page 18: Wash Programmes

    Wash programmes 3.4.1 Programme assignment The programme assignment varies depending on the machine type, electrical connection and water supply. The programme assignment is shown in the fol- lowing tables. M-iClean Voltage Variant PF-S Programme position 3NPE 400V Glass 10 11 12 Dishes Thermolabel* 15 16 17...
  • Page 19 MEIKO M-iClean PF M-iClean PF-S P: 60s, B: 81°C, P: 90s, B: 81°C, P: 120s, B: 81°C, T: 60°C, T: 60°C, T: 60°C, KSP: 4,5 l KSP: 4,5 l KSP: 4,5 l P: 180s, B: 81°C, P: 240s, B: 81°C, P: 360s, B: 81°C,...

  • Page 20: Type Label

    Type label Meaning Name and address of manu- MEIKO facturer Maschinenbau GmbH & Co. KG Englerstraße 3 D-77652 Offenburg Made in Germany Machine type Model Model name Serial No. Serial number ○ ● ○ ○ Electrical connection variant Connection Date...

  • Page 21: Illuminated Programme Start Key

    MEIKO M-iClean PF Illuminated programme start key Blue Green Malfunction/important Ready for operation Programme is running message Blue operating concept The parts of the dishwashing machine that must be touched by the operator in operation and during daily cleaning are blue. This means that the operator knows intuitively, even after a quick briefing, that they have to remove and clean the washing system, tank cover sieve and filter, for example.

  • Page 22: Options

    3.8.3 External dosing The dishwashing machine can be equipped with an external dosing system (e.g. solid detergent) ex works or subsequently by the MEIKO service depart- ment. 22 / 76 9020879...

  • Page 23: Automatic Standard Functions

    MEIKO M-iClean PF Automatic standard functions 3.9.1 Eco mode 3.9.2 Extended cycle runtime The actual programme duration differs from the specified programme duration if it is not sufficient to heat the fresh water to the specified temperature. In this case, the cycle runtime is extended. The programme then runs until the re- quired temperatures are reached, but for a maximum of 5 minutes.

  • Page 24: Detergent And Rinse Aid

    If necessary, the concentration can be adjusted depending on the water quality, washware and degree of soiling. This setting is made during com- missioning by an service technician authorised by MEIKO or the chemical sup- plier. Change dosing quantity, see page 56.

  • Page 25: Dosing Equipment

    The service life of the dosing units and other components of the dishwashing machine depends on the use of suitable chemical products. MEIKO recom- mends MEIKO ACTIVE detergent and rinse aid. MEIKO ACTIVE products are optimally adapted to the dishwashing machine.

  • Page 26: Technical Data

    3. Wipe the suction lance and put it into the canister with the other detergent product. 4. Refill the dosing system by venting the lines. For dishwashers with an internal reservoir, have the system flushed by a ser- vice technician authorised by MEIKO. Technical data Environmental conditions Operating temperature 5-40 °C...
  • Page 27 MEIKO M-iClean PF Dimensions M-iClean PF-S standard M-iClean PF-S with exhaust air heat recovery M: Installation clear- A: Entry height T: Split ance * max. 500 (door folded down) ** max. 2369 (door folded down) Country-specific deviations are possible. Binding specifications can be found on the order-specific dimension sheet.

  • Page 28: Ec/Eu Declaration Of Conformity

    EC/EU declaration of conformity See separate EC-/EU-Declaration of Conformity. Transport The packaging is specifically designed to allow the machine to be moved safely and securely using a pallet jack. For safe transport, the dishwashing machine is supported by a special square timber frame. •...

  • Page 29: Requirements For The Installation Site

    MEIKO M-iClean PF Requirements for the installation site The dishwashing machine is only frost-proof in as-delivered state or if equipped with special features (optional: frost removal). Installation of the dishwashing machine in an area where the ambient tempera- ture is below 0° C can result in damage to the internal water circuit components (e.g.
  • Page 30 • Mains power cables, unless part of the standard product scope of supply, must be oil-resistant, sheathed, flexible cables no lighter than a normal poly- chloroprene-sheathed cable (or other equivalent synthetic elastomer) with the marking 60245 IEC 57. • Refer to the circuit diagram for technical data for the main switch such as torque and stripping length.

