Summary of Contents for Tobbi TH17E0987
- Page 2 For more information,please browse TOBBI Kids Car, for Kids and Fun!
-
Page 3: Structure Chart
Structure Chart To reduce the risk of injury, adult supervision is required. Never use on roadways, near motor vehicles, on or near steep inclines or steps, swimming pools or other bodies of water; always wear shoes, and never allow more than one rider Never leave a child unattended Steering Front Fender... - Page 4 Spare Parts Product Figure M10*95 Screw M10 Gasket M12 Gasket M10 Gasket M4*14 Screw M5*30 Screw M5*30 Screw Cotter Pin Charger Spanner...
- Page 5 Assembly Steps Assembly Steps 1.Insert the rear axle(11) into the motor hole,and pass through the 1. Install the front wheel iron(7) from the bottom to the top on the opposite side of the body,so that both sides of the rear axle are even. front steering bracket.
- Page 6 Assembly Steps Assembly Steps Install the Front Wheel Install the Steering Connecting 1. Install a M12 gasket(14) and slide it into the front axle. 1.Install the steering adapter(5) connecting rod and fasten the M5 2. Install the front wheel(8) on the front axle. nut(17) with a short 5*30MM screw with a gasket(17).
- Page 7 Assembly Steps Assembly Steps Install the Steering Rod Install the Steering Wheel Connecting Rod 1. Pass the steering axle(6) through the steering hole and align it 1.Connect the terminal at the bottom of Part No. 2 to the terminal on through the connecting rod, the chassis.
- Page 8 Assembly Steps Assembly Steps Install the Seat Fixed Base 1. Install the seat(3) on the body and fix it with 4 M4*14 screws(16). 1.Use a screwdriver to tighten 2 M4x14 screws(16) at the pre-drilled screw holes on both sides of the armrest to fix the base.
- Page 9 Assembly Steps Funciton Diagram and Operation Method Change the music Klaxon 1. Use a screwdriver to remove the rear cover according to the position shown in the figure, and then connect the two connection terminals below. 2. Cover the rear cover tightly. Pedal High speed Forward...
- Page 10 Charge Mode Funciton Diagram and Operation Method Battery indicator The charging outlet is located under the seat. Plug one end of the part 11 Turn up the volume · charger into a charging outlet and the other end into a wall outlet. Turn down the volume Charge the battery for at least 12 hours before initial use.
-
Page 11: Simple Troubleshooting
Disclaimer Simple Trouble Shooting The vehicle moves slowly Drive on level ground The vehicle...