  • Page 31: Requirements For The Fresh Water Connectionrequirements For The Fresh Water Connection

    Commercial Cooking Operations, NFPA * Where discharge currents exceed 10 mA, the use of an RCD is not recom- mended. False alarms restrict machine availability. MEIKO expressly excludes any liability for damages caused by improper connection of the machine.
  • Page 32 Fresh water connection Water quality The fresh water must be of drinking water quality from a microbiological perspective. This also ap- plies to treated water. Air gap Type AB according to EN 1717 or EN 61770 Pressure booster pump after air gap Equipment Solenoid valve/leakage detector switch Minimum flow pressure...
  • Page 33 MEIKO M-iClean PF Fresh water limit values when operating a reverse osmosis module Designation Value 70 – 1000 µS/cm Conductivity 0 – 28 °dH Water hardness Feed water temper- Min. 1°C to max. 35°C (cold water connection) ature Minimum flow pres-...

  • Page 34: Requirements For The Waste Water Connection

    Requirements for the waste water connection • • Waste water connections must comply with DIN EN 1256 and the locally ap- plicable regulations. Wastewater connection Drain pump present? Grease trap Observe local regulations Maximum drain height With GiO MODULE: 650 mm above finished floor Without GiO MODULE: 700 mm Special national condi-...
  • Page 35 MEIKO M-iClean PF 1. Turn on the tap. 2. Switch on the power. 3. Check the canister fill level. 4. Open the door with both hands. 5. Check that the filter, sieves, wash pipes and rotating arms are cor- 6. Close the door with both hands.

  • Page 36: Start Up The Machine

    The time required for the machine to be ready to operate depends on the temperature of the water supply and the installed heating capacity. 1. Touch the MEIKO key to activate 2. Touch the on/off key for 1 second. the display.

  • Page 37: Putting In Washware

    MEIKO M-iClean PF Putting in washware • Remove coarse residues (food, pastry, etc.). • Pour leftover drinks into the sink. • Soak cutlery and kitchen utensils until they are washed. Examples • Hollow containers must always be loaded upside down. Otherwise the water will not be drained from the washware and brilliant drying will not be possi- ble.

  • Page 38: Selecting The Wash Programme

    • Always place trays and dishes into the rack at an angle. The inner surfaces face upwards. • If cutlery quivers are used, always insert the cutlery pieces with the handles down. • Mix spoons, knives and forks in each cutlery quiver as far as possible, as cutlery of the same type can lie close together.

  • Page 39: Washing

    MEIKO M-iClean PF Washing Pre-washing • Dispose of leftovers and waste separately, empty liquids into the slop sink unit. • Remove larger pieces as well as possible. CAUTION – Hand injuries when opening/closing or folding down the door • Always use both hands to open/close the door or fold it down for cleaning.
  • Page 40 4. Change the programme if required, 3. Close the door with both hands. see page 38. 5. Start the programme. 40 / 76 9020879...

  • Page 41: End Of Programme

    MEIKO M-iClean PF End of programme CAUTION – Danger of burns and scalding due to hot wash water, washware and machine parts • Allow hot washware or machine parts to cool down before touching or use gloves. • Do not open the door while the programme is running.

  • Page 42: Interrupting The Programme

    2. Remove the washware. 3. Push in the rack, close the door. Interrupting the programme 2. Change the programme if neces- 1. Touch the on/off key. sary. 42 / 76 9020879...

  • Page 43: Switch Off The Machine

    MEIKO M-iClean PF Switch off the machine Shutdown machine? 2. Answer the query in the affirma- 1. Touch the on/off key. tive or touch the on/off key di- rectly a second time. SELF-CLEANING MACHINE OFF The machine carries out a self- Clean the machine after the self- cleaning routine.

  • Page 44: Replace Canister

    8.10 Assistance in case of malfunctions WARNING – Danger to operator and damage due to improper repairs • Repairs to the product may only be carried out by MEIKO authorised service technicians. Many malfunctions can be rectified without the help of customer service. The following malfunctions can be remedied by the operating personnel or the in- house technician.
  • Page 45 Unsuitable detergent Change product Unsuitable rinse aid As a rule, malfunctions that are not described here require assistance from a MEIKO authorised service technician. Please contact your subsidiary or author- ised dealer. 9020879 45 / 76...

  • Page 46: Messages

    8.10.1 Messages When a malfunction occurs, a grey or red message is shown on the display de- pending on the nature of the malfunction. • Grey messages can be acknowledged using the relevant confirmation key. • Red messages usually require the deployment of an authorised service tech- nician.
  • Page 47 MEIKO M-iClean PF Display text Measures/remedial action • Check drainage sieve, clean if necessary Drainage level not reached • Call a service technician if re- quired • Possible to continue working Tank temperature not reached • Call a service technician! Wash time increase insufficient •...
  • Page 48 Display text Measures/remedial action • Sort washware correctly Maximum final rinse cycles in- • sufficient Possible to continue working • Forced drainage due to perma- Change water or drain machine nently filled boiler at least once a day • Check rinse system and clean if necessary Pressure booster pump or air •...
  • Page 49 MEIKO M-iClean PF Display text Measures/remedial action • Energy optimisation active Possible to continue working • Tank temperature not reached Call a service technician! • Energy optimisation active Possible to continue working • Wash time increase in tank in- If this message reoccurs, call a...

  • Page 50: Modifying Settings

    The machine must be in MACHINE OFF mode. Touch the on/off key once for this. The machine does not need to be emptied! 1. Touch the MEIKO key for approx. 2. Enter the service code of the re- three seconds.
  • Page 51 MEIKO M-iClean PF i-menu Symbol Level Description Languages 1, 4 Set display language Set descaling parameters Wash tank 1, 4 View status Final rinse 1, 4 View status Set dosage quantity for detergent, Chemicals rinse aid and dosing agent 3...

  • Page 52: Resetting The Pre-Filter Counter

    Action menu Symbol Level Description Vent detergent Starts the dosing unit to vent the 1, 4 pipe lines, e.g. if the canisters have be- come empty during operation. Vent rinse pipe 1, 4 Manually start wa- 1, 4 Drain wash tank completely and refill. ter change Manually start Partially drain wash tank and refill...

  • Page 53: Private Label

    (for 3 seconds). This only works if you order the op- tion in advance! 3. Call up https://privatelabel.meiko- 4. Click the "Create new graphics set" global.com. button. 9020879...
  • Page 54 The selection menu for uploading the welcome screen and screen saver ap- pears. + can be used to upload two additional screen saver motifs, if required. 5. Click in the display to upload. 6. Select the file. 7. Adjust the size and position, rotate 8.

  • Page 55: Ventilating The Pipes

    2nd waiting time until Start Private Label. 0 means: always ON= no screen saver or 2nd waiting time deactivated. 3. Touch the MEIKO key for 3 seconds and confirm the request to log off from the current session by checking the box.

  • Page 56: Changing Water

    Changing water Depending on the contamination, 100% (water change) or approx. 50% (partial water change) of the water can be renewed. 1. Switch to level 1, see page 50. 2. Call up the action menu using the relevant confirmation key. 3.

  • Page 57: Cleaning

    MEIKO M-iClean PF Cleaning 10.1 Cleaning the interior CAUTION - Danger of burns from hot machine parts • Let the machine cool down before cleaning • Wear protective gloves if necessary. • Only use the handles provided for opening or closing.
  • Page 58 3. Remove the rack from the ma- 2. Open the door with both hands. chine. 5. Fold down the door with both hands. 4. Push the latch mechanisms on the left and right upwards. CAUTION – Lever linkage moves out of the machine! 58 / 76 9020879...
  • Page 59 MEIKO M-iClean PF 6. Remove the wash pipes and rinse 7. Clean the wash pipes and rinse arms. arms. 9. Remove the tank cover sieve and 8. Clean the interior. filter. 9020879 59 / 76...
  • Page 60 10. Clean the tank cover sieve and fil- 11. Clean the tank heater. ter. 13. Reinstall everything in reverse or- 12. Wipe down the seals. der. 60 / 76 9020879...
  • Page 61 MEIKO M-iClean PF 14. Fold the door upwards with both hands until the wheels engage be- 15. Insert the rack and push it in. hind the latch mechanisms. 16. Close the door with both hands, leaving it open a crack.

  • Page 62: Cleaning The Glass Operating Panel

    10.2 Cleaning the glass operating panel Clean the glass operating panel with a damp cloth. 62 / 76 9020879...

  • Page 63: Cleaning The Exterior Stainless Steel Surfaces

    MEIKO M-iClean PF 10.3 Cleaning the exterior stainless steel surfaces CAUTION – Material damage to stainless steel due to incorrect clean- Cleaning of parts made of stainless steel with unsuitable detergents, care products and cleaning utensils leads to damage, deposits or discolourations on the machine.

  • Page 64: Descaling

    If necessary, run the descaling programme for the tank interior. The boiler can only be descaled by a service technician! 1. Touch the MEIKO key for approx. three seconds. 2. Enter service code 40044. 3. Call up the action menu using the relevant confirmation key.

  • Page 65: Non-Use For Several Days

    MEIKO M-iClean PF Non-use for several days 11.1 Break in operation (e.g. seasonal operation) • Run self-cleaning programme and clean the machine, see page 57. • Close the on-site shut-off valve. • Switch off on-site mains isolator. • Manually open a gap in the front door or hood to prevent germ formation and odours.

  • Page 66: Maintenance

    After a year, the message Carry out maintenance appears on the display. CARRYING OUT MAINTENANCE MEIKO recommends having the machine serviced by an authorised service technician at least once a year. As part of the maintenance, an electrical safety inspection is also carried out in accordance with DIN VDE 0701-0702/DGUV Regulation 3.
  • Page 67 MEIKO M-iClean PF • Thoroughly rinse the new filter car- tridge inside and out with clean wa- ter. Replacing the filter cartridge (dishwashing machine is disconnected from power and water supply) 1. Use the spanner to unscrew the 2. Empty out the water and remove housing by turning it clockwise.
  • Page 68 3. Thoroughly clean and rinse out 4. Replace the old sealing ring. the filter housing. Remove depos- its. 5. Insert the new filter cartridge, 6. Keep the housing vertical and which has already been thor- screw back on by hand. oughly rinsed both inside and out.

  • Page 69: Dismantling And Disposal

    MEIKO M-iClean PF 7. Check seal: connect water and 8. Mark date label and apply to filter power supply. Fill machine or run unit. a cycle. 9. Replace any covers removed. 10. Reset exchange interval in the controller, see page 52.

  • Page 70: Disposal Of Packaging Materials

    13.1 Disposal of packaging materials All the packaging materials are recyclable. The following materials are used: • Square timber frame • Plastic sheeting (PE film) • Foam • Cardboard packaging (edge protection) • Packaging strap (steel strip) • Packaging strap (plastic (PP)) •...

  • Page 71: Index

    MEIKO M-iClean PF Index Action menu ........ 57 Delivery contents ......6 Adjust dosing quantity ....62 Descaling....... 57, 69 AirConcept ........26 Designation of machine type ..6 Assembly ........33 Detergent........28 Assistance in case of malfunctions Detergent and rinse aid ....28 ..........
  • Page 72 Glass control panel ..... 19 Presentation conventions ....7 Pre-washing ........ 45 Private Label 2.0 ......59 i-menu ......... 57 Product description ..... 15 Intended use ......... 8 Programme Interrupting the programme ..49 PF-S ............. 23 Programme assignment ....21 Level Programme start key ....
  • Page 73 MEIKO M-iClean PF Switching on ........ 39 Ventilating the pipes ....61 Technical data ......30 Wash programmes ...... 21 Waste water connection ....38 Water change ......57 Vent detergent supply ....57 What to do in the event of an Vent rinse pipe ......

  • Page 74: Notes

    Notes ……………………………………………………… ……………………………………………………… ……………………………………………………… ……………………………………………………… ……………………………………………………… ……………………………………………………… ……………………………………………………… ……………………………………………………… ……………………………………………………… ……………………………………………………… ……………………………………………………… ……………………………………………………… ……………………………………………………… ……………………………………………………… ……………………………………………………… ……………………………………………………… ……………………………………………………… ……………………………………………………… ……………………………………………………… ……………………………………………………… ……………………………………………………… ……………………………………………………… ……………………………………………………… ……………………………………………………… 74 / 76 9020879...
  • Page 75 MEIKO M-iClean PF 9020879 75 / 76...
